HB80-1C
Remote control rolling code 433.92 MHz, 1 channel.
Designed to control RGB and RGBW lights.
1 - PRODUCT FEATURES
1.1
TECHNICAL DATA
Power supply
Programmable channels
Groups
Radio frequency
Code
Dimensions
80mm
Type CR2450 lithium battery
1
0
433,92 MHz ISM
Rolling code
Diameter 80X13
13mm
Battery
(insert right
way round)
7mm
Magnet
Advertisement
Summary of Contents for Nexta Tech HB80-1C
- Page 1 HB80-1C Remote control rolling code 433.92 MHz, 1 channel. Designed to control RGB and RGBW lights. 1 - PRODUCT FEATURES TECHNICAL DATA Power supply Type CR2450 lithium battery Programmable channels Groups Battery Radio frequency 433,92 MHz ISM (insert right Code...
-
Page 2: Description Of Transmitter
2 - USE OF TRANSMITTER DESCRIPTION OF TRANSMITTER Remote control rolling code 433.92 MHz, 1 channels and 1 group. Designed to control RGB, RGBW, tunable white lights, dimmer and ON/OFF device. The functions of each key depending on the type of lamp controlled are given below. FIG.2.1a COMMANDS SENT ON A CONTROL UNIT FOR COLOURED LIGHTS "Color"... - Page 3 FIG.2.1b COMMANDS SENT ON A CONTROL UNIT FOR TUNABLE WHITE "Color" key SHORT PRESS = change light temperature in steps LONG PRESS = dimmer ligh temperature, a gradual change “Play / memo” key “Speed / Cycle” key SHORT PRESS = SHORT PRESS = change speed (shown with leds) play/stop cycle...
- Page 4 USE OF TRANSMITTER To be able to use the transmitter you must first carry out the learning procedures on the receiver (see paragraph 3). SEND A COMMAND TO A DEVICE: 1- With the “channel” keys, select on the LEDs the channel associated with the device that you want to use. 2- Send the desired command with the "function"...
-
Page 5: Transmitter Programming
3 - TRANSMITTER PROGRAMMING To use the transmitter at least one channel must be programmed (paragraph 3.1). TRANSMITTER PROGRAMMING Default: no channel programmed This procedure is used to programme a channel in order to then associate it with a compatible receiver. Access to the receiver is required to carry out the following procedure. - Page 6 4 - DELETION OF A CHANNEL RECEIVER DELETION OF THE CHANNEL FROM THE RECEIVER This procedure is to delete one of the transmitter's channels from the memory of the receiver on which it was programmed. PROCEDURE: 1- Access the receiver and carry out the "delete single transmitter" procedure (see receiver manual).
- Page 7 Nexta Tech company brand of Team srl via G.Oberdan 90, 33074 Fontanafredda (PN) - Italy Ph. +39 0434 998682 Email: info@nexta-tech.com Web: www.nexta-tech.com...
