1693 ES - Fix it yourself repair stand, with stainless steel
pump.
Instruction manual
Usage
1693E Fix-it-yourself bike stand is simple to use and compatible with all types and models of bicycles. We just simple
raise a bike, drive the seat post between the brackets of the stand and release the bike suspended freely. Service tools
are fastened to the stand with plasticized steel braided cables long enough to reach all parts of the bike. After the
service intervention has been completed, we raise the bike again, take it off the stand brackets and put it on the
ground. We check the tire pressure and cycle away satisfied.
Positioning
Fix-it-yourself bike stand is not free-standing. Stand has to be fastened on bedrock. The base of the stand has got four
holes which enable fastening on a concrete or any other hard surface with larger bolts. With safety precautions in
mind we advise against the use of stand without fastening to the ground.
Maintenance
Due to exposure to various weather conditions some parts of the stand (Tools + Pump) requires constant
maintenance.
Tools: We recommend oiling tools with Dry Lube (PTFE) at least once a month, if necessary several times a month. In
winter we recommend Wet Lube once a week.
Pump: We recommend lubricating Handle stick with Dry Lube or PTFE spray 1-2 times a month. In winter repeat the
process several times a month. Rubber seals wear out over time and must be replaced after some time.
Warranty
3 years anti corrosion warranty on all galvanized and powder coated parts of the stand. Warranty does not apply if
corrosion is caused by physical damage, also excluded are damages due to any form of vandalism.
Tools are treated under standard Unior warranty. Due to tools being exposed to different elements, corrosion on tools
are not covered by Unior warranty. To ensure the longevity of the tools, please follow regular maintenance
requirements. See paragraph above.
District Court of Celje, File No. 1/00248/00 • Share capital: 23.688.983, 48 EUR • Identification number: 5042437 •
V. A. T. Number: SI7246172 • Bank account No. SI56 0600 0002 5482 781 at Banka Celje d. d. • SWIFT SBCESI 2X •
Chairman of the Supervisory Board: Matej Golob Matzele.
cvbcccvb
Advertisement
Related Manuals for Unior 1693 ES
Summary of Contents for Unior 1693 ES
- Page 1 Tools are treated under standard Unior warranty. Due to tools being exposed to different elements, corrosion on tools are not covered by Unior warranty. To ensure the longevity of the tools, please follow regular maintenance requirements.
- Page 2 Warning: tools and stainless-steel pump are opened for public use and therefore used more than they would be under standard circumstances. Warranty does not apply for product wear. All maintenance is done by the owner of the stand, also all the cost related to maintenance and tool replacements is covered by the owner. Spare products Code Dim.
- Page 3 Pump maintenance and replacement To replace or maintain the pump, follow these steps: 1) With a drill, remove ten rivets – 6 from the side, 4 from the bottom, to separate the pump frame from the main frame. Use drill 4.2mm. (image 1) 2) Unscrew the bottom 4 screws to remove the metal plate under the pump (image 2) 3) Keeping the complete frame and pump upside down, pull the plastic part from the pump (image 3) 4) Remove the pump from the metal frame...
- Page 4 Image 2. Image 3. Image 4. Image 5.
