- Page 1 RisingHF RHF0M0E5 User Manual UM019180 RHF0M0E5 User Manual V1.2 Document information Info Content Keywords RisingHF, User Manual, Instruction RHF0M0x5 module user manual to help users quickly use Abstract the module...
-
Page 2: Table Of Contents
RisingHF RHF0M0E5 User Manual Content Content ..............................2 1 Preface ............................... 1 2 Hardware Description ......................... 1 2.1 Pin definition ..........................1 2.2 Pin details............................. 1 3 quick start ............................2 3.1 ABP mode ............................ 2 3.1.1 ID query ..........................2 3.1.2 Configure band ........................ -
Page 3: Preface
RisingHF RHF0M0E5 User Manual 1 Preface ® RHF0M0E5 is a low-cost, ultra-low power, ultra-small size LoRaWAN module designed by Rui Xing Heng Fang Network (Shenzhen) Co., Ltd. The module uses ST system on chip STM32WLE5JC, ® intergrated high-performance LoRa SX126X IP and ultra-low power Consumption of MCU. The target application of this module is wireless sensor networks and other Internet of Things devices, especially battery-powered low power consumption and long-distance occasions. -
Page 4: Content
RisingHF RHF0M0E5 User Manual MCU GPIO ；LPUART1_TX from MCU MCU GPIO ；LPUART1_RX from MCU Ground RFIO RF input/output Ground Reset trigger input for MCU MCU GPIO；USART2_RX from MCU MCU GPIO；USART2_TX from MCU PB10 MCU GPIO MCU GPIO Ground MCU GPIO PB13 SPI2_SCK from MCU;... -
Page 5: Configure Band
RisingHF RHF0M0E5 User Manual +ID: DevEui, 20:4F:37:50:32:36:50:08 +ID: AppEui, 52:69:73:69:6E:67:48:46 3.1.2 Configure band Set the band of the node according to the working frequency of the gateway.( EU868、US915、US915、 HYBRID、CN779 、EU433、AU915、AU915OLD、CN470、AS923、KR920、IN865 、RU864、 CN470PREQUEL、STE920) Format： AT+DR=CN470 Return： +DR: CN470 3.1.3 Configure channels Set the channel of the node according to the type of gateway subnet Format：... -
Page 6: Otaa Mode
RisingHF RHF0M0E5 User Manual +MSG: Done 3.2 OTAA mode Use the AT+ID command to query the module ID information and register the ID information to the server OTAA mode device. Follow these steps to configure the node so that it can communicate with the server. -
Page 7: Configure Class
RisingHF RHF0M0E5 User Manual 3.2.5 Configure class Format： AT+CLASS=A Return： +CLASS: A 3.2.6 Join Use the at + join command to join the network. Start the network access process when the module is not connected to the network Format： AT+JOIN Return：... -
Page 8: Test Noise Floor
RisingHF RHF0M0E5 User Manual AT+TEST=RFCFG,[FREQUENCY],[SF],[BANDWIDTH],[TX PR],[RX PR],[TX POWER],[CRC],[IQ],[NET] Format： AT+TEST=RFCFG,470,7,125,8,8,14,OFF,OFF,OFF Return： +TEST: RFCFG F:470000000, SF7, BW125K, TXPR:8, RXPR:8, POW:14dBm, CRC:OFF, IQ:OFF, NET:OFF noise floor 3.3.1 test Parameter 470 is the test frequency (MHz) and parameter 25 is the number of samples. -
Page 9: Faq
RisingHF RHF0M0E5 User Manual Return： +TEST: LEN:3, RSSI:-11, SNR:12 +TEST: RX "AB04BA" 4 FAQ Q：Why does not the baud rate change take effect immediately after setting A：Restart the module to take effect after baud rate setting Q：Why there is no response when entering DFU mode A：In DFU mode, the baud rate of the serial port is 115200. - Page 10 RisingHF RHF0M0E5 User Manual ORIGINAL EQUIPMENT MANUFACTURER (OEM) NOTES The OEM must certify the final end product to comply with unintentional radiators (FCC Sections 15.107 and 15.109) before declaring compliance of the final product to Part 15 of the FCC rules and regulations. Integration into devices that are directly or indirectly connected to AC lines must add with Class II Permissive Change.
- Page 11 RisingHF RHF0M0E5 User Manual This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
-
Page 12: Revision
RisingHF RHF0M0E5 User Manual Revision V1.2 2020-09-25 + New OEM/FCC warning V1.2 2020-09-25 + Update STM32WLE5JC description V1.1 2020-05-08 + Initial creation V1.2 2020-09-25 www.risinghf.com... - Page 13 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted under this document. If any part of this document refers to any third party products or services it shall not be deemed a license grant by RisingHF for the use of such third party products or services, or any intellectual property contained therein or considered as a warranty covering the use in any manner whatsoever of such third party products or services or any intellectual property contained therein.
