Table of Contents
Summary of Contents for Dyno JL430B
-
Page 2: Table Of Contents
CONTENT SAFETY PRECAUTION ...................... 2. Machine Components........................3 Machine Installation ......................Open the machine package....................Install battery........................3.3 Install the brush/pad driver ..5 ....................3.4 Add cleaning water ......................4. Machine Operation ......................Check before operation....................Start the machine...................... -
Page 3: Safety Precaution
1.SAFETY PRECAUTION FETY PRECAUTION This machine is for commercial usage. It specializes in cleaning indoor floors, can not be used for other purposes. Please use our suggested scouring pads，brushes and use No Foam detergent only(When you use detergent,only No Foam is allowed). The following Safety warning symbol and “... - Page 4 4.Before leaving or maintain the machine: - Park the machine on smooth ground，p ower off the machine. - Set hand brake (if equipped ). 5.When repair the machine: - Do not move parts, do not wea r loo se sh i rt s or slee ves. - Disconnect the battery wiring before operating the machine.
-
Page 5: Machine Components
2.MACHINE COMPONENTS instructions SAFETY PRECAUTION (Fig. 1) Note: Electric Type Not With Battery... -
Page 6: Machine Installation
3.MACHINE INSTALLATION 3.1.Open the machine package 1 Carefully check whether there is damage on the packing box. If there is damage, please report to the carrier immediately 2.Check the list of freight contents, please contact the dealer if missing something. The standard s p a r e p a r t s of the machine: 2PCS* 52AH 24V Gel lead acid battery 1 PCS *24V 7AH charger... -
Page 7: Install The Brush/Pad Driver
. I f t u r n r i g h t s i d e , b r u s h w i l l m o v e o f f . 图7 Fig 5 Fig 6 3.4 Add Cleaning Water Add cleaning water in the cleaning tank Fig7, Fig8 Fig7 Fig8 Model JL430B Voltage Battery 52Ah *2pcs 12V Gel Battery Cleaning tank 5.81 gallon Recovery tank 6.6 gallon Brush 15inch ,381mm Squeegee dia. -
Page 8: Machine Operation
4.MACHINE OPERATION please do not operate the machine before you reading and understand this operation manual Check before operation: 1. Clean the garbage on the ground. 2. Check battery power meter. 3 . Check the abrasion of brush/pad driver / scouring pad. 4 . -
Page 9: During Machine Operation
machine operation For safety: when using the machine, please walk slowly and wear non-skid shoes. 1. Each wash path was overlapped by 5 cm. 2 . Keeping machine running continuously to avoid damage to the ground. 3 . If there is a drag mark on the ground after the water absorption, please wipe the tape with a rag to remove the garbage, and clean the area in advance to avoid the drag marks. -
Page 10: Battery Charging
6.BATTERY CHARGING The following charging instructions apply to the attached charger. Note: in order to extend the application life of the battery, please ensure that the battery is full charged every time before use. At least every 2months, machine need to be used finish the power (discharge all battery), then full charged it. -
Page 11: Maintenance Every Month
8.MAINTENANCE IN EVERY MONTH Monthly maintenance 1. Take off the solution tank filter from the machine and clean it (figure 23) Make sure empty the solution tank before you take o f f the filter. Check the top of battery to avoid electric corrosion. Check if battery connecting wires loosened Check and clean recovery tank cover (figure 24) replace it if broken. -
Page 12: The Replacement Of The Squeegee Rubber
10.THE REPLACEMENT OF THE SQUEEGEE R U B B E R Each squeegee lip has four blade edges, and when the strip is worn, only replace the two sides of the tape and use the other side of the intact scraper edge. If the four edges are worn, please replace the tape. -
Page 13: Troubleshooting
12.TROUBLESHOOTING Problem Reason Solution The ring is not pulled Pull start ring handle The battery is dead Charge the battery Machine can’ t be The battery failed Replace the battery operated Tighten the battery connection The cable is loose Replace the fuse The main fuse blew out The plug is not connected to the power Check plug connection... - Page 14 water strainer or solution tube is blocked Clean water strainer or solution tube Remove the valve to clean up Solution valve is blocked Little or no water Adjust flow control knob Flow control knob flow rate is low Adjust the knob , then lock the screw Loosen the screw of the control knob The sewage tank is full Drain sump...
