freeVoice Nimbus 60 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Nimbus 60
FBT060BT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nimbus 60 and is the answer not in the manual?

Questions and answers

Related Manuals for freeVoice Nimbus 60

Summary of Contents for freeVoice Nimbus 60

  • Page 1 Nimbus 60 FBT060BT...

  • Page 3: Table Of Contents

    User Manual 1. WELCOME 2. FBT060BTOVERVIEW 2.1 HEADSET OVERVIEW 2.2 INCLUDED ACCESSORIES 3. HOW TO WEAR 3.1 LEFT OR RIGHT WEARING STYLE 3.2 ADJUST THE HEADBAND 3.3 POSITION THE MICROPHONE 3.4 STORING THE MICROPHONE 4. HOW TO CHARGE THE BATTERY 5.

  • Page 4: Welcome

    1. WELCOME Thank you for using the FBT060BT Headset. We hope you will enjoy it ! FBT060BTFEATURES • Connect to PC via FCT170 Bluetooth adapter • Connect to mobile devices via Bluetooth • Dual microphones technology makes voice clear • Integrated Busylight •...

  • Page 5: Fbt060Btoverview

    2. FBT060BTOVERVIEW 2.1 HEADSET T-Bar Adjustable headband Adjustable headband Busylight indicator Multi-function button Busylight indicator Noise canceling microphone Multi-function button Voice pick up microphone Noise canceling microphone Voice pick up microphone Mute button Base Charge Point Volume up Bluetooth Volume down indicator USB charging port Power On/off/...

  • Page 6: Included Accessories

    2.2 INCLUDED ACCESSORIES Carry pouch USB-C cable Charging Base FCT170 (Optional) (Optional) 3. HOW TO WEAR...

  • Page 7: Left Or Right Wearing Style

    3.1 LEFT OR RIGHT WEARING STYLE The FBT060BTcan be worn on the right or left which you want. 3.2 ADJUST THE HEADBAND Adjust the headband to find the most comfortable fit.

  • Page 8: Position The Microphone

    3.3 POSITION THE MICROPHONE It is recommended to position the microphone close to your mouth. 3.4 STORING THE MICROPHONE Discreet boom arm can be neatly folded away into the headband when not on a call. Ear Cushion Removal Rotate the earmuff counterclockwise to remove it completely and then replace or clean it;...

  • Page 9: How To Charge The Battery

    4. HOW TO CHARGE THE BATTERY Option 1: The headset battery will be charged when connected to a PC using a USB cable, or when using any USB charger supplied with your mobile device. Option 2: If you have a charging base, you could plug the charging base into a powered USB port and then dock the headset.

  • Page 10: How To Connect

    5. HOW TO CONNECT 5.1 CONNECT TO PC (USING FCT170) 1. Ensure the headset is switched on. 2. Plug the FCT170 dongle into a USB port on your PC. The headset and FCT170 are already pre-connected. 5.2 CONNECT TO MOBILE DEVICE (USING BLUETOOTH) 1.

  • Page 11: How To Use

    6. HOW TO USE T-Bar Adjustable headband Adjustable headband Busylight indicator Multi-function button Busylight indicator Noise canceling microphone Multi-function button Voice pick up microphone Noise canceling microphone Voice pick up microphone Mute button Base Charge Point Volume up Bluetooth Volume down indicator USB charging port Power On/off/...

  • Page 12: Everyday Use

    6.1 EVERYDAY USE FUNCTION ACTION LED STATUS Blue Light flash twice in Headset on Slide the On switch succession Red Light flash twice in Headset off Slide the off switch succession Pairing Slide the Pair Button Blue Light flash Blue Light flash twice in Pairing Successfully succession Blue Light flash 1 time per...

  • Page 13: Multiple Call Handling

    6.2 MULTIPLE CALL HANDLING The headset can accept and handle multiple calls at the same time. FUNCTION ACTION End current call and Press the Multi-function button answer incoming call Put current call on hold Press and hold (2 secs) the and answer incoming call Multi-function button Switch between held call...

  • Page 14: Technical Specification

    8. TECHNICAL SPECIFICATIONS FBT060BTHEADSET SPECIFICATION Bluetooth Version: V5.0(Without BLE) Mono headset 106g Headset weight: Stereo headset 146g Mono headset L196.3mm x W72.5mm x H189.1mm Headset dimensions: Stereo headset L196.3mm x W72.5mm x H191.1mm Wear Style: Headband Talk Time: 26 hours Charging Time: 3 hours Charging Base:...

  • Page 15: Important Note

    Important Safety Instructions To prevent possible hearing damage, do not listen at high volume levels for long periods. FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules.
  • Page 16 AG Industriestrasse 4a CH-8604 Volketswil Switzerland UID: CHE-166.396.031 (Switzerland)
