Summary of Contents for Segway Xyber BAT-UPG-Package
- Page 1 Segway Xyber BAT-UPG-Package User Manual...
-
Page 2: Table Of Contents
Contents 1. List of products and accessories........................... 1 2. Assembly..................................2 3. Product information ..............................9 4. Trademarks and legal notices ..........................9 5. After-sales services..............................9... -
Page 3: List Of Products And Accessories
1. List of products and accessories Battery x 1 Battery strap x 1 Dual battery discharge harness x 1 Battery base x 1 Battery fixing plate x 1 Dual charging expansion cable x 1 Hexagon socket countersunk Hexagon socket button Battery lock insert x 4 head screw x 4 head screw x 4... -
Page 4: Assembly
2. Assembly 1. Loosen the bolts and remove the left cover 2. Loosen the battery fixing strap and remove plate; the battery plug;... - Page 5 3. Turn the key, unlock the battery anti-theft 4. Loosen the 3 screws and remove the lock, and remove the battery; decorating plate; 5. Remove the rubber plugs on the left and 6. Loosen the 6 screws on the front panel; right sides of the plastic part;...
- Page 6 7. Remove the 2 plastic parts; 8. Remove the plastic parts on the controller; 9. Loosen the screw, remove the connector, 10. Fix the dual battery discharge harness with and remove the wire; screws and connect the connectors;...
- Page 7 11. Fasten the plastic parts on the controller; 12. Arrange the dual battery discharge harness; 13. Install the plastic parts and fix them with 14. Fasten the plastic parts; screws;...
- Page 8 15. Install the rubber plugs on the left and right 16. Remove the rubber plug on the bottom of sides of the plastic part; the battery; 17. Take out the battery lock insert from the 18. Install the battery base on the bottom of the accessory package, and install it on the bottom battery, and fix it with the hexagon socket of the battery;...
- Page 9 19. Install the battery fixing plate and fix it with 20. Install the assembled battery components, the hexagon socket countersunk head screw insert the power plug and fix it with a battery taken out from the accessory package; strap; 21. Install the second battery, insert the power 22.
- Page 10 23. Install the left cover plate, fix it with screws, 24. Use a dual charging extension cable to and put the cover plate in place; charge the two batteries.
-
Page 11: Product Information
Black 4. Trademark statement Segway Xyber and the Segway logo featuring a flying man are trademarks of Segway Inc. Other trademarks mentioned herein are trademarks of their respective owners. Due to product updates, the product described in this user manual may differ from the product you actually purchased in color, appearance, etc. - Page 13 Black 4. Trademark statement Segway Xyber and the Segway logo featuring a flying man are trademarks of Segway Inc. Other trademarks mentioned herein are trademarks of their respective owners. Due to product updates, the product described in this user manual may differ from the product you actually purchased in color, appearance, etc.
