Alctron PS-2 Manual

The PS-2 is a 2-way selector footswitch that makes changing inputs and outputs easy. One stomp is all takes to
instantly switch between guitars or effectors setups, changing amps or switching between amp and tuner. 9V battery
provides stable performance voltage. Specially designed rubber bottom grips the floor and stays put while you play.
The heavy-duty spring allows for better control and playing longevity.
1
1.A/B: input/output connector, connects to guitars or guitar amps such similar devices.
2.IN/OUT: input/output connector, connects to guitars or guitar amps such similar devices.
3.LED indicators, when press the footswitch, if red LED lit it indicates taking A as input connector, IN/OUT as output
connector, or taking A as output connector, IN/OUT as input connector; if green LED lit it indicates taking B as input
connector, IN/OUT as output connector, or taking B as output connector, IN/OUT as input connector.
4.Removable door, 9V battery clip.
PS-2 Footswitch
CONNECTOR INTRODUCTION
2
4
爱克创
3
