Summary of Contents for Camouflage EZ Birdfeed

Page 1 Camouflage EZ Birdfeed Instruction Manual...
Page 2 LINK TO ALL LANGUAGE MANUALS Scan the QR code to download manuals in all languages available Zeskanuj kod QR, aby pobrać instrukcje we wszystkich dostępnych językach. Scan de QR-code om handleidingen in alle beschikbare talen te downloaden. Scan QR-koden for at downloade manualer på alle tilgængelige sprog.
Page 3: Table Of Contents
TABLE OF CONTENTS PREFACE TIPS WHAT’S IN THE BOX? SPECIFICATIONS INTRODUCTION CAMERA OVERVIEW HOW TO CONNECT TO THE APP APP INTERFACE INTRODUCTION TOP COVER INSTALLATION HOW TO INSTALL THE BIRDFEEDER 10. HOW TO CHARGE THE CAMERA GUARANTEE 12. FAQ...
Page 4 CAMOUFLAGE WEBSITE Scan the QR code to go directly to our website, where you'll find a wide range of videos, guides, and product tutorials. Quickly and easily access all the information you need to make the most of your product!
Page 5: Preface
PREFACE Congratulations on purchasing the Camouflage EZ-BirdFeed. To use our product easily and have a general understanding, we have created this manual, especially for you. This manual explains how to systematically use this camera. Read this manual carefully before use to master the method quickly and correctly.
Page 6: Tips
1. TIPS TIPS Keep the bird feeder and all accessories out of reach of children and pets. • Make sure the camera has been fully charged for the first time. • Please do not expose the camera lens to sunlight directly. •...
Page 7: What's In The Box
2. WHAT’S IN THE BOX? Bird feeder Bird feeder bracket Bracket connector Drill sticker Perch Screw 3 Screw for Green screws spacers bracket Waterproof Screw for Charging Perch 2 rubber cable...
Page 8: Specifications
3. SPECIFICATIONS Product Model EZ-BirdFeed Charging Solar panel and USB cable Battery 5200 mAh Rechargeable Lithium-Ion Battery 2.0MegaPixels Photos and 1080P HD Live Stream Resolution Video Operating Temperature -5°F to 120°F (-20.5°C to 48.5°C) Wireless Type WiFi 2.4GHz Field of View Diagonal: 130°, Horizontal: 94°, Vertical: 40°...
Page 9 3. SOLAR PANEL SPECIFICATION IPCE Working Voltage (Vmp) 6V±5% Working Current (Imp) 400mA±5% Open Circuit Voltage 7.2V±5% (VOC) Short-Circuit Current 480mA±5% (ISC)
Page 10: Introduction
4. INTRODUCTION Solar panel Camera Perch...
Page 11: Camera Overview
5. CAMERA OVERVIEW Indicator light Infrared LED Microphone Motion sensor Light sensor Lens Mounting hole Speaker Power on/off Sync/Reset Charging port TF card slot (capacity expansion 128gb)
Page 12 5. CAMERA OVERVIEW INDICATOR LIGHT Camera turn on: Red light always ON. Pairing mode: Red light fast blinking. Network connecting: Green light fast blinking. Network connected: Green light always ON. Abnormal status : Red light slow blinking.(Need to reset). During firmware update: Yellow light always ON. Charging status: White light always ON during charging and OFF after fully charged.
Page 13: How To Connect To The App
6. HOW TO CONNECT TO THE APP INSTALLING THE APP SCAN ME!
Page 14 6. HOW TO CONNECT TO THE APP Download or scan the QR code and install the Bird Lover App for either IOS or • Android. Once downloaded, the APP will prompt you to register your device. Enter your email address and select the country you live in. You will receive the registration code.
Page 15 6. HOW TO CONNECT TO THE APP 2. Open the APP and connect according to the following steps. Select the device: BF11...
Page 16 6. HOW TO CONNECT TO THE APP 3. Enter the WIFI password.
Page 17 6. HOW TO CONNECT TO THE APP Problems connecting? Make sure to follow the following steps: 1. Find out if you have 2.4Ghz 2. Switch to 2.4Ghz if you have a dual band wifi router link: https://wildcameraxl.nl/pages/wifi-eng...
Page 18 6. HOW TO CONNECT TO THE APP 4. Scan the QR code with the camera, and enter the connection after hearing the sound of the camera prompt. NOTE: The QR code needs to be aimed at the camera below...
Page 19 6. HOW TO CONNECT TO THE APP 5. Wait for the connection to complete, and click "Done" .
Page 20: App Interface Introduction
7. APP INTERFACE INTRODUCTION Quality adjustment : you can choose HD or SD Battery Remaining Capacity Voice switch Zoom in the screen for camera Screen horizontal and vertical adjustment Take photo Bird recognition Shot videos Playback for previous View photos or videos took Check out the bird collection Share the device Motion detection(Click to turn...
Page 21: Top Cover Installation
8. TOP COVER INSTALLATION Align the top cover with the groove of the birdhouse and press down. 2. Connect the battery charging cable to the top cover.
Page 22: How To Install The Birdfeeder
8. TOP COVER INSTALLATION 3. Twist and snap the top cover. 9. HOW TO INSTALL THE BIRDFEEDER 1. Stick the sticker on the tree or wall and drill holes within the range marked on the sticker.
Page 23 9. HOW TO INSTALL THE BIRDFEEDER 2. Insert the green plastic screw spacers into the hole. 3. Fix the bracket with long screws.
Page 24 9. HOW TO INSTALL THE BIRDFEEDER 4. Install the bird feeder and align the three holes underneath. 5. Fix bird feeder with three short screws.
Page 25 9. HOW TO INSTALL THE BIRDFEEDER 6. Install the perch with the two screws in the package. 7. The bird house can rotate left and right.
Page 26: How To Charge The Camera
10. HOW TO CHARGE THE CAMERA Rotate the camera down. Connect the solar charging cable. Or remove the camera and charge it with the charging cable.
Page 27: Guarantee
11. GUARANTEE We are very proud of our products. We always keep our promises. We offer advanced warranty period and service. When you purchase our product, you are covered by a limited warranty. We warrant our products to be free from defects in materials and workmanship for a limited warranty from the date of original purchase.
Page 28: Faq
12. FAQ Q: Do I need to create an account to use the App? A: Yes, you need to use an email address or phone number to get a verification code for registering an account. Q: What operating systems are the App compatible with? A: The App is compatible with Apple iOS and Android systems.
Page 29 12. FAQ Q: Why is the camera battery draining so fast? A: It is a low power consumption camera. Plus the solar panel power in charge can maintain the daily energy consumed on sunny days. If the battery drains too fast you should check: Whether you check the camera with APP too often.
Page 30 12. FAQ Q: Why the recognition result is wrong? A: The accuracy rate depends on the angle and clarity of the bird image. To get a more accurate result, please ensure the picture is clear enough. The identified features (bird’s head, tail wings, and pattern of feathers) should not be obscured.
Page 31: Declaration Of Conformity
DECLARATION OF CONFORMITY...
