Sony SLV-N500 Service Manual

SERVICE MANUAL
5
ilf-[Fo
y
Photo: SLV-N700
RMT-V402B
SLV-N500/N700
MT-V402/V402B
US Model
Canadian Model
System
Format
VHS NTSC standard
Video recording system
Rotary head helical scanning FM system
Video heads
Double azimuth four heads
Video signal
NTSC color, EJA standards
Tape speed
SP: 33.35 mm/s (1 % inches/s)
EP: 11.12 mrv/s ( A 6 inches/s)
LP: 16.67 min/s ( Yio inches/s),
playback only
Maximum recording/playback time
8 hrs. in EP mode (with T- 160 tape)
Rewind time
Approx. | min (with T-120 tape)
Tuner section
Channe] coverage
VHF 2 to 13
UHF 14 to 69
CATV A-8 to A-1, A to W, W+l to W+84
Antenna
75-ohm antenna terminal for VHF/UHF
Inputs and outputs
LINE IN | and LINE-2 IN
VIDEO IN, phono jack (1 each)
Input signal: | Vp-p, 75 ohms, unbalanced, sync
negative
AUDIO IN, phono jacks (2 each)
Input Jevel: 327 mVrms
Input impedance: more than 47 kilohms
SPECIFICATIONS
LINE OUT
VIDEO OUT, phono jack (1)
Output signal: 1 Vp-p, 75 ohms, unbalanced, sync
negative
AUDIO OUT, phono jacks (2)
Standard output: 327 mVems
Load impedance: 47 kilohms
Output impedance: less than 10 kilohms
Timer section
Clock
Quartz locked
Timer indication
12-hour cycle
Timer setting
8 programs (max.)
General
Power requirements
120 V AC, 60 Hz
Power consumption
16W
Operating temperature
0°C to 45°C (32°F to 113°F)
Storage temperature
—20°C to 60°C (-4°F to 140°F)
Dimensions including projecting parts and controls
(w/h/d)
SLV-N700
Approx. 430 « 96 « 251 mm
(Approx. 17 * 3 2% 10 inches)
SLV-N500
Approx. 360 = 9§ x 250 mm
(Approx. 14 % x3 % «9 } inches)
Mass
SLV-N700
Approx. 2.8 kg (Approx. 6 Ib 3 oz)
SLV-N500
Approx. 2.6 kg (Approx. 5 Ib 12 oz)
Supplied accessories
Remote commander (1)
Size AA (R6) batteries (2)
75-ohm coaxial cable with F-type connectors (1)
Design and specifications are subject to change without
notice.
