Programmable Dual Plug-in Tim
USER GUIDE
19528
19528SP
Philex Customer Careline 08457 573479
Functions
Before programming, insert two back up batteries supplied into the
battery holder located at the top right hand corner on back of timer.
Replacement button cells CX 921 or equivalent.
Battery disposal: Please follow manufacturer's instructions when
disposing of old and used batteries.
er
The 19528R Programmable Dual
Plug-in Timer has functions for:
•
Up to 98 On/Off programs
per week
•
Different individual programs
at the same time each day
•
Random and Countdown
modes
•
Temporary Over-ride Mode
to allow manual switching
On/Off of appliances
•
Individual ON/OFF buttons
for each socket allowing
appliances to be switched
On/Off separately
•
Easy to read LCD display with
AM/PM or 24 hour settings
•
LED indicators show the
On/Off status of each
channel
•
Summer/Winter time
conversion
Advertisement
Related Manuals for Philex 19528
Summary of Contents for Philex 19528
- Page 1 Programmable Dual Plug-in Tim USER GUIDE 19528 19528SP Philex Customer Careline 08457 573479 Functions The 19528R Programmable Dual Plug-in Timer has functions for: • Up to 98 On/Off programs per week • Different individual programs at the same time each day •...
- Page 2 Programming your Dual Plug-in Timer 1. CLOCK 2. POWER TIME ON/OFF SETTING 1.1 Optional clock display: 2.1 Press the button once to enter the power timer On/Off setting mode with 1 ON (a) 12-hour (AM/PM) display: displayed at the bottom left of the screen. the digital number is from 1:00 to 12:59 1 = Group 1 On/Off time with AM or PM showing on the left of the...
- Page 3 Programming continued 3. COUNTDOWN SETTING 2. Continued (Channel 1 only) 2.5 Press SET and or V buttons to select the Socket CH1 has Countdown, but not Random different sockets. function. CH1 must be set to AUTO mode when The display order will be: using Countdown function.
- Page 4 CH2 must be set to AUTO mode when using Random function. Ensure that you familiarise yourself with the set-up procedures before you initiate a programming sequence, as display will revert back to clock mode if unattended for 10-15 seconds. © Philex Electronic Ltd. 2004...
