Summary of Contents for Nomadic 2000
- Page 1 USER GUIDE NOMADIC 2000 & 3000 12V 24V 48V • •...
-
Page 2: Your Product
RECORD THIS INFORMATION FOR FUTURE REFERENCE Automotive Rooftop Air Conditioner Nomadic Cooling CO. LTD All service and dealer locations can be found at: WWW.NOMADICCOOLING.COM Nomadic Cooling DC Air Conditioner advantages: Fuel savings 12v 24v 48v DC Battery powered Environmentally friendly R134a refrigerant... -
Page 3: Technical Parameters
SPECS TECHNICAL PARAMETERS Model: 2000 and 3000 Cooling capacity (Standard mode): 2800W Driven mode: Battery driven unit Installing type: Mono-block & rooftop mounted Compressor Voltage: DC12V/24V/48V Evaporator blower air volume: 650m3/h Condenser fan air volume: 1050m3/h Compressor: 15cc/r, 18cc/r or 27cc/r Dimensions (mm): 900×804×160... -
Page 4: General Safety Guidelines
NOTICE This Unit is designed for OEM installation. Read these instructions carefully. Nomadic Cooling reserves the right to modify appearances and specifications without notice. This air conditioner (hereinafter referred to as “unit” or “product”) is designed and intended for installation on the roof of a Recreational Vehicle (hereinafter referred to as RV). -
Page 5: Other Considerations
• Incorrect maintenance or use of spare parts other than original spare parts provided by the manufacturer. • Alterations to the product without express permission from the manufacturer • Use for purposes other than those described in this manual, Nomadic Cooling reserves the right to change product appearance and product specifications. -
Page 6: Use Guide
USE GUIDE AIR CONDITIONER SIZING The ability of an air conditioner to cool a vehicle or maintain a desired temperature is dependent on the heat gain of the vehicle. • Physical size of vehicle • Window area • Quality and amount of insulation •... - Page 7 DIMENSIONS...
-
Page 8: Filling Refrigerant
REFRIGERANT FILLING REFRIGERANT NOTE: All Nomadic Air Conditioners shipped via land from manufacturer are pro-filled with the cor- rect refridgerant. This section only pertains to shipments delivered by air (internationally), or if the unit has had a leak and been repaired. -
Page 9: Cutting The Opening
• Clean surface with an oil repellent, such as Isopropyl alcohol diluted to 10%-15%, or other degreasers. • Remove the Nomadic Cooling 3M 14x14 waterproof gasket from the box. • Apply the 3M sticky side DOWN onto your vehicles roof, around the cut opening. - Page 10 • We recommend a Blue Sea 187 Breaker between your power source and the A/C Unit. • Nomadic Cooling 2000 – Blue Sea 187 100A • Nomadic Cooling 3000 – Blue Sea 187 125A • Use included copper butt connectors and attach to DC power cables. Crimp both ends of the DC-to-DC butt connectors onto the positive and negative wires.
-
Page 11: Operation
OPERATION REMOTE ON AND OFF Turns unit on and off SLEEP Turns the light on the control panel off but not the unit COOL/POWERFUL Will allow the unit to pull maximum amps for optimal performance, recommended in 90+ F situations Unit will pull power at the most efficient speed Will just run fan without the compressor UP AND DOWN...
