Summary of Contents for Astell & Kern ACRO B100E
- Page 1 ACRO B100E INSTRUCTION BOOK User Guide...
-
Page 2: Table Of Contents
CONTENTS Getting Started Before Using the Product Included Items Parts Names Power Management Connections Using the Device Basic Operations Listening to Music Listening to Radio Miscellaneous Safety Pre-Cautions Troubleshooting Copyright Certifications Registered Trademarks Disclaimers Specifications... -
Page 3: Before Using The Product
User Guide Before The descriptions contained in this instruction book are based on the product's default settings. Using the The content of this user guide may differ from that of the Product actual product depending on the manufacturer's specification changes, and the picture in the user guide may differ from that of the actual product. -
Page 4: Included Items
User Guide Included Components may change without previous notice to improve the performance or quality of the product. Items ACRO B100E FM antenna Power adopter US&JP Adaptor plugs Quick Start Guide & (UK, KR, EU, US&JP, CN) Warranty Card FM antenna : Receive FM broadcasts. -
Page 5: Parts Names
User Guide Parts The appearance of the product as well as the information printed and engraved on the product may vary depending Names on the manufacturer's specifications. Play/Pause Preset Bass Power/Volume/Mode Treble Next Song/Channel Previous Song/Channel Power Port AUX IN Service Port Antenna Port Getting Started... - Page 6 User Guide Preset: You can save up to 6 radio channels of your choice. Bass: Adjust the bass level. Play/Pause: Play or pause playback. Power/Volume/Mode: Long press - Turn ON/OFF the product. Short press - Change the mode. Turn the wheel to adjust the sound volume. Treble: Adjust the treble level.
-
Page 7: Power Management
User Guide Power Connecting the adapter and the plug Manage- 1. Remove the adapter by pressing the bottom of the cover and lifting it up. ment 2. Select the appropriate plug for your country and slide it down until it clicks in place. - Page 8 User Guide Connecting Power 1. Connect the included adapter to the [Power] port on the back of the product. 2. Select the appropriate plug for your country, connect it to the adaptor, and then connect it to the outlet to supply power to the product.
- Page 9 User Guide Turning the Device On 1. Press and hold the [Power/Volume/Mode] wheel to turn on the speaker. The front display will show [BT], and the LED under the [Power/Volume/Mode] wheel will light up. Turning the Device Off 1. With the power on, press and hold the [Power/Volume /Mode] wheel.
-
Page 10: Connections
Bluetooth Pairing Standby mode. 2. Turn ON the Bluetooth feature on your mobile device: [Settings > Connections > Bluetooth] 3. Select [ACRO B100E] when it appears in the device search to complete pairing with your mobile device. Entering Bluetooth Pairing Mode Use this mode to connect the speaker with a device other than the currently paired mobile device on Bluetooth. - Page 11 User Guide The connection image may vary depending on the connected mobile device and the version of the software. After pairing is complete, check the volume before using the speaker. If Bluetooth pairing is not working, press and hold the [Preset] button for 5 seconds or longer to enter the Pairing Standby state.
-
Page 12: Basic Operations
User Guide Basic Button Operations Opera- tions Preset Bluetooth Mode: Press and hold the [Preset] button for 5 seconds or longer to enter the Pairing mode. Radio Mode: You can save up to 6 channels of your choice. Treble Press the [Treble] button to adjust the treble level. - Page 13 User Guide Next Song/ Bluetooth Mode: Go to the next song. Channel Radio Mode: Go to the next channel. Power/ Long press - Turn ON/OFF the Volume/ product. Mode Short press - Change the mode. Available in 3 modes: BT > FM > AUX Turn the wheel to adjust the sound volume.
-
Page 14: Listening To Music
User Guide Listening Connecting to Bluetooth to Listen to Music to Music 1. Press the [Power/Volume/Mode] wheel to set it to [BT] mode. The front display will show [BT]. 2. After connecting the speaker and the mobile device via Bluetooth, you can play music through the speaker by playing it on the mobile device. -
Page 15: Listening To Radio
User Guide Listening Listening to Radio to Radio 1. Press the [Power/Volume/Mode] wheel to set it to [FM] mode. The front display will show [FM]. 2. Press the [ ] button to go to the desired frequency. The front display will show the new frequency. Pressing the [ ] button moves the frequency in 0.1 MHz steps. - Page 16 User Guide Listening to a Saved Radio Channel 1. In [FM] mode, press the [Preset] button to go to the saved channel. The front display will show the frequency with [P]. 2. Press the [Preset] button to navigate through the saved channels.
-
Page 17: Safety Pre-Cautions
User Guide Safety Product Precau- Do not insert any metal objects (coins, hairpins, etc.) or flammable debris into the device. tions Do not place heavy objects on the product. If the product gets wet from rain (water), beverages, liquid medicine, cosmetics, sweat, or other moisture, do not turn it ON. - Page 18 User Guide Do not press multiple buttons simultaneously. Do not press the button too hard. Do not block the vent in the back where the sound comes out. Do not place a fire source such as a candle on the product.
-
Page 19: Troubleshooting
User Guide Trouble- Common issues and solutions shooting 1. The device won't turn on. Please check whether the power adapter is connected properly. 2. Sound doesn’t come out. Check if the volume is set to [0]. Check the volume of the connected mobile device or external device. -
Page 20: Copyright
User Guide Copyright Dreamus Company retains the rights to patents, trademarks, copyrights, and other intellectual property rights related to this manual. No contents of this user manual may be duplicated or reproduced in any format or by any means without the prior approval of Dreamus Company. Using or reproducing, in whole or part, the contents of this document is subject to penalties. -
Page 21: Registered Trademarks
User Guide FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with FCC radiation exposure limits set forth for an uncontrolled environment. This module may not be co-located with any other transmitters or antennas. -
Page 22: Specifications
User Guide Specifi- ACRO BE100 Product Name cations Product Type Bluetooth Loudspeaker Model Name DSM21 Woofer Unit 4inch x1 Twitter Unit 1.5inch x2 Amplifier Output 55W(25W x1 + 15W x2) Frequency Response 50 ~ 20kHz Maximum Sound Level 94dB SPL @1m Bluetooth Version Bluetooth Codecs SBC, AAC, aptX™...
