SERVICE MANUAL
Ver 1.0 2003.03
• DAV-S888 are composed of following models.
As service manuals are issued for each component model,
please refer to them.
COMPONENT MODEL NAME
SACD/DVD RECEIVER
FRONT SPEAKER
CENTER SPEAKER
REAR SPEAKER
SUB WOOFER
PACKAGE SPEAKER
SPECIFICATIONS
General
Power requirements
European models:
220 – 240 V AC, 50/60 Hz
Power consumption
120 W (120 V AC) 120 W (230 V AC)
1
W (120 V AC) 2 W (230 V AC)
(at the Power Saving Mode)
Power requirements
(Subwoofer)
European models:
220 – 230 V AC, 50/60 Hz
Power consumption
(Subwoofer)
90 W (1 W in standby mode)
×
×
Dimensions (approx.) 355
60
323 mm (14
incl. projecting parts
Mass (approx.)
3.8 kg (8 lb 7 oz)
Operating temperature 5˚C to 35˚C (41˚F to 95˚F)
Operating humidity
5 % to 90 %
• Speakers (5)
Supplied accessories
• Subwoofer (1)
• AM loop antenna (1)
• FM wire antenna (1)
• Speaker cords (5m
• Subwoofer cord (3.5m) (11ft. 5
• Video cord (1)
• Remote Commander (remote) RM-SS880 (1)
• R6 (size AA) batteries (2)
• Speakers-connection and Installation (card) (1)
• 21-pin Adapter (1) (Only for the European models)
Design and specifications are subject to change without notice.
Sony Corporation
9-877-204-01
2003C1600-1
Home Audio Company
C 2003.03
Published by Sony Engineering Corporation.
DAV-S888
HCD-S888
SS-TS551
SS-CT551
SS-CT551
SA-WS888
SA-SS888
×
×
2
3
/
12
3
/
inches) (w/h/d)
8
4
×
×
×
×
3, 15m
2) (17ft.
3, 50ft.
2)
7
/
in.) (1)
8
DAV-S888
PARTS LIST
Part No.
Description
1-477-370-13 COMMANDER, STANDARD (RM-SS880)
1-754-060-13 ANTENNA (FM)
1-754-149-11 LOOP ANT (AM)
1-769-108-11 CORD, CONNECTION (VIDEO CORD)
1-770-783-21 CONNECTOR, CONVERSION
1-824-180-11 CORD, CONNECTION (21PIN ADAPTOR) (AEP)
1-824-622-11 CORD (WITH CONNECTOR) (RED)
1-824-622-21 CORD (WITH CONNECTOR) (PURPLE)
1-824-622-31 CORD (WITH CONNECTOR) (WHITE)
1-824-622-41 CORD (WITH CONNECTOR) (GRAY)
1-824-622-51 CORD (WITH CONNECTOR) (BLUE)
1-824-622-61 CORD (WITH CONNECTOR) (GREEN)
4-243-416-01 BATTERY COVER (for RM-SS880)
4-243-457-01 RUBBER (SPEAKER) (for SPEAKER)
4-246-867-11 MANUAL, INSTRUCTION (ENGLISH)
4-246-867-21 MANUAL, INSTRUCTION (FRENCH)(AEP)
4-246-867-31 MANUAL, INSTRUCTION
COMPACT AV SYSTEM
AEP Model
UK Model
Remark
(for FRONT R SPEAKER)
(for SUB WOOFER)
(for FRONT L SPEAKER)
(for REAR R SPEAKER)
(for REAR L SPEAKER)
(for CENTER SPEAKER)
(GERMAN,SPANISH,DATCH,SWEDISH,
ITALIAN,PORTGUESE) (AEP)
