Saftronics GP10 Addendum To Instruction Manual

Hide thumbs Also See for GP10:

Advertisement

Quick Links

Addendum to Instruction Manual
Several functions have been added and a few functions are changed
to increase the versatility of the GP10 and VG10 drives.
Please refer to both the instruction manual (P/N 027-GP1001
027-VG1001) and this addendum (P/N 027-1001A).
Function
No.
F14
Restart after momentary power
failure(selection)
F25
Stop Frequency
F41
Torque Limit 1 (Braking)
E17
Torque Limit 2 (Braking)
E01-E09
X1 to X9 Terminal Function
E20-E24
Y1 to Y4/Y5A and Y5C Transistor output
function
H07
ACC/DEC pattern (mode select)
Uxx
User Functions
The addendum applies for the following inverter ROM versions.
Inverter of
The software will be identified by the serial number on the unit.
Example: 0129-06061A001
The A in the serial number shows the drive has the latest software
installed.
ROM version in the maintenance information on the keypad panel.
(Please refer to section 4-3-9 Maintenance information in the instruction manual of the
inverter).
Saftronics, Inc.
5580 Enterprise Pkwy., Ft. Myers, Fl 33905
Telephone: (239) 693-7200
Fax: (239) 693-2431
www.saftronics.com
GP10 and VG10
Function Name
30Hp or less :S09000 or later
40Hp or more
Changed or added contents
In case of set value 2 or 3, setting
U23and U24 become effective.
Setting range changed to 0 to 60Hz.
U01 (maximum compensation
frequency during braking torque)
becomes effective.
Value set to 0% U60 becomes
effective.
Setting range increased to 0 to 35
Setting range increased to 0 to 37
Sharp S-shape set value = 2 is
changed to variable S-shape
New addition
:H09000 or later
PART NUMBER 027-2154
REV August 2002
