- Page 1 User Manual GM7ZG0P GM7ZG7P GM7ZQ7P GM7ZG8P GM7NG0P GM7NG7P GM7NG8P GM7NQ7P...
-
Page 2: Notice
Notice The information in this user’s manual is protected by copyright laws, all parts of this manual, including the products and software described in it, can not be reproduced, transmitted, transcribed, stored in a retrieval system, nor translated into any language. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL... -
Page 3: Table Of Contents
TABLE OF CONTENTS Notice ...................... 2 Preface ....................5 1.1 Regulations Information..............6 1.2 Safety Instructions ................10 1.3 Conventions for this Manual .............11 1.4 Release History ................12 Getting to know the basics ..............13 2.1 Product Specification............... 14 2.2 Preparing your Computer ............... - Page 4 4.1 About BIOS Setup ................35 4.1.1 When to Use BIOS Setup ?............35 4.1.2 How to Run BIOS Setup ?............35 4.2 BIOS Setup Menu................37 4.2.1 Main Menu..................38 4.2.2 Advanced Menu ................40 4.2.3 Security Menu................42 4.2.4 Boot Menu ..................
-
Page 5: Preface
Chapter 1 Preface English Notebook Manual... -
Page 6: Regulations Information
1.1 Regulations Information CE compliance ¤ This device is classed as a technical information equipment (ITE) in class B and is intended for use in living room and office. The CE-mark approves the conformity by the EU-guidelines: - EMC Directive 2014/30/EU, - Low Voltage Directive 2014/35/EU(equals A2 : 2013) , - RF Directive 2014/53/EU SAR/DAS refers to the rate at which the body absorbs RF... - Page 7 Rechargeable Battery Notice Do not 1. Throw into fire or a hot oven, or mechanically crush or cutting of a BATTERY 2.Throw or immerse into water 3.Heat to more than 60°C 4.Repaire or disassemble 5.Leave in an extremely low air pressure environment 6.Leave in an extremely high-temperature environment A power cord is connected to a socket-outlet with earthing connection.
-
Page 8: Fcc Information
FCC Information FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 9: Rf Exposure Information (Sar)
RF Exposure Information(SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Commu- nications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. -
Page 10: Safety Instructions
1.2 Safety Instructions Do not apply heavy pressure to the computer or subject it to any form of strong impact as this can damage the computer's components or otherwise cause it to malfunction. Never cover or block the air vents including those located at the base of the computer. -
Page 11: Conventions For This Manual
1.3 Conventions for this Manual CAUTION : This message contains important information that must be followed for safe operation. NOTE : This message contains information for special situations. English Notebook Manual... -
Page 12: Release History
1.4 Release History Version Date Revision Initial release 12/2020 English Notebook Manual... -
Page 13: Getting To Know The Basics
Chapter 2 Getting to know the basics English Notebook Manual... -
Page 14: Product Specification
Dimension 394.0*260.8*20.0mm 2.3 kg +/- 5% ・CPU / APU Support Processor AMD Cezanne H series R5 R7 (GM7ZG0P) AMD Cezanne H series R5 R7 R9 AMD Renoir H series (GM7NG0P) ・GPU Support Processor NVIDIA GN20-E3,192bits (GM7ZG0P) NVIDIA GN20-E5,256bits (GM7ZG7P) - Page 15 ・I/O Port DC-in USB Type A @Right side x2: USB 3.1 (Gen1) X2 (Power off mode support USB power, but w/o bc1.2 protocol ) USB Type A @Left side x1: USB 3,1 (Gen2) X1 (Power off mode support USB power, but w/o bc1.2 protocol ) USB Type C x1 @Rear side x1 USB 3.1 Gen2 + DP (Power off mode support USB power,...
-
Page 16: Communication Port
・Display 17.3" FHD, 16:9 FHD, 1920x1080 /QHD, 2560x1440 ・Webcam Infrared capability for facial reconition camera IR Camera w/ D-MIC*2 ・Communication Port *RTL8125BG *Supports 10/100/1000/2500 Mb/sec *PCIE interface *Power Down Mode D1~D3 support *PCIE ASPM L1.1, L1.2 support *UI for network package management ... - Page 17 ・Input Keyboard Membrane KB(333X104mm) travel=1.4mm backlight = 4zone RGB(NEW) Pointing Device TDA3072 Outline: 130.0*72.5mm +/- 0.15mm Glass like Enable/Disable area :10mmx10mm Palm Rejection:Support ・Power AC Adapter Gaming sku: Automatics Voltage adjustment between 100 and 240VAC 50/60Hz, 230 Watts(19.5V/11.8A), 3 Pins ...
-
Page 18: Preparing Your Computer
2.2 Preparing your Computer Connect the AC adapter’s DC output plug to the DC IN jack. The display panel can be opened to a wide range of angles for optimal viewing. Press the power button to turn on your notebook computer. English Notebook Manual... -
Page 19: Product Overview
2.3 Product Overview Please become familiar with each component before you operate the computer. Top-Open View NOTE: The product’s color/ LED color, I/O port, indicator location, and specifi- cation will depend upon the actually shipping product. English Notebook Manual... - Page 20 Camera Status LED The Camera Status LED shows the Camera status. Camera A device that allows you to record video or take photographs with your computer. Infrared capability for facial reconition camera can be used to identify and authenticate user to unlock notebook, conduct payment and other security functions.
- Page 21 Power Button Press this button to turn the computer's power on or off. Power ON: White Suspend: Blinking White Power Off: OFF Turbo / Game / Office Mode Switch On screen display Turbo mode ：Both White (Bright) Game mode： White (Faint light) Office mode：...
-
Page 22: Right Side View
Right Side View Card Reader Insert Memory Card. USB3.0 Interface -Support Micro SD /SDHC/SDXC card -SDCard support up to UHS-I USB Port Connects an USB device (such as USB Zip drive, keyboard or mouse) into this jack. With charging function. Vents The thermal vents are designed to cool the internal components and avoid overheating. -
Page 23: Left Side View
Left Side View Kensington® Lock Port To be secured using Kensington® Lock Port security products. Vents The thermal vents are designed to cool the internal components and avoid overheating. USB Port Connects an USB device. (such as USB Zip drive, keyboard or mouse) into this jack. Mic In Jack Connects amplified speakers, headphones or microphone into this jack. -
Page 24: Bottom Side View
Bottom Side View NOTE : The product’s thermal vent will depend upon the actually shipping product. Vents The thermal vents are designed to cool the internal components and avoid overheating. Speaker CAUTION: To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. - Page 25 Compartment View NOTE: Specification will depend upon the actually shipping product. SSD(Option) DD(Option) BATTERY (Option) eserved space If need to upgrade Please contact technical support and after-sales service . English Notebook Manual...
-
Page 26: Front Side View
Front Side View Light bar Smart lighting color control of Light Bar. English Notebook Manual... -
Page 27: Back Side View
Back Side View Vents The thermal vents are designed to cool the internal components and avoid overheating. USB Type C Port USB Type C / DP / USB Power Delivery HDMI port Connected to the screen, or home theater system. Network Jack This jack lets you connect to a LAN. -
Page 28: Getting Started
Chapter 3 Getting started English Notebook Manual... -
Page 29: Ac Adapter
3.1 AC Adapter Please be noted that it is strongly recommended to connect the AC adapter and use the AC power while using this notebook for the first time. When the AC adapter is connected, the battery is being charged immediately. Attach the AC adapter when you need to charge the battery or you want to operate from AC power. -
Page 30: Knowing The Keyboard
Knowing the Keyboard The following defines the colored hot keys on the Keyboard. The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. NOTE: The number of keys available on your keyboard will depend on the country/region in which the keyboard was designed and built. -
Page 31: For Keyboard Users
3.2.1 For keyboard users To activate these functions, press the hot key associated with the desired function as below : Function Keys Keypad Function Description Press this key combination (Fn+F1) Suspend: to enter sleep mode. Windows Press this key combination (Fn+F2) Windows to turn Lock/On . - Page 32 Function Keys Keypad Function Description Keyboard Press this key combination (Fn+F6) Brightness Keyboard to decrease brightness of down: Keyboard Press this key combination (Fn+F7) Brightness Keyboard. to increase brightness of Press this key combination (Fn+F8) MUTE: to enter MUTE mode. Press this key combination (Fn+F9) Volume to enter Volume down mode.
- Page 33 Function Keys For a full list of Windows keyboard Search shortcuts, please visit the Microsoft Charm : (Optional) official website https://support.microsoft.com/en-us/ English Notebook Manual...
-
Page 34: Using The Touchpad / Clickpad
3.3 Using the touchpad / clickpad The touchpad / clickpad is a rectangular electronic panel located just below your keyboard. Click twice left corner will open or close (Green light) touchpad functionality.You can use the static-sensitive panel of the touchpad / clickpad and slide it to move the cursor. You can use the buttons below the touchpad as left and right mouse buttons. -
Page 35: Bios Setup
Chapter 4 BIOS setup English Notebook Manual... -
Page 36: When To Use Bios Setup
4.1 About BIOS Setup 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・An error message appears on the screen during the system booting up and is requested to run SETUP. ・You want to change the default settings for customized features. -
Page 37: Bios Setup Menu
4.2 BIOS Setup Menu Once you enter the BIOS Setup Utility, the Main Menu will appear on the screen. Select the tags to enter the other menus. Main Menu Show system overview about memory size and setting of system time and date. Advanced Menu To select the XD feature enable or disable XD feature only work with Intel platform + Windows. -
Page 38: Main Menu
4.2.1 Main Menu ・System Time This item allows you to set the system time. There is a small internal (CMOS) battery which is designed to maintain your system clock. It is designed to maintain time even when the PC is powered down or in sleep mode. The time format is [hour:minute:second]. - Page 39 Day of the week, from Sun to Sat, which is determined by BIOS (read-only). The month from 01 (January) to 12 Month (Month) (December). Date (Date) The date from 01 to 31. Year (Year) The year can be adjusted by users. ・Total Memory This allows you to see the total amount of memory.
-
Page 40: Advanced Menu
4.2.2 Advanced Menu • Wake on LAN/WLAN Enable/Disable from Modern Standby(S0i3) with LAN/WLAN Device • NVMe RAID mode NVMe RAID to optimize performance. English Notebook Manual... - Page 41 • Serial ATA HDD It will show AHCI SATA HDD info. •NVMe Device It will show NVMe Device info. • Light Bar Effect Select Light Bar mode when power on. •Operating Mode Operating Mode includes the Fan Speed and CPU power level setting to optimize overall performance and heat dissipation •Display Mode Select the System Display Mode MSHybrid or dGPU only.
-
Page 42: Security Menu
4.2.3 Security Menu ・Change Administrator Password When this item is selected, a message box shall appear on the screen as below: Enter New Password Type a maximum of 20-digit password and press [Enter]. The password typed now will replace any previously set password from CMOS memory. - Page 43 Select Change User Password to give or to abandon password setting same as Change Administrator Password item above. Note that Administrator Password field allows users to enter and change the settings of the BIOS SETUP UTILITY, while User Password field only allows users to enter the BIOS SETUP UTILITY without having the authorization to make any change.
-
Page 44: Boot Menu
4.2.4 Boot Menu ・Boot Configuration Configure Settings during System Boot. ・LAN Remote Boot [Disable]: Boot from LAN or not. ・Set Boot Priority (1st/2nd/3rd/..Boot) Specifies the boot sequence from the available devices. A device enclosed in parenthesis has been disabled in the corresponding type menu. -
Page 45: Exit Menu
4.2.5 Exit Menu ・Save Changes and Reset Exit system setup after saving the changes.F4 key can be used for this operation. ・Discard Changes and Exit Exit system setup without saving any changes. ESC key can be used for this operation. ・Restore Defaults Restore/Load Defaults values for all the setup options.
