We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance's aesthetic and functional qualities. For further information on the product: www.smeg.com
Apple, App Store and iOS are trademarks of Apple Inc.
Google Play Store and Android are trademarks of Google Inc.
Wi-Fi is a trademark of Wi-Fi Alliance.
PRECAUTIONS
General safety instructions
Risk of personal injury
• Keep children under the age of
8 at a safe distance unless they
are constantly supervised.
• This appliance may be used by
children aged at least 8 and by
people of reduced physical,
sensory or mental capacity, or
lacking in experience in the use
of electrical appliances,
provided that they are
supervised or instructed by
adults who are responsible for
22 - PRECAUTIONS
22
22
26
26
27
27
27
27
27
27
27
27
28
28
28
28
29
their safety.
• This appliance is not suitable
for use by persons (including
children) with reduced
physical, sensory or mental
capacity, or by those without
experience or knowledge,
unless they are supervised or
instructed on the use of the
appliance by a person
responsible for their safety.
• Children must be supervised to
ensure that they do not play
with the appliance.
• According to current
29
29
29
29
30
31
33
33
35
35
35
36
36
36
36
37
38
39
91477B592/A
Advertisement
Related Manuals for Smeg CVI120B3E
Summary of Contents for Smeg CVI120B3E
-
Page 1: Table Of Contents
Mounting (mm) We advise you to read this manual carefully, which contains all the instructions for maintaining the appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com Apple, App Store and iOS are trademarks of Apple Inc. - Page 2 regulations, children between 3 technician from Technical and 8 years of age can take or Support Service. load food from the appliance, • DO NOT USE OR STORE but it is highly discouraged to FLAMMABLE MATERIALS allow children under 8 years of NEAR THE APPLIANCE.
- Page 3 • Take care that no objects are • Always unplug the appliance in stuck in the doors. the event of a fault or when • Do not store inflammable, performing cleaning or explosive or volatile substances maintenance. (e.g. spray bottles with •...
- Page 4 • Keep the ventilation openings installed on a pedestal. surrounding the appliance or in • Position the appliance into the the nearby area free from any cabinet cut-out with the help of obstructions. a second person. • Do not damage the cooling •...
-
Page 5: Appliance Purpose
is installed or a switch must be door open to prevent the incorporated in the fixed system development of mould inside. in compliance with installation • This appliance can be used up regulations. to a maximum altitude of 2,000 • CAUTION: while positioning metres above sea level. -
Page 6: Manufacturer's Liability
Manufacturer’s liability The appliance does not contain substances in quantities sufficient to be considered hazardous The manufacturer declines all liability for to health and the environment, in accordance damage to persons or property caused by: with current European directives. • use of the appliance other than that specified;... -
Page 7: How To Read The User Manual
How to read the user manual service. This user manual uses the following reading conventions: Warning/Caution Information/Advice • This appliance contains light sources of efficiency class "A". DESCRIPTION General description 1 Control panel 4 Upper removable shelf 2 Interior lighting 5 Central removable shelf 3 Activated charcoal filter 6 Lower shelf... -
Page 8: Description Of Parts
Smeg Connect (on some models only) Interior lighting The appliance is equipped with the Smeg The appliance’s interior lighting comes on: Connect technology so that the user can control • with light pressure in the upper area of the its operation through an App on his smartphone door. -
Page 9: Using The Control Panel
To activate the device, press at the top of the To deactivate manual ventilation: door against the opening direction. press the fan key again. The door will open a few centimetres and from Control lock there you can grasp it to open it completely. This function prevents the appliance Using the control panel functions from being accidentally... -
Page 10: Using The Wine Cellar Compartments
Temperature format (on some models only) bottles. Allows you to set the temperature scale to degrees Celsius (°C) or degrees Fahrenheit (°F). To change the temperature display format: 1. if necessary (on some models only), press the ON/OFF key to activate the control panel. - Page 11 The number of bottles that can be accommodated per shelf Bordeaux-type Alsace-type champagne-type number of bott- number of bott- number of bott- Shelf mode mode mode 5 + 4* all facing in the same direction with the cork toward the door. 4* The bottles should be placed in the second row.
-
Page 12: Alarms
4. Replace the filter cap following the than the previous one is set; • if the wine cellar is loaded with many bottles indications in points 1 and 2. at ambient temperature; Replacement filters can be ordered • in the event of an extended interruption in from Authorised Service Centres. - Page 13 temperature between 10°C and 14°C. sparkling wines are suitable for lower temperatures, even down to 8°C, while those Young, fresh, aromatic white wines can be with a slightly higher tannin content require served at a temperature as low as 10°C, while temperatures as high as 14°C.
-
Page 14: Cleaning And Maintenance
Type of wine Temp. (°C) Young whites 10 - 12 Mature whites 12 - 14 Young, light rosés 10 - 12 Mature, full-bodied rosés 12 - 14 Nouveau reds 10 - 14 Young, light reds with low tannin 14 - 16 Mature, full-bodied reds with high 16 - 18 tannin... -
Page 15: What To Do If
2. Pull the shelf out. • Make sure that the appliance is plugged in and that the main switch is turned on. The compressor starts to function too often or functions continuously: • The room temperature is too high. • The door is being opened too often or for too long. -
Page 16: Reverse The Door Opening Direction (On Some Models Only)
3. cover the screws with the supplied bushings. Class Room temperature SN-T + 10°C to + 43°C SN = Subnormal - N = Normal ST = Subtropical - T = Tropical • Locate the appliance at least 3 cm away from electrical or gas cookers and at least 30 cm away from combustion heaters or radiators. -
Page 17: Appliance Overall Dimensions (Mm)
4. remove the hinge block fixing screws from Appliance overall dimensions (mm) the door. 5. reposition the hinges on the other side by reversing their direction. The upper right hinge (A) will become the lower left hinge. The lower right hinge (B) will become the upper left hinge. -
Page 18: Mounting (Mm)
Mounting (mm) Do not cover the ventilation holes. 91477B592/A INSTALLATION - 39...
