Operating & Installation Instructions

Table of Contents

Need help?

Do you have a question about the charnwood C Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Blu charnwood C Series

Page 1 ® charnwood C-SERIES Operating & Installation Instructions...
Page 3: Table Of Contents
C-SEVEN Parts Lists ....22 C-EIGHT Parts Lists ....23 Ref. C-Series blu v4 02.18...
Page 4: Operating Instructions
OPERATING INSTRUCTIONS ® Congratulations on becoming the owner of a Charnwood C-Series FITTING THE WOOD ASH REMOVAL Stove. GRATE Before lighting the stove check with the installer that the work and Tools Required: checks described in the Installation Instructions have been carried out 10mm Socket correctly and that the chimney has been swept, is sound and free Pozidriv screwdriver...
Page 5: Lighting
OPERATING INSTRUCTIONS ® LIGHTING CONTROLLING THE FIRE On initial lighting, the stove may smoke and give off an odour as the The rate of burning and hence the output is controlled by the air silicon paint with which the firebox is painted reacts to the heat. This control (see Fig.
Page 6: Reduced Burning
OPERATING INSTRUCTIONS ® REDUCED BURNING Door Seals For the fire to operate correctly it is important that the door seals For reduced burning the fire door must be closed. are in good condition. Check that they do not become worn or When burning wood in areas that are not smoke controlled, load frayed and replace them when necessary.
Page 7: Chimney Sweeping
OPERATING INSTRUCTIONS ® CHIMNEY SWEEPING a) Wet or unseasoned wood, or logs overhanging the front fence will cause the glass to blacken. Where the chimney previously served an open fire, it is possible that b) The airwash relies on a supply of heated air to keep the glass clean, the higher flue gas temperature from a stove may loosen soot therefore, when lighting the stove allow the firebed to become well deposits with the consequent risk of flue blockage.
Page 8: Co Alarm
OPERATING INSTRUCTIONS ® d) Door seals and airwash slide are intact. Chimney Fires If the chimney is thoroughly and regularly swept, chimney fires should not occur. However, if a chimney fire does occur close the air control, and tightly close the door of the appliance. This should cause the chimney fire to go out in which case the controls should be kept closed until the stove has gone out.
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS ® HEALTH AND SAFET Y PRECAUTIONS The wrapping is first removed, then the stove released from the pallet by either removing the single bolt (C-4) or 4 pallet bolts(C-5 to Please take care when installing the stove that the requirements of C-8) using a 10mm spanner.
Page 10: Chimney
INSTALLATION INSTRUCTIONS ® Fig. 4. Vertical Register Plate With Bricked Up Fireplace CHIMNEY In order for the appliance to perform satisfactorily the chimney height Soot Door In Side or Rear must not be less than 4 metres measured vertically from the outlet of Of Chimney the stove to the top of the chimney.
Page 11: Connection To Flues
INSTALLATION INSTRUCTIONS ® Fig. 7. Horizontal Register Plate With Optional Fig. 8. Flue Blanking Plate. Vertical Rear Flue Connector Back of Stove Blanking Plate Inside back of Stove Alternative Clamping Plate Soot Door Positions M8 Nut Glass Fibre Webbing Blanking Plate Register Plate Clamping plate finishes With Soot Door...
Page 12: Pre Lighting Check
Clean Air Act requirements. location and positioning of the throat plate is shown in Fig. 3. The C-Four Blu, C-Five Blu, C-Six Blu, C-Seven Blu and C-Eight Blu Check that the front fence is fitted correctly and that the door closes have been recommended as suitable for use in smoke control areas properly.
Page 13: Certification
A.J WELLS & SONS LTD A.J WELLS & SONS LTD Bishops Way, Newport, Isle of Wight PO30 5WS, United Kingdom A Division of A.J.Wells & Sons Limited Registered in England No. 03809371 CE Certificate for compliance with EN13240:2001 EN13240:2001 C SERIES ROOMHEATERS FIRED BY SOLID FUEL C Four* C Six...
Page 14: C-Four Dimensions
C-FOUR DIMENSIONS (mm) ® Plan View 140 i/d to suit 125mm (5") Optional Vertical Rear Flue Adapter flue pipe 613 560 64 OD 61 ID 763 710 Front Side Rear...
Page 15: C-Five Dimensions
C-FIVE DIMENSIONS (mm) ® ® Plan View 140 i/d to suit 125mm (5") flue pipe Optional Vertical Rear Flue Adapter Front Side Rear...
Page 16: C-Six Dimensions
C-SIX DIMENSIONS (mm) ® Plan View 156 i/d to suit 150mm (6") flue pipe Optional Vertical Rear Flue Adapter Front Side Rear...
Page 17: C-Seven Dimensions
C-SEVEN DIMENSIONS (mm) ® Plan View 156 i/d to suit 150mm (6") flue pipe Optional Vertical Rear Flue Adapter 79 OD Front Side Rear...
Page 18: C-Eight Dimensions
C-EIGHT DIMENSIONS (mm) ® Plan View 156 i/d to suit 150mm (6") flue pipe Optional Vertical Rear Flue Adapter Front Side Rear...
Page 19: C-Four Parts Lists
C-FOUR PARTS LIST ® Issue B Optional Wood Ash Removal Kit These items are only used on models prior to serial no. 100417 Item Part No. Description Item Part No. Description 008/BR038 Rope Door Seal 008/BR013 Wooden Handle 008/FW29 Door Seal Adhesive 004/BR041 Airbox Cover 004/BR005...
Page 20: C-Five Parts Lists
C-FIVE PARTS LIST ® Issue D Optional Wood Ash Removal Kit These items are only used on models prior to serial no. 100623 excluding serial no. 100301 - 100305 Item Part No. Description Item Part No. Description 008/NR039 18mm Rope Door Seal (V2 Door) 008/BR013 Wooden Handle 008/NR038...
Page 21: C-Six Parts Lists
C-SIX PARTS LIST ® Issue C These items are only used on models prior to serial no. 100151 Item Part No. Description Item Part No. Description 008/PV21 Rope Door Seal 004/CR041 Airbox Cover 008/FW29 Door Seal Adhesive 004/BR016 Control Rod 006/PV19 Glass (Inc Seal) 008/AY37...
Page 22: C-Seven Parts Lists
C-SEVEN PARTS LIST ® Issue C Optional Wood Ash Removal Kit These items are only used on models prior to serial no. 100224 Item Part No. Description Item Part No. Description 008/ER003 Door Seal (10mm Dia) 004/CR041 AirBox Cover 008/ER038 Door Seal (18mm Dia) 004/ER016 Control Rod...
Page 23: C-Eight Parts Lists
C-EIGHT PARTS LIST ® Issue B Optional Wood Ash Removal Kit These items are only used on models prior to serial no. 100117 Item Part No. Description Item Part No. Description 004/CR041 Airbox Cover 008/DR038 Rope Door Seal (10mm Dia) 004/BR016 Control Rod 008/DR039...
Page 24 (EU)2015/1185 - (EU)2015/1186 Model identifier(s): Charnwood C-Four Blu Test laboratory: RRF Indirect heating functionality: No Notified body no: 1625 Direct heat output: 4.8(kW) Test report no: 40 15 3969-1 Indirect heat output: - (kW) Harmonized standard: EN 13240 TECHNICAL INFORMATION FOR SOLID FUEL LOCAL SPACE HEATERS...
Page 25 (EU)2015/1185 - (EU)2015/1186 Model identifier(s): Charnwood C-Five Blu Test laboratory: Cetiat Indirect heating functionality: No Notified body no: 1623 Direct heat output: 5(kW) Test report no: BOI 1414385-1 Indirect heat output: - (kW) Harmonized standard: EN 13240 TECHNICAL INFORMATION FOR SOLID FUEL LOCAL SPACE HEATERS...
Page 26 (EU)2015/1185 - (EU)2015/1186 Model identifier(s): Charnwood C-Six Blu Test laboratory: RRF Indirect heating functionality: No Notified body no: 1625 Direct heat output: 5.9(kW) Test report no: 40 15 411-2 Indirect heat output: - (kW) Harmonized standard: EN 13240 TECHNICAL INFORMATION FOR SOLID FUEL LOCAL SPACE HEATERS...
Page 27 (EU)2015/1185 - (EU)2015/1186 Model identifier(s): Charnwood C-Seven Blu Test laboratory: Cetiat Indirect heating functionality: No Notified body no: 1623 Direct heat output: 7.1(kW) Test report no: BOI 1414385-2 Indirect heat output: - (kW) Harmonized standard: EN 13240 TECHNICAL INFORMATION FOR SOLID FUEL LOCAL SPACE HEATERS...
Page 28 (EU)2015/1185 - (EU)2015/1186 Model identifier(s): Charnwood C-Eight Blu Test laboratory: RRF Indirect heating functionality: No Notified body no: 1625 Direct heat output: 8(kW) Test report no: 40 15 3886 Indirect heat output: - (kW) Harmonized standard: EN 13240 TECHNICAL INFORMATION FOR SOLID FUEL LOCAL SPACE HEATERS...
Page 29 y o u r p r e m i e r d e a l e r charnwood BISHOPS WAY, NEWPORT, ISLE OF WIGHT PO30 5WS, UNITED KINGDOM T : + 4 4 ( 0 ) 1 9 8 3 5 3 7 7 7 7 • F : + 4 4 ( 0 ) 1 9 8 3 5 3 7 7 8 8 • C O N T A C T U S A T W W W . C H A R N W O O D . C O M ®...
