- Page 1 ® FOOD SERVICE SYSTEMS · For NU–VU® Model: XO–1M Revised 21 February, 2011 MENOMINEE, MICHIGAN 49858 This page was created using BCL ALLPDF Converter trial software. To purchase, go to http://store.bcltechnologies.com/productcart/pc/instPrd.asp?idproduct=1...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ABOUT YOUR NU–VU® EQUIPMENT..... WARRANTY ............RECEIPT AND INSTALLATION......START–UP ............11 PROGRAMMING INSTRUCTIONS....15 OPERATING INSTRUCTIONS......16 MAINTENANCE AND CLEANING GUIDE ..20 SERVICE AND REPLACEMENT GUIDE..22 REPLACEMENT PARTS LIST ......27 ELECTRICAL SCHEMATICS ......29 NU–VU®... -
Page 3: About Your Nu-Vu® Equipment
XO–1M OWNER'S MANUAL ABOUT YOUR NU–VU® EQUIPMENT * ABOUT YOUR NU–VU® EQUIPMENT * NU–VU® as a product line has been in existence for over twenty-one years. Its units are in use throughout the United States and Canada and have been exported to other parts of the world. - Page 4 ABOUT YOUR NU–VU® EQUIPMENT XO–1M OWNER'S MANUAL The NU–VU® XO– series Ovens can also be used for: • Meats • Poultry • Seafood • Pizza • Vegetables • Casseroles • Potatoes • Food combinations • Hot dishes All Ovens of the XO– series are designed for the following: •...
- Page 5 Side Racks. Optional 4-Pan Side Racks are available for those who require increased shelf spacing to bake larger products. Both units measure 26½" wide, 24" deep (26½" with the Door Latch), and 21¼" high. The XO-1M unit takes up less than five square feet of table or counter space! NU–VU®...
-
Page 6: Warranty
THIS IS THE STANDARD WARRANTY THAT APPLIES TO ALL NU– VU® EQUIPMENT WITH THE FOLLOWING EXCEPTION: DUE TO THE SMALL SIZE THE XO–1M NU-VU® WILL NOT ALLOW THE CHARGING OF TRAVEL TIME BY A SERVICE AGENCY. IF YOUR XO–1M REQUIRES THE ATTENTION OF A SERVICE TECHNICIAN WE REQUEST THAT YOU TRANSPORT THE UNIT TO YOUR LOCAL APPROVED SERVICE AGENCY YOURSELF. - Page 7 XO–1M OWNER'S MANUAL NU–VU® EQUIPMENT WARRANTY LABOR - - We require that you call our NU–VU® Service Department at (906) 863-4401 for service authorization BEFORE you call any service agency if you wish to claim a labor expense under the warranty. We may be able to solve your problem over the telephone, or be able to recommend one or more capable and reliable service agencies in your area.
-
Page 8: Extended Warranty
NU–VU® EQUIPMENT WARRANTY XO–1M OWNER'S MANUAL EXTENDED WARRANTY: Available at an additional charge. Please ask for a quote depending upon warranty requested. WARRANTY LIMITATIONS: NU–VU®'s warranty for parts and labor is subject to the following limitations: • NU–VU® will pay for service under warranty if there is a defective component, but not for: ... -
Page 9: Receipt And Installation
XO–1M OWNER'S MANUAL RECEIPT AND INSTALLATION RECEIPT AND INSTALLATION RECEIPT: It is essential to inspect the unit immediately when it arrives. NU–VU® has placed instructions on the packaging to help avoid damage in transit. However, accidents or negligent handling can produce hidden damage. These steps should be followed: A. -
Page 10: Installation Procedures
RECEIPT AND INSTALLATION XO–1M OWNER'S MANUAL INSTALLATION PROCEDURES: Attach the Appliance Legs to the base of the unit if your Oven will sit on a table or counter. Legs are not necessary if the unit is to be fastened and sealed to the table or counter surface. Move the unit into the position where it is to be operated. - Page 11 XO–1M OWNER'S MANUAL RECEIPT AND INSTALLATION Refer to the illustration of the Power Terminal Block connections on page 8 and carefully follow these steps to safely complete the electrical portion of the Installation Procedure: A. Take note of the labeling on the terminal connections (Line 1, Line 2) at the Power Terminal Block.
- Page 12 RECEIPT AND INSTALLATION XO–1M OWNER'S MANUAL IMPORTANT: THIS UNIT REQUIRES A SCREEN OF AT LEAST 100 MESH TO BE INSTALLED IMMEDIATELY UPSTREAM OF ALL CHECK VALVE TYPE BACKFLOW PREVENTERS USED FOR WATER SUPPLY PROTECTION. THE SCREEN SHALL BE ACCESSIBLE AND REMOVABLE FOR CLEANING OR REPLACEMENT. Please follow these steps to connect an optional water supply to your unit: A.
-
Page 13: Start-Up
XO–1M OWNER'S MANUAL INITIAL START–UP INITIAL START–UP This START–UP procedure is used to verify that your unit has been installed correctly and will perform as intended when you put it into use. Please read completely through all the START–UP procedures before you begin. The installation of your NU–VU®... - Page 14 INITIAL START–UP XO–1M OWNER'S MANUAL B. Slowly open the Oven Door. The Micro Switch should turn the Oven Motor OFF as the Door is opened. Leave the Oven Door open. FOR THE INTERNAL STEAM OPTION - - Press and release the Steam Switch. The Water Solenoid Valve should open with an audible "click", allowing a controlled and timed water mist to be sprayed from the...
- Page 15 XO–1M OWNER'S MANUAL INITIAL START–UP only need a simple adjustment: Remove the Knob of the Temperature Control by pulling it straight out from the front of the unit. b. Hold the black Knob securely with the back of the clear plastic dial toward you.
- Page 16 INITIAL START–UP XO–1M OWNER'S MANUAL PROCEDURE: A. Make sure that all Controls and Switches are set to OFF and that the Oven Door is closed and latched. Engage the main electrical supply. B. Refer to the illustrations at right and on the following page.
-
Page 17: Programming Instructions
XO–1M OWNER'S MANUAL PROGRAMMING INSTRUCTIONS * PROGRAMMING INSTRUCTIONS * WATLOW PROGRAMMABLE CONTROL: Your NU–VU® XO–1P Programmable Oven is fully programmed when you receive it. The Menu panel lists selections for: • Breakfast • Lunch / Dinner • Special Breakfast • Special Lunch / Dinner •... -
Page 18: Operating Instructions
PROGRAMMING INSTRUCTIONS XO–1M OWNER'S MANUAL CAUTION: STAND AWAY FROM THE FRONT OF THE OVEN WHEN OPENING THE OVEN DOOR AFTER A COOKING CYCLE TO AVOID EXPOSURE TO ESCAPING HEAT AND STEAM!!! H. The display window will continue to count down on each Shelf that was loaded into the Oven as long as the appropriate Shelf Key was selected at the time of loading. - Page 19 XO–1M OWNER'S MANUAL OPERATING INSTRUCTIONS B. Check the recommended temperature for the product to be baked and set your Temperature Control accordingly. NOTE: At the beginning of each day you may want to pre-heat your Oven 25 higher than the required baking temperature. Since your Oven requires time to reach the proper operating temperature you should plan ahead so your Oven and product are ready at the same time.
- Page 20 OPERATING INSTRUCTIONS XO–1M OWNER'S MANUAL This XO–1M option uses a manually-operated Steam Switch to activate the Water Solenoid Valve and spray a fine 12 to 15 second water mist through the Water Injection Nozzles into the heated Oven chamber. This water mist flashes into steam and is circulated through-out the Oven cavity by the Blower Wheel.
- Page 21 XO–1M OWNER'S MANUAL OPERATING INSTRUCTIONS The Watlow Control is fully programmed when you receive it. The Menu panel lists selections for: • Breakfast • Lunch / Dinner • Special Breakfast • Special Lunch / Dinner • Late Breakfast • Late Lunch / Dinner •...
-
Page 22: Maintenance And Cleaning Guide
CLEANING GUIDE MAINTENANCE: NU-VU® equipment is designed to last for years of useful service. Careful consideration is given in selecting components for durability, performance and ease of maintenance. For example, the Oven Motor has sealed bearings and never needs to be lubricated. While NU- VU®... - Page 23 XO–1M OWNER'S MANUAL SERVICE AND REPLACEMENT GUIDE CLEANING: Your XO–1M should be cleaned daily and as soon as possible after a spill has occurred. It is essential to maintain a clean unit, especially if the public views the unit in your place of business.
-
Page 24: Service And Replacement Guide
* * * NOTE * * * NU-VU® has had very good results with a product called JIFFY CLEANER. For standard cleaning simply spray JIFFY on and wipe off. Heavily soiled areas may require a short period of soaking. - Page 25 XO–1M OWNER'S MANUAL SERVICE AND REPLACEMENT GUIDE TEMPERATURE CONTROL, How to Adjust: A. Place a reliable thermometer (or the thermocouple of a test instrument) on a pan in the center of the Oven. Turn the unit ON and set the Temperature Control [23] to its normal setting.
- Page 26 SERVICE AND REPLACEMENT GUIDE XO–1M OWNER'S MANUAL A. Loosen the two acorn nuts inside the Latch Cover with a _" wrench. Pull the Latch Cover straight out from the Door to remove it and then remove the acorn nuts. B. Open the Door and take careful notice of the adjustment plate position against the body of the Door Latch.
- Page 27 XO–1M OWNER'S MANUAL SERVICE AND REPLACEMENT GUIDE DOOR GASKET, How to Replace: Follow these instructions to correctly install your Door Gasket with minimal problems. Use the installation kit provided. If you have any problems or questions call NU–VU® at (906) 863–4401. Ask for the Service Department. A.
- Page 28 SERVICE AND REPLACEMENT GUIDE XO–1M OWNER'S MANUAL G. Seal the corner joints after the entire Gasket is properly fitted. Pull the joints apart only enough to put sealant on all the cut edges only. Allow the Gasket joint to come together. Smooth out any excess sealant to form a smooth surface on the face of the Gasket.
-
Page 29: Replacement Parts List
XO–1M OWNER'S MANUAL ELECTRICAL SCHEMATICS REPLACEMENT PARTS LIST XO–1M & XO–1P Reference # Description Replacement Part # ELECTRICAL COMPONENTS: 1 Power Terminal Block* ..................50-0237 2 Ground Lug......................50-0062 3 Contactor ....................... 66-2013 4 Motor ........................66-5596 5 Heating Element: 120v, 2000w....................60-0062-6 208v, 4000w....................60-0063-1 240v, 4000w....................60-0064-1... -
Page 30: Interior Components
REPLACEMENT PARTS LIST XO–1M OWNER'S MANUAL CONTROL COMPONENTS (XO–1P): 20 Power Switch .......................252-6001 21 Programmable Controls: XO-1PCS......................66-1020 XO-1P......................66-7012 Mini-Chef .......................66-7016 22 Control Sensors: Watlow......................252-3001 Mini-Chef .......................50-0634 INTERIOR COMPONENTS: 23 Motor Assy w/ Blower Wheel ................250-1003 24 Side Rack (5-pan): Left........................98-1024 Right .......................98-1028 Side Rack (4-pan): Left........................98-1027... -
Page 31: Electrical Schematics
XO–1M OWNER'S MANUAL ELECTRICAL SCHEMATICS NU–VU® FOOD SERVICE SYSTEMS MENOMINEE, MICHIGAN 49858 This page was created using BCL ALLPDF Converter trial software. (906) 863-4401 SALES FAX (906) 863-5889 • SERVICE FAX (906) 863-6322 page 29 To purchase, go to http://store.bcltechnologies.com/productcart/pc/instPrd.asp?idproduct=1... - Page 32 REPLACEMENT PARTS LIST XO–1M OWNER'S MANUAL NU–VU® FOOD SERVICE SYSTEMS MENOMINEE, MICHIGAN 49858 This page was created using BCL ALLPDF Converter trial software. page 30 SALES FAX (906) 863-5889 • SERVICE FAX (906) 863-6322 (906) 863-4401 To purchase, go to http://store.bcltechnologies.com/productcart/pc/instPrd.asp?idproduct=1...
