Canopy Kit
Workman
Model No. 07140—Serial No. 316000001 and Up
This product contains a chemical or chemicals known to the State of California to
Installation
1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface, set the parking
brake, shut off the engine, and remove the key from
the ignition switch.
2. Remove the seats.
3. Raise the cargo box to the dump position.
© 2016—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
®
GTX Utility Vehicle
WARNING
CALIFORNIA
Proposition 65 Warning
cause cancer, birth defects, or reproductive harm.
Register at www.Toro.com.
Form No. 3407-127 Rev A
Installation Instructions
Original Instructions (EN)
All Rights Reserved *3407-127* A
Printed in the USA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Toro 07140
Summary of Contents for Toro 07140
- Page 1 Form No. 3407-127 Rev A Canopy Kit Workman ® GTX Utility Vehicle Model No. 07140—Serial No. 316000001 and Up Installation Instructions WARNING CALIFORNIA Proposition 65 Warning This product contains a chemical or chemicals known to the State of California to cause cancer, birth defects, or reproductive harm.
-
Page 2: Installing The Kit
Procedure Note: Do not tighten any fasteners except when instructed. 1. Install the left loop bracket as follows: A. Remove the rivet from left panel behind the rear Installing the Kit seat base (Figure B. Install the left loop bracket using 2 hex-flange Parts needed for this procedure: bolts (3/8 x 1 inch) and 2 nuts (3/8 inch) as shown in... - Page 3 D. Repeat this step to install the right loop bracket 4. Secure the middle bracket of the windshield support to on the right side of the machine. the machine using 2 hex-flange bolts (5/16 x 1 inch) and 2 nuts (5/16 inch) in the holes you drilled (Figure 2.
- Page 4 6. Loosely install the rear tubes to the rear loop brackets 8. Loosely install the left and right front plates and corner using 8 carriage bolts (5/16 x 2 inches), 2 mounting gussets to the crosslink tubes and the left and right plates, and 8 nuts (5/16 inch) as shown in Figure windshield supports using 8 carriage bolts (5/16 x...
- Page 5 10. Loosely install the front crosslink to the front plates 13. Install the sunshade to the rear crosslink using 2 and corner gussets using 4 carriage bolts (5/16 x 1-3/4 hex-flange bolts (1/4 x 1 inch), 2 sealing washers, inch) and 4 flange nuts (5/16 inch) as shown in Figure 2 friction washers, 4 plastic washers, and 2 flange bushings...
- Page 6 Notes:...
- Page 7 Notes:...
- Page 8 Countries Other than the United States or Canada Customers who have purchased Toro products exported from the United States or Canada should contact their Toro Distributor (Dealer) to obtain guarantee policies for your country, province, or state. If for any reason you are dissatisfied with your Distributor's service or have difficulty obtaining guarantee information, contact the Toro importer.
