Schaefer WayCool WC-1/3HPA220OSC Evaporative Air Cooler 220 Volts
Schaefer WayCool WC-1/3HPA220 Evaporative Air Cooler 220 Volts
Schaefer WayCool WC-1/3HPAOSC Evaporative Air Cooler
Schaefer WayCool WC-1/3HPA Evaporative Air Cooler
WayCool® 1HP MFA Series
WC-1HPMFA
netzerotools.com
netzerotools.com
Portable Evaporative Cooler
USER'S MANUAL
WC-1HPMFAOSC
WCG-1HPMFA
netzerotools.com
WC-1HPMFA360
Advertisement
Table of Contents
Related Manuals for Schaefer WayCool 1HP MFA Series
Summary of Contents for Schaefer WayCool 1HP MFA Series
- Page 1 Schaefer WayCool WC-1/3HPA220OSC Evaporative Air Cooler 220 Volts Schaefer WayCool WC-1/3HPA220 Evaporative Air Cooler 220 Volts Schaefer WayCool WC-1/3HPAOSC Evaporative Air Cooler Schaefer WayCool WC-1/3HPA Evaporative Air Cooler Portable Evaporative Cooler WayCool® 1HP MFA Series USER'S MANUAL WC-1HPMFAOSC...
-
Page 2: Table Of Contents
This manual is designed to provide comprehensive planning, installation, safety, operation, maintenance, troubleshooting and parts information. If a problem should arise, or if replacement parts are needed, your Schaefer dealer can supply the necessary information to help you. Table of Contents INTRODUCTION ..........................3... -
Page 3: Introduction
netzerotools.com Introduction WHY USE EVAPORATIVE COOLERS IN YOUR WORKPLACE • The WayCool® evaporative cooler requires little space, has a low initial cost, is inexpensive and simple to operate and requires minimal scheduled maintenance. • Due to the design and construction of the cooling pads, cooling efficiency is normally maintained near optimum throughout the life of the pads (approximately two seasons). -
Page 4: About This Manual
netzerotools.com About This Manual The intent of this manual is to help you in two ways: to provide you with step-by-step instructions for quick and easy assembly of your product, and to serve as a reference for simple maintenance and questions you may have regarding your product. -
Page 5: Safety Recommendations
netzerotools.com Safety Recommendations READ AND SAVE THESE INSTRUCTIONS! This is an electric device with moving components. There is the possibility of fire, electric shock or injury to persons. Ensure all the safety recommendations are adhered to in order to minimize this risk. •... -
Page 6: Description
netzerotools.com Description The WayCool® evaporative cooler is a completely self-contained, portable unit capable of delivering 40 MPH velocity of air with a temperature drop of up to 20 degrees F. The unit is composed of: • Level-controlled water supply system •... -
Page 7: Water Supply System
netzerotools.com Water Supply System Actual WayCool® may vary slightly from unit shown here. Water Supply System The reservoir can be supplied continuously with an ordinary garden hose by attaching the supplied hose adapter to the fill connection, or it can be filled manually. With a continuous water supply connected, the float valve in the reservoir (like the one in your toilet tank) rises and falls with the water level. - Page 8 netzerotools.com Water Supply System cont'd A drain in the reservoir allows you to drain the unit for cleaning and maintenance. A drain cap on the underside of the aluminum tray covers the drain during operation. Make sure the cap is in place before you fill the reservoir.
-
Page 9: Cooling Pad Assembly
netzerotools.com Cooling Pad Assembly The cooling pads are critical for proper, efficient cooler operation. They are made of laminated cellulose (paper) fibers and arranged to give a large surface area for evaporation and to provide a rigid structure. The shape of the cells allows high velocity airflow through the pad at a minimum pressure drop. -
Page 10: Blower And Ductwork
netzerotools.com Blower and Ductwork Actual WayCool® may vary slightly from unit shown here. Fan Blower The WayCool® evaporative cooler uses a belt-driven, 1 HP electric motor to drive a centrifugal blower. The blower draws room air through the cooling pads and discharges the cooler air through the spout, displacing the warmer air with cooler air and decreasing the temperature. -
Page 11: Control
netzerotools.com Control The WayCool® control switch is mounted on the outside of one frame leg. It has the following positions: OFF power is off to the blower motor and the pump motor. LOW VENT the blower runs at low speed and the pump is OFF. HIGH VENT the blower runs at high speed and the pump is OFF. -
Page 12: Unpacking And Initial Setup
netzerotools.com Operation and Maintenance cont'd UNPACKING AND INITIAL SETUP The WayCool® is shipped upright in a corrugated container. The unit is fully assembled and ready for service except for thoroughly cleaning manufacturing dust from the cooling pads before running it for the first time. CAUTION Be careful when you move the unit while it is in the shipping container and when moving it around with the container removed. -
Page 13: Regular Cleaning
netzerotools.com Operation and Maintenance cont'd REGULAR CLEANING The frequency with which the WayCool® should be cleaned will depend on the environment in which it is used. The more dirty the environment the more often it will need cleaning. In most cases the WayCool® will need to be cleaned weekly. CAUTION The pads should be dry before you handle them, as they are stronger when dry than when they are wet and less susceptible to damage. -
Page 14: Troubleshooting
netzerotools.com Troubleshooting COOLING PADS NOT WETTING Ensure there is water in the reservoir. Ensure the motor switch is in the START position and the pump switch is in the ON position. Ensure the pump is running. Pump is running but no water: Ensure hose is connected. -
Page 15: Options And Accessories
netzerotools.com Options and Accessories Your WayCool® can be purchased with certain options and/or accessories, and some of these can be retrofitted after the initial purchase. Instructions are included with all equipment purchased separately. Options available at time of purchase only: •... -
Page 16: Oscillating Spout
netzerotools.com Options and Accessories cont'd OSCILLATING SPOUT Oscillator Switch The oscillating spout is operated by a four RPM gear motor that On/Off Switch delivers 50 in/lbs. of torque. As the gear motor rotates, the spout oscillates in a 110-degree arc, which cools an area of about 9500 square feet. -
Page 17: Warranty
Schaefer Ventilation Equipment, LLC Schaefer Limited Warranty Policy Schaefer Ventilation Equipment, LLC (SVE) provides the following limited warranty from the date of invoice to the initial purchaser of our products or to its customer with a dated proof of purchase: Two-year coverage (unless otherwise indicated below) applies to all products, components and assemblies provided by SVE that prove to be defective in material or workmanship. - Page 18 netzerotools.com netzerotools.com...
