Potter UD-2000 Installation Manual

INSTALLATION MANUAL: UD-2000 DIGITAL ALARM COMMUNICATOR
NOTICE TO THE INSTALLER
This manual provides an overview and the installation instructions for the UD-2000 module.
All terminals are power limited and should be wired in accordance with the requirements of NFPA 70 (NEC) and NFPA
72 (National Fire Alarm Code). Failure to follow the wiring diagrams in the following pages will cause the system to not
operate as intended. For further information, refer to the control panel installation instructions.
The module shall only be installed with listed control panels. Refer to the control panel installation manual for proper
system operation.
1. DESCRIPTION
The UD-2000 Digital Alarm Communicator Transmitter (DACT) provides for up to two (2) phone lines for communication
to a monitoring station. The UD-2000 DACT communicates using the SIA-DCS or Ademco Contact ID protocols. When
enabled, the DACT automatically monitors each phone line or voltage and has the ability to seize the line and connect
with a remote receiver. Once the communication is complete, the DACT will hang up the phone line.
The DACT is provided with terminal blocks for each phone line. In order for the DACT to work properly, it must be installed
on a plain old telephone service (POTS) or equivalent as deemed by the authority having jurisdiction. The DACT must be
installed before any other equipment to ensure it can seize the line and disconnect any other lines.
Phone lines are high voltage and should be run in a separate conduit from other circuits. The wire conductors connecting
the DACT to the phone system should be 26 AWG or larger.
When the phone lines are connected to the control panel, the phone lines are supervised. The phone line are non-power
limited and should be routed accordingly.
UD-2000 comes factory addressed as address 1
To comply with UL 864 10th Edition, an alternate source of communication shall be used as the secondary means of
communications and shall not be a phone line.
Before connecting a device to the RS-485, take the following precautions to prevent potential damage to the RS-485
connection or P-Link or device.
•
Power to the UD-2000 connection is removed.
•
Field wiring on module is correctly installed.
•
Field wiring has no open or short circuits.
2. TECHNICAL SPECIFICATIONS
Standby Current
Alarm Current
Operating Temperature Range
Operating Humidity Range
Max no. of UD-2000 Expanders
Dimensions (WxHxD)
3. INSTALLATION
The UD-2000 is connected to the fire control panels using the provided four-wire cable connection (P/N 5210514)
between P4 and UD-2000 P1. The connection is power limited and supervised. The UD-2000 must be mounted in the
control panel cabinet. The wiring diagrams shown below illustrate where to connect. The connection is power limited and
supervised.
Potter Electric Signal Company, LLC
.
16 mA
23 mA
32° to 120°F (0° to 49° C)
10%-93% (non-condensing)
31
4" x 6" x 1 5/8"
•
St. Louis, MO
5406324-REV A 6/18
firealarmresources.com
•
Phone: 800-325-3936
•
www.pottersignal.com
PAGE 1 OF 3
