Page 3: General
External Reference Clock is now available. New Settings window for Analysis Tab. Purpose The purpose of this document is to describe the use of the ADC demonstration board EV12AQ600. Scope This document provides a description of the ADC demonstration board hardware and GUI.
Page 4 Total Distortion TILD Total Interleaving Distortion All information given in this document is property of Fraunhofer IIS. The document may contain confidential information and page 4 of 22 is intended for use inside the addressed project only...
Page 5: Quick Start
Quick Start In this paragraph the first usage of the EV12AQ600 demonstration board is described step by step. In this example a 100 MHz sinus signal is digitized with ADC1 with 6 Gsps. Setup Hardware First the hardware has to be set up. An overview can be seen in Figure 1.
Page 6: Connect To Hardware
Connect to Hardware When the hardware is running the GUI can connect to the demoboard. 1. Run ev12aq600-gui.exe 2. Then connect to the board. Therefore fill in the host. a. Interface eth0 will always be set to DHCP, which means that it will get its IP address by a DHCP server in the local network b.
Page 7: Trigger And Analyze Snapshot
Figure 3: Trigger snapshot and analyze signal in the frequency domain This was a simple example to show the basic function of the EV12AQ600 demo board. A more detailed description of the hardware and the GUI can be found in the following paragraphs.
Page 8: Detailed Hardware Description
Detailed Hardware Description There exist two different versions of the ADC Demoboard. The v1 can be seen in Figure 4 and the v2 in Figure 5. Figure 4: detailed overview of the v1 ADC-Demoboard All information given in this document is property of Fraunhofer IIS. The document may contain confidential information and page 8 of 22 is intended for use inside the addressed project only...
Page 9: Difference V1 And V2
Figure 5: detailed overview of the v2 ADC-Demoboard Difference v1 and v2 The difference in between v1 and v2 is that v1 needs a SD-Card to work. This is not the case for v2. Here the operating system is stored inside a flash memory. The v2-Boards have also an additional button S1107.
Page 10: Rescue Procedure
Rescue Procedure This procedure is only working with v2 boards. It is needed when the connection to the ADC Demoboard can be no longer established. The procedure is as following: 1. Insert a rescue SD-Card into the ADC-Demoboard 2. Power on the ADC-Demoboard 3.
Page 11: Detailed Gui Description
Detailed GUI Description In this paragraph the menu bar and every tab of the GUI is described in detail. Menu Bar File: The current GUI-Configuration can be stored (Save Configuration) to be loaded later (Load Configuration). The loaded configuration is applied directly. Analysis: The current snapshot can be stored (Save Snapshot) or a snapshot can be loaded to be analyzed with the GUI (Load Snapshot).
Page 12: Functions
The Status-tab is the tab that opens automatically after the start of the GUI. It shows general information about the connected board. This includes temperatures, version information and hardware information. Just the temperature is updated automatically (every second). The rest has to be updated with the refresh button.
Page 13: Adc-Tab
ADC-Tab Figure 7: GUI ADC-Tab 4.3.1 Description The ADC-tab shows information about the ADCs. In this tab the settings for the ADCs can be viewed and changed for each ADC separately. The preset settings are the default values of the ADCs.
Page 14 4 Clock: Clock modes of the selected ADC according to the data sheet (refer to section 5.7 Clock Interleaving). 1: all cores interleaved 2: Clock coreA = coreB; clock coreC = coreD 3: Clock coreA = coreC; clock coreB = coreD 4: all cores clocked interleaved 5 Channel Mode: Configuration of ADC cross-point switch (refer to section 5.6 of datasheet).
Page 15: Board-Tab
13 Get Configuration: Load the ADC configuration and display it in the GUI. Board-Tab Figure 8: GUI Board-Tab 4.4.1 Description Board settings can be viewed and changed on the Board-Tab. 4.4.2 Function 1 Sample Clock: Select sampling clock for both ADCs 2 Clock Chaining: Enable clock chaining on ADCs (connect CLKOUT of ADC1 to CLK of ADC2).
Page 16: Sync-Tab
4 Set Configuration: Write the current configuration to the ADC. 5 Get Configuration: Load the ADC configuration and display it in the GUI. 6 Manual Ethernet: Changes made here only apply to Ethernet 1. If the manual Ethernet is deactivated DHCP for eth1 is active. Press Set Ethernet Settings to save changes and restart the board if IP address was changed (press Reboot-Button on Status Tab).
Page 17: Description
4.5.1 Description ADC synchronization can be viewed and changed on the Sync-Tab. 4.5.2 Function 1 Synchronization Configuration: • Forward synchronization signal from ADC1 to ADC2 (Sync Chaining): activate/deactivate sync-chaining (e.g. synchronization from ADC1 and ADC2) • Always synchronize ADCs on Trigger Snapshot: send always the sync-signal (reestablish the ESIstream-Connection) before a snapshot is triggered 2 ADC Sync Status: Shows whether ADCs are synchronized or not (ESIstream-Connection is established)
Page 18: Analysis-Tab
Analysis-Tab Figure 10: GUI Analysis-Tab 4.6.1 Description The Analysis-Tab shows information and settings about triggering and analyzing snapshots. ADC snapshots can be triggered, stored and analyzed here. 4.6.2 Function Device: Select ADC for which the snapshot will be triggered. • ADC1, •...
Page 19 o time: time domain plot o psd: power spectral density plot using Welch’s method o fft: frequency domain plot o histogram: probability density function of the signal over time • Unit: selection of x-axis scaling. Default setting is frequency domain, unit MHz. •...
Page 20 Zoom rectangle Plot settings Figure options (axis and curve settings) Save plot as image Analysis Log: Lists the detected peaks, harmonics and interleaving distortions. The measurement results base on those values. Measurement Results: The measurement results are calculated when a new snapshot is triggered or the settings are changed and applied.
Page 21: Log-Tab
Register 0x000B CSV-File (row adc-mode) one_channel_0 one_channel_3 two_channel_0AB two_channel_0CD four_channel Table 3: adc-mode register-value translation Load Snapshot: Load *.csv file to plot snapshot data and calculate the Measurement Results. Log-Tab Figure 11: GUI Log-Tab 4.7.1 Description The Log Tab provides a more detailed feedback about the GUI status. 4.7.2 Functions All information given in this document is property of Fraunhofer IIS.
Page 22 1 Current Logging Status: Choose which logs should be displayed. There are four different levels possible: Error: Just log error messages Warning: Log error messages and warnings Info: Log errors, warnings and additional information Debug: log everything including debugging information 2 Clear Log: Clear the Text in the Log Window.
