GENERAL DESCRIPTION
The SGM7220 enables USB Type-C ports with the
Configuration Channel (CC) logic needed for Type-C
interface. The SGM7220 uses the CC pins to determine
port attachment and detachment, cable orientation, role
detection and port control for Type-C current mode.
The SGM7220 can be configured as a downstream
facing port (DFP), an upstream facing port (UFP) or a
dual role port (DRP) making it ideal for most
applications.
The SGM7220 alternates configuration as a DFP or an
UFP according to the Type-C specifications. The CC
logic block monitors the CC1 and CC2 pins for pull-up
or pull-down resistances to determine when a USB port
has been attached, the orientation of the cable, and the
role detected. The CC logic detects the Type-C current
mode as default, medium, or high depending on the
role detected. V
BUS
determine a successful attachment in UFP and DRP
modes.
The SGM7220 operates over a wide supply range and
has low power consumption. The device is available in
a Green UTQFN-1.6×1.6-12L package and operates in
industrial and commercial temperature range of -40℃
to +125℃.
SG Micro Corp
www.sg-micro.com
detection is implemented to
USB Type-C Configuration
Channel Logic and Port Control
FEATURES
● Supply Voltage Range: 2.7V to 5V
● Supports USB Type-C Specification 1.1
● Enable Control: Active Low ( EN Pin)
● Backward Compatible with USB Type-C
Specification 1.0
● Supports up to 3A of Current Advertisement and
Detection
● Mode Configuration
 Host Only - DFP (Source)
 Device Only - UFP (Sink)
 Dual Role Port - DRP
 Try.SNK
● Channel Configuration (CC)
 Attachment of USB Port Detection
 Cable Orientation Detection
 Role Detection
 Type-C Current Mode (Default, Medium or High)
● V
Detection
BUS
2
● I
C or GPIO Control
● Role Configuration Control through I
● Low Current Consumption
● -40℃ to +125℃ Operating Temperature Range
● Available in Green UTQFN-1.6×1.6-12L Package
APPLICATIONS
Host, Device, Dual Role Port Applications
Mobile Phones
Tablets and Notebooks
USB Peripherals
SGM7220
2
C
DECEMBER 2018 – REV. A
