HomeControl Flex Installation: TG-1 Express with DMP XT30
The following information is to serve as a guide for installations of TG-1Express devices enabled for
Interactive Services with the DMP XT30. The configuration shown in the diagram below is an example of
how a proper installation could look. The output and zone could differ from the diagram, without changing
the outcome of the installation.
Installation Diagram
Note: Although a resistor is not depicted here, one may be required by the Keyswitch zone in accordance to the
Panel's specifications. For more information, please refer to the Panel's Installation and/or Programming Manuals.
Rev 2.0
1: Ring return
2: GND
3: STC
4: Ring
5: Tip
6: STC
7: DC+
8: Tip return
1
© 2015 Telguard
Advertisement
Summary of Contents for Telguard HomeControl Flex
- Page 1 HomeControl Flex Installation: TG-1 Express with DMP XT30 The following information is to serve as a guide for installations of TG-1Express devices enabled for Interactive Services with the DMP XT30. The configuration shown in the diagram below is an example of how a proper installation could look.
- Page 2 Programming Steps After getting into configuration mode, check/do the following: Set to Contact ID: Enable Open/Close Reports: Program Output: Rev 2.0 © 2015 Telguard...
- Page 3 Program Keyswitch zone: Reference Note For more detailed TG-1B and TG-4 installation and programming instructions, refer to the HomeControl Flex Installation Guide. Rev 2.0 © 2015 Telguard...
