Falcon SSGB-1S40-5U Owner's Operating Manual

5u rackmount 40ah extended battery bank with internal charger
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S
OPERATING
MANUAL
5U Rackmount 40AH Extended Battery Bank with Internal Charger
Models: SSGB-1S40-5U
SSGB-1S40-5U-2
FALCON
®
Electric Inc., 5116 Azusa Canyon Rd., Irwindale, California 91706, (626) 962-7770, Fax 626-962-7720, Email: sales@falconups.com
2017 Falcon
®
Electric Inc. All rights reserved.
All other brand names and trademarks are the property of their respective owners.
The information stated in this document is subject to change without notice. 2017-07-20
®
Falcon
and Falcon® Electric are registered trademarks of Falcon Electric Inc

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSGB-1S40-5U and is the answer not in the manual?

Questions and answers

Related Manuals for Falcon SSGB-1S40-5U

Summary of Contents for Falcon SSGB-1S40-5U

  • Page 1 Electric Inc. All rights reserved. All other brand names and trademarks are the property of their respective owners. The information stated in this document is subject to change without notice. 2017-07-20 ® Falcon and Falcon® Electric are registered trademarks of Falcon Electric Inc...

  • Page 2: Table Of Contents

    T BLE OF CONTENTS Features Internal Configuration Diagram. Important Safety Instructions (READ FIRST) . Overview Interface Control Drawing Battery Connector Wiring Details Installation Details Maintenence Servicing Information . Storing the Battery Bank Technical Support...

  • Page 3: Features

    FEATURES Dual Internal Battery Chargers Rugged 5U Rackmount Construction May be Used with any SSG and SSG-RP model (supports both 48Vdc and 96Vdc models) High Capacity, Deep Cycle, 10-Year Rated Batteries Optional High Capacity Slide Rail Kits INTERNAL CONFIGURATION DIAGRAM...

  • Page 4: Important Safety Instructions (Read First)

    CAUTION This device has an internal sealed lead-acid battery energy source and utilizes no user replaceable parts. Refer all servicing to Falcon Electric, Inc. voltage that may be hazardous. Do not attempt to disassemble. This unit contains CAUTION THIS DEVICE IS NOT INTENDED TO BE USED IN CONjUNCTION WITH LIFE SUPPORT OR OPERATING ROOM EqUIPMENT.
  • Page 5 CAUTION Servicing of batteries should be performed or supervised by personnel knowledgeable about batteries and the required precautions When replacing batteries, replace with the same type and number of batteries or battery packs. CAUTION A BATTERY CAN PRESENT A RISK OF ELECTRICAL SHOCK AND HIGH SHORT CIRCUIT CURRENT.

  • Page 6: Overview

    Due to the 270 pound weight of the entire battery bank it is constructed of heavy gage aluminum. Mounding holes are provided on both sides of the chassis for the installation of optional heavy duty slide mounting rails. (Falcon Part Number: SSGB-40A-SRKIT) CAUTION DUE TO THE 270 POUND WEIGHT OF THIS BATTERY BANK NEVER ATTEMPT TO LIFT WITHOUT SUITABLE LIFTING EqUIPMENT.

  • Page 8: Installation Details

    Installation Details 1. If more that one battery bank is to be installed into an equipment rack you must verify the rack is rated to support the weight of all battery banks and any additional equipment to be installed into the rack. 2.
  • Page 9 WARNING DO NOT TURN ON ANY BATTERY DISCONNECT SWITCHES UNTIL INSTRUCTED TO DO SO DURING THE FOLLOWING INSTALLATION STEPS 8. Once the battery bank has been installed into the rack, connect the supplied charger power cord to the battery bank power inlet then to a properly rated power outlet. 9.

  • Page 10: Maintenence

    77ºF environment with the proper charging and limited ments or in locations where the batteries are cycled excessively, battery service life will be substantially reduced. Should you require battery replacement contact the Falcon Service Department WARNING exists within the unit, which could cause electrical shock. Servicing of Untrained personnal should never attempt to service batteries.

  • Page 11: Servicing Information

    SERVICING INFORMATION...

  • Page 15: Storing The Battery Bank

    Storing the Battery Bank Should you need to store the battery bank for a period of time exceeding 6 month, fully recharge the battery just prior to storage and recharge the battery every 6 months by plugging it in and turning on the battery charger power switch. Allow to recharge for 48 hours.

  • Page 16: Technical Support

    You may request technical information or support by email or telephone. SUPPORT@FALCONUPS.COM Please send your technical or support questions by email to: You may contact a FALCON support engineer directly by calling the FALCON 800.842.6940 support line between 9:00 am and 4:00 pm PST.
