INSTALLATION AND SERVICE MANUAL
For Installation of Light Linear VT 5,6 Post top.
Model. VT-20021,VT-20022,VT-20023 and VT-20024
Product drawing (dimensions)
IP65 CLASS I IK07
VT-20021,VT-20022
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
Technical amendments and modifications techniques reserved.
L i g m a n L i g h t i n g
Europe Headquarters
Ligman Europe s.r.o.
VGP Park Usti nad Labem, P 2
Prestanov 113
403 17 Prestanov
Czech Republic
Tel. +420 608 740 504
sales.cz@ligman.com
|
www.ligman.com
VT-20023,VT-20024
MOUNTING DETAIL
1
20
30
6
CABLE SIZE : 3x1.0mm
Thailand Headquarters
Ligman Lighting Co., Ltd.
17/2 Moo 4, Monthong, Bangnampreaw
Chachoengsao 24150 Thailand
Tel : +66 (2) 7339140
info@ligman.com
M VT-20021/07/12/17/REV.0
1/2
2.5
Torque:3.0Nm.
TOOL
2
²
3
N
L
Torque:0.25Nm.
Push
4
5
Torque:3.0Nm.
Ligman Ltd
Regus House, Victory Way
Crossways Business Park
Dartford DA2 6QD
Tel. 0800 975 0622
sales.uk@ligman.com
FM-TS-13-1/13-03-2561/REV.4
