Slican MAC-6400 Technical Specifications

Digital pbxes
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Technical
Specifications
for Digital PBXes
Slican MAC-6400
Slican MAC-ZERO
PBX Structure
Revision 1.05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAC-6400 and is the answer not in the manual?

Questions and answers

Summary of Contents for Slican MAC-6400

  • Page 1 Technical Specifications for Digital PBXes Slican MAC-6400 Slican MAC-ZERO PBX Structure Revision 1.05...
  • Page 2 The MAC-6400 PBX contains software is accessible on the base of the GNU General Public Licence, Mozilla Public License and other licenses derived from BSD. The contents of the license document have been enclosed on a CD.

  • Page 3: Table Of Contents

    Slican MAC-6400 Table of contents Table of content 1 Introduction.....................5 2 Basic parameters and characteristics of the Slican MAC-6400 PBX.......6 2.1 Functional features..................6 2.2 Technical data....................6 2.3 Line lengths....................7 2.4 Connecting additional consoles to CTS-202 system sets........8 2.4.1 Example 1 – consoles powered from main supply connected to CTS-202..8 2.4.2 Example 2 –...
  • Page 4 6.2 Data communication interfaces..............53 6.3 Lines fitted with RJ-45 plugs..............54 6.4 Lines fitted with RJ-21 plug...............55 7 Specification of technical parameters of the Slican MAC-6400 PBX.....56 8 External dimensions of MAC-6400 PBXs............56 9 Safety requirements in operating Slican MAC-6400 PBXes.........57 9.1 Installation and service................57...

  • Page 5: Introduction

    Slican MAC-6400 1 Introduction Digital PBX Slican MAC-6400 have been designed with the purpose of providing solutions for communication systems of large companies, where the maximum number of subscribers does not exceed 640. Basing ourselves on the rich experience gained designing and...

  • Page 6: Basic Parameters And Characteristics Of The Slican Mac-6400 Pbx

    Technical specifications 2 Basic parameters and characteristics of the Slican MAC-6400 PBX 2.1 Functional features • modularity of PBXs, • remote management of the PBX through a modem, an LAN network or the Internet, by means of PC, • LCR – inteligent call routing, cost reduction, reliability, networking, •...

  • Page 7: Line Lengths

    Slican MAC-6400 2.3 Line lengths Type of line Range 1500m with AWG-22 (point-point) 1000m for cable 0.6mm , 120nF (point – 750m for cable 0,6mm , 120nF multipoint) According to the WTO – Operator’s (TP S.A.) Technical Requirements - maximum loop resistance for 1800 Ω direct current with a terminal (only for cable approx.

  • Page 8: Connecting Additional Consoles To Cts-202 System Sets

    162. The other system telephone sets can be equipped with a maximum of two Slican CTS-232 consoles, which allows to extent the number of speed access keys to 72. For system phones CTS-102 or CTS-102.IP it is not possible to extend number of speed access keys using console CTS-232.

  • Page 9: Example 2 - To Consoles Powered From Cts-202, Remain From Power Supply Connected To Cts-232

    Slican MAC-6400 2.4.2 Example 2 – to consoles powered from CTS-202, remain from power supply connected to CTS-232 -202 connected with two first consoles using 6-wires cable, (assures power • supply of phone and two consoles from PBX). Three consoles are connected using 4-wires cable (without power supply).

  • Page 10: Accordance Of System Phone And Console Power Supply

    3 Architecture of the Slican MAC-6400 PBX 3.1 General information Slican MAC-6400 PBXes are operated in a hierarchical system. The system may be composed of maximum four elements called shelves, with one of them working as a superior device (Master) in relation to the other shelves (Slave). Such a situation is a consequence of equipping the shelf in one of two types of controllers: PBX master controller –...

  • Page 11: Components Of The Slican Mac-6400 Pbx

    19 inch racks. Fig. 4.1.: MAC-ZERO – front view There are some differences between this version and standard version of MAC-6400: 1. There is no possibility of adding next shelves. 2. Power supply device is installed on the back side of casing – it is mounted as standard by manufacturer.

  • Page 12: Mac-6400 Model

    Technical specifications Fig.4.2.: MAC-ZERO – back side view 4.2 MAC-6400 model 4.2.1 Main supply unit Fig. 4.3.: Main supply unit– front view There are diodes installed in the front of the main supply shelf and the meaning of the diode signals is as follows: POWER –...

  • Page 13: Pbx Shelf Housing

    4.2.3 PBX shelf base board CTR UPS Fig. 4.6.: View of base board MAC10BAZ for Slican MAC-6400, PCB number MAC10BAZv2 The base board is mounted on the inner back wall of the PBX shelf housing. It enables the fixing of equipment cards in the system and ensures connection between them. There are 12 card connections on the board.
  • Page 14 Terchnical specification On the master shelf base board, there is also a connection for the main supply unit, as related to sending signals concerning supply. The connection is presented on the above drawing as UPS Ctrl (it is marked with such a label on the PBX shelf rear panel, as viewed from the rear of the PBX housing).

  • Page 15: Housing 12U

    Slican MAC-6400 4.3 Housing 12U Housing 12 U enables to install one or two shelves of MAC-6400, eventually shelf of MAC- ZERO: • Marking: Slican MAC-6400.12U-XSH – where X=1..2 means number of shelves. Location of elements, starting from top: 1. main supply shelf – 2U.

  • Page 16: Housing 22U

    Terchnical specification 4.4 Housing 22U Housing 22 U enables to install 1 to 4 shelves of MAC-6400, eventually shelf of MAC-ZERO: • Marking: Slican MAC-6400.22U-XSH – where X=1..4 means number of shelves. Location of elements, starting from top: 1. main supply shelf – 2U.
  • Page 17 Slican MAC-6400 environment temperature is in range 25-30°C. • Fan set MAC.LID-8FAN is equipped in thermostat, it means, that fan operating is • subject of temperature inside housing. Following figure present installation method of cover with forced air flow or replacement of standard cover with gravity cooling to cover with forced air flow.

  • Page 18: Battery Housing

    BATB-3x12/7 – housing (smaller) for battery of 3 battery 7Ah – dedicated for MAC- • ZERO configuration. Operating time calculator can be accessed from ServNet: MAC-6400 section Example battery operating times as a function of battery capacity and PBX configuration: Type...

  • Page 19: Pbx Shelf Equipment Modules

    4.8 PBX shelf equipment modules 4.8.1 List of modules MAC-6400 PBX have a modular structure. A module in the PBX is an expansion card including a front panel. All modules are placed in the slots on the base board dedicated to them. The panels may occur in two different designs, as described separately for each module.
  • Page 20 Terchnical specification WARNING! Cards used in MAC are labelled HOT SWAP! - it mean they can be replaced when the power supply of the shelf where the cards are located is switched on Moreover, attention must be paid when replacing or installing a new card to sufficient tightening of the screws fastening the front panel to the PBX shelf casing to ensure an efficient protection against over-voltages that may occur in connected telecommunication lines.

  • Page 21: Maximum Numbers Of Cards In The Mac-6400 Pbx

    Slican MAC-6400 4.8.2 Maximum numbers of cards in the MAC-6400 PBX Limits concerning the Limits concerning the whole SHELF Note Card type Maximum Maximum Maximum Maximum number of number of number of number of cards accessories cards accessories MACxAB 10*16=160...

  • Page 22: Master Controller Module

    Print name: MAC1MPUv4 the PBX and supervises the operation of slave controllers. Only one master controller can be installed in the Slican MAC-6400 PBX. Card Card designation: MAC1MPU enables transmission with rate 10/100 Mbs View of the master controller card and its front panel: Installation of the card in the PBX: The controller card is located in the base plate slot marked as MPU/SPU.
  • Page 23 Slican MAC-6400 PRG – green diode flashes green slowly: the PBX is in the course of the startup (unit and shelves • initialisation), shines constantly green: a subscriber is logged to the PBX according to the SDTP • protocol (the PBXd programmed from the ConfigMAN software level), flashes quickly green: data are sent from/to the computer.

  • Page 24: Mac-Zero Master Controller Module

    Technical specification 4.8.4 MAC-ZERO master controller module Short description of the card: Module name: MAC.M-0MPU The master controller card is the main unit of the PBX. It is responsible for managing Print name: MAC1MPUv4 processes in the PBX and supervises the operation of slave controllers.
  • Page 25 Slican MAC-6400 ERR – indicates an error detected in the PBX. Red diode: shines constantly red: a non-critical error (e.g. a fault of the E1 translation), • flashes red: a critical error (e.g. a conflict of cards in the PBX).

  • Page 26: Slave Controller Module

    Print name: MAC1MPUv3 where it is installed. Up to three slave controllers Card can be installed in the Slican MAC-6400 PBX. enables transmission with rate 10/100 Mbs. Card designation: MAC1SPU View of the slave controller card and its front panel: Installation of the card in the PBX: The slave controller card is placed in the base plate slot marked as MPU/SPU.

  • Page 27: E1 (Isdn-Pra) Route Module

    Slican MAC-6400 4.8.6 E1 (ISDN-PRA) route module Short description of the card: Module name: MAC.MRJ-1E1 The E1 route card ensures communication with the PSTN networks through the ISDN PRA (30B+D) connection. Print name: MAC1E1v2 Card designation: MAC1E1 View of the card and the card front panel: Installation of the card in the PBX: All cards of the E1 route are installed in lots marked as SLOT 1 to SLOT 10.

  • Page 28: Isdn-Bra Digital Accessories Module

    Technical specification 4.8.7 ISDN-BRA digital accessories module Short description of the card: Module name: MAC.MRJ-8ST MAC.MRJ-4ST The digital accessories cards include ISDN 2B+D accessories. Each connection can be configured as a translation (urban line) or a subscriber inner contact. Print name: MAC8STv2 Card designations: MAC8ST MAC4ST...
  • Page 29 Slican MAC-6400 Elements of ISDN contacts configuration: Digital accessory ports, marked on the card board as S , can be configured as external ports (translations), and internal (subscriber) ones. The mode of the port operation is defined by setting of the armatures on the board. Armature positions: EXT –...

  • Page 30: System Digital Accessory Module

    Technical specification 4.8.8 System digital accessory module Module names: MAC.MRJ-16CTS Short description of the card: MAC.MKB-16CTS MAC.MRJ-8CTS Digital accessory cards include accessories for MAC.MKB-8CTS system telephone sets CTS-202 and CTS-102. MAC.MRJ-4CTS MAC.MKB-4CTS Print name: MAC16CTSv1 MAC16CTS Card designations: MAC8CTS MAC4CTS View of the digital system accessories card: Documentation issue 1.05...
  • Page 31 Slican MAC-6400 Installation of the card in the PBX: All cards with system digital accessories (CTS) are installed in slots marked SLOT 1 to SLOT Types of accessory cards: MAC16CTS 16 ports U (CTS) MAC8CTS 8 ports U (CTS) MAC4CTS...
  • Page 32 Technical specification Short description of diodes on the front panel: STAT – two-colour diode off: the card has not been recognised by the controller, • flashes red: the card has been recognised but not initiated by the equipment (e.g. a •...

  • Page 33: Ass Analogue Trunk Module

    Slican MAC-6400 4.8.9 ASS analogue trunk module Short description of the card: Module name: MAC.MRJ-8ASS MAC.MRJ-4ASS The ASS trunk card is intended for connecting the PBX to analogue subscriber lines of the PSTN network. Print name: MAC8ASSv2 Card designations: MAC8ASS...
  • Page 34 Technical specification Front panels of the cards: MAC.PCRJ-8AB MAC.PCRJ-4AB Short description of the diode on the front panel: STAT – two-colour diode off: the card has not been recognised by the controller, • flashes red: the card has been recognised but not initiated by the equipment (e.g. a •...

  • Page 35: Analogue Port Module

    Slican MAC-6400 4.8.10 Analogue port module Short description of the card: Module name: MAC.MRJ-16AB MAC.MRJ-8AB Analogue port cards are intended for operating MAC.MKB-16AB analogue telephone sets with DTMF or impulse MAC.MKB-8AB dialling. All cards are fitted with the CLIP function.
  • Page 36 Technical specification Front panels of the cards: MAC.PCRJ-16AB MAC.PCKB-16AB MAC.PCRJ-8AB Short description of the diode on the front panel: STAT – two-colour diode off: the card has not been recognised by the controller, • flashes red: the card has been recognised but not initiated by the equipment (e.g. a •...

  • Page 37: Voip Module

    Slican MAC-6400 4.8.11 VoIP module Short description of the card: Module name: MAC.M-0VoIP VoIP cards ensure integration of the PBX with the Internet telephony. Number of channels possible to use depends on: number of installed DSP sub-modules (1DSP – Print name: MACVOIPv2 =4 VoIP channels.

  • Page 38: Mac32Voip Module

    Technical specification Short description of the diode on the front panel: STAT – two-colour diode off: the card has not been recognised by the controller, • flashes red: the card has been recognised but not initiated by the equipment (e.g. a •...

  • Page 39: Ebdrec Calls Recording Module

    Slican MAC-6400 Installation of the card in the PBX: The card can be installed in any slot marked Slot 1 to SLOT 10. Short description of the diode on the front panel: STAT – two-colour diode off: the card has not been recognised by the controller, •...
  • Page 40 Technical specification View of the MACxREC card and the card front panel: Cards MAC.M-8REC-HD160GB and MAC.M-16REC-HD160GB look identical, they only differ in the number of the DSP modules inserted. System maintain up to 8 cards. Installation of the card in the PBX: The card can be installed in any slot marked Slot 1 to SLOT 10.

  • Page 41: Gsm Trunk Module

    Slican MAC-6400 4.8.14 GSM trunk module Short description of the card: Module names: MAC.MA-4GSM MAC.MA-2GSM GSM trunk cards are intended for maintaining MAC.MA-1GSM direct connections to the cellular telephony network. To operate the cards, external aerials delivered with the cards are required as well as SIM cards (to be placed on the card at sites marked SIM 1-4).
  • Page 42 Technical specification shines constantly green: the card has been initiated and functions properly, • shines constantly green, sometimes flashes red: traffic on one of the accessories (a • ring, an output to translation, and logging with the operator). [1-4] GSM – the green diode is off: the GSM module is switched off, •...

  • Page 43: Controlling Module 4Rl4Sn

    Slican MAC-6400 4.8.15 Controlling module 4RL4SN Short description of the card: Module names: MAC.MRJ-4RL4SN Controlling card is equipped with following ports: 4 REL relay terminals, • Print name: MAC8RELv0 4 SNS sensor tewrminals. • SNS working modes: DCI – voltage release - Max 5-30V DC •...

  • Page 44: Shelf Supply Unit Module

    Technical specification Configuration: Installation of the card in the PBX: All GSM translation cards are installed in slots marked SLOT 1 to SLOT 10. 4.8.16 Shelf supply unit module Short description of the card: Module name: MAC.M-1ZAS Shelf supply unit cards are intended for power supplying the PBX shelf equipment.

  • Page 45: Pbx Electronic Number (Sdn) Submodule

    Slican MAC-6400 Short description of diodes on the supply unit front panel: POWER – green diode on: the power supply unit functions correctly (values of VCC, VBB and VLL voltages • are correct) RING – green diode • on: the RNG voltage level is above 45V AC FAULT –...

  • Page 46: Dsp Submodule

    Technical specification 4.8.18 DSP submodule Short description of the submodule: Sub-module name: SM.DSP DSP sub-modules occur in two designs: 1. SM.DSP - supports G711a/μ and GSM codecs Can be used on VoIP and REC cards 2. SM.DSP-V - supports G711a/μ and G729 codecs Can be used on VoIP cards.

  • Page 47: System Installation

    MAC-6400 PBX. For the same reason, one should remember to tighten firmly enough those screws fastening accessory card front panels to the PBX shelf casing.

  • Page 48: Installation Requirements Regarding The Emergency Supply System

    5.2 Installation requirements regarding the emergency supply system Slican MAC-6400 PBXes are fitted with an emergency power supply system. To enable system functioning, the PBXs installed in manufacturer’s 19” casings have been equipped with 3 12V/17Ah batteries connected in series.

  • Page 49: Connections At The Back Of The Mac-Zero

    Table 5.1: System of inter-shelf connections between controllers WARNING! Any change in the length of the cables connecting A and B interfaces is not allowed for the sake of the cable transmission properties. 5.3.2 Connections at the back of the MAC-ZERO Fig. 5.2.: Connection of Slican MAC-ZERO...

  • Page 50: Inter-Shelf Connections At The Back Of The Mac-6400

    5.3.3 Inter-shelf connections at the back of the MAC-6400 Here Y ou should: - Insert jumper when PBX is installed in any 19'' rack - Connect external switch when system is installed in Slican casing Fig. 5.3. Inter-shelf connection for MAC-6400.EU-2SH...

  • Page 51: Backup Supply

    Slican MAC-6400 The following connections are to be made at the back of the PBX: main supply unit shelf – PBX shelves, ● main supply unit shelf – accumulator battery, ● equalizing connection between shelves (optionally, depending on the rack design).

  • Page 52: Connections And Interfaces

    6 Connections and interfaces 6.1 Computer interfaces in MAC-6400 PBXs Slican MAC-6400 PBXs can be reached locally by means of RS232 or USB connections or the LAN. The PBXs can also be connected to the WAN network. The WAN port is accessible, depending on whether or not the VoIP module is used in the system.

  • Page 53: Data Communication Interfaces

    Slican MAC-6400 3. USB – allows managing locally the PBX with the use of the ConfigMAN software. 6.2 Data communication interfaces Names used by Equivalent names applied Functionality Slican by other manufacturers Digital port for CTS-202 and CTS- 202.Plus telephone sets a/b;...

  • Page 54: Lines Fitted With Rj-45 Plugs

    Slican MAC-6400 6.3 Lines fitted with RJ-45 plugs Access E1 FUNCTION RX1 (receiving pair) RX2 (receiving pair) TX1 (sending pair) TX2 (sending pair) -36V ÷ -41,5V (supply of the HDSL modem) Interface ST Set as INT FUNCTION LRA (receiving pair)

  • Page 55: Lines Fitted With Rj-21 Plug

    Slican MAC-6400 6.4 Lines fitted with RJ-21 plug Analogue and digital internal lines can be connected to a distribution frame situated in the vicinity of the PBX, and then to the MAC system (via MAC.PCKB-16AB front panels) with the use of 21-pair cable ended with the RJ-21 plug ( MAC.KB21-6m – cable 6 metres long with the CENTRONICS 50-pin angle plug).

  • Page 56: Specification Of Technical Parameters Of The Slican Mac-6400 Pbx

    Slican MAC-6400 7 Specification of technical parameters of the Slican MAC-6400 PBX ONNECTIONS VoIP SIP, IAX • CTS for CTS-202.IP VoIP system digital telephone sets cooperating • with the PBX with the use of a protocol developed by Slican Dual Band: GSM 900, GSM 1800 •...

  • Page 57: Safety Requirements In Operating Slican Mac-6400 Pbxes

    Slican MAC-6400 9 Safety requirements in operating Slican MAC-6400 PBXes A rigorous observation of safety rules is an absolute requirement for proper equipment operation. The rules presented below are a basis for the manufacturer’s considering any complaints and comments of the users.

  • Page 58: Declaration Of Conformity And The Proper Disposal Of The Product

    A subscriber telephone PBX with a modular construction and capacity of up to 640 ports. The following devices can be connected to the PBX: analogue all-purpose telephone sets with the decade dialling and DTMF, Slican system digital telephones of the CTS-202 series as well as ISDN (EuroISDN) terminals, VoIP (SIP, IAX) terminals, telephone PBX interface for the cellular telephony network and VoIP, gatephones, and, through the MAB adapter, acoustic devices.
