Aura Dual Boost 14 Pro User Manual

Dual portable monitor
Hide thumbs

Advertisement

Table of Contents

User Guide
Dual Boost 14" Pro
Dual Portable Monitor
Aura

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dual Boost 14 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Aura Dual Boost 14 Pro

  • Page 1 User Guide Dual Boost 14" Pro Dual Portable Monitor Aura...

  • Page 2: Package List

    1. Package List 14’’ Portable Dual Monitor USB-C to USB-C / USB-A Cable USB-C to USB-A Cable Aura USB Disk (with Display Driver) User Manual...
  • Page 3 2. Introduction Type-C Full Function Port • USB Type-C 3.1 • Transmit the audio and video signal • Simultaneously support power delivery Type-C Power Supply Port • Only for power delivery Indicator Light • Green: Power on and monitor connected successfully •...
  • Page 4 3. Set It Up The correct sequence should be performed to avoid any damage to the device. Note: Unfolding Sequence Please open the right display screen first and then open the left display screen. Storing Monitor Please fold the left display screen first and then fold the right display screen.
  • Page 5 3. Set It Up Adjustable Stand and Monitor Adjust the stand angle according to your need. Landscape Mode Triangular Mode Single Portrait Mode...
  • Page 6 4. Driver Installation 4.1 For macOS Laptop Please download the driver of the macOS system in the USB disk Or download the drive by: https://www.siliconmotion.com/downloads/index.html Connect macOS Laptop: Click “About This Mac” on your Macbook.

  • Page 7: Driver Installation

    4. Driver Installation Click “Overview” to check your detailed macOS system info.
  • Page 8 4. Driver Installation Please insert the included USB Disk into your Macbook and download corresponding driver based on your macOS system.
  • Page 9 4. Driver Installation Please drag “macOS InstantView” to “Applications” folder and run it. Click “macOS InstantView” in “Applications” to run the driver.
  • Page 10 4. Driver Installation Please click “Open”. Please click "Open System Preferences". Choose “Secrity & Privacy”, click “Screen Recording” and enable “macOs InstantView”.
  • Page 11 4. Driver Installation Please click the “CONNECT”. When connected successfully, a screen record icon shows up.
  • Page 12 4. Driver Installation 4.2 For Windows Laptop Please download the driver of the Windows system in the USB disk. Or download the drive by: https://www.siliconmotion.com/downloads/index.html Please insert the included USB Disk into your Wins laptop and download Windows driver.
  • Page 13 4. Driver Installation Click: Click the “INSTALL”.

  • Page 14: For Android

    4. Driver Installation 4.3 For Android Please download the driver of the Android system in the USB disk. Or download the drive by: https://www.siliconmotion.com/downloads/index.html...

  • Page 15: Connection Method

    5. Connection Method Single Connection Methods Note: After the display driver is installed, at least 5V/3A of sustained power is required for the Dual Boost 14" Pro monitor to receive signal. Single USB-C to USB-A Converter Head Connection Single USB-C Cable Connection (USB-A can not power the monitor) An external power is required ! Cable Connection Methods if Additional Power is Required...
  • Page 16 6. Display Setting for Wins/macOS 6.1 macOS Display Settings and Configuration Click the System Settings icon in the Dock or choose Apple menu > System Settings. Click "Display" and "Arrangement". Then long drag the Screen to rearrange the screen location based on your preference.
  • Page 17 6. Display Setting for Wins/macOS Click "Display" and "Arrangement". Then long drag the Screen to rearrange the screen location based on your preference. Choose the display mode you prefer [Main display/Extended display/Mirror]...
  • Page 18 6. Display Setting for Wins/macOS 6.2 Windows Display Settings and Configuration Right-click the desktop and select either Screen Resolution (Windows 7/8) or Display Settings (Windows 10/11 ). Click Detect to check if the dual monitor is connected successfully. If yes, please click Identify to confirm the screen location.
  • Page 19 6. Display Setting for Wins/macOS Duplicate & Extend Mode Setting: Click the Multiple displays drop-down list, and then select Extend/Duplicate...
  • Page 20 6. Display Setting for Wins/macOS 6.3 How to Close Single Display Screen 6.3.1 For macOS and Wins Laptop Long press MENU key for 5s.
  • Page 21 6. Display Setting for Wins/macOS 6.3.2 Only For Wins Laptop In "Display Setting", select the display screen you want disconnect and click "Disconnect this display" in drop-down list.

  • Page 22: Power Button

    7. OSD Function Introduction 7.1 OSD Overview Power button • Long press for 3s to turn the monitor on/off. “+” button • Quickly adjust the brightness; • Choose the OSD setting subpage; • In/decrease the value of the setting on OSD. Menu button •...
  • Page 23 7. OSD Function Introduction 7.2 Restore OSD Default If you accidentally change the OSD default language setting, please follow the steps below to restore the OSD default value. Press the “MENU” button. Press the “+”to choose “ ”, then to press “MENU” button. 7.3 OSD Menu...

  • Page 24: Osd Function Introduction

    7. OSD Function Introduction Brightness The adjusting range is from 0 to 100 Backlight The adjusting range is from 0 to 100 Picture Contrast The adjusting range is from 0 to 100 Sharpness The adjusting range is from 0 to 4 Temperature 9300/7500/6500/5800/sRGB/User Color Effect...

  • Page 25: Tech Specs

    8. Tech Specs Product 2146g Portable Dual Monitor Weight name Viewable Screen size 310(H)*175mm (inch) 14inch*2 area Product size 1080P FHD IPS 353mm*208mm*30mm (mm) Aspect Resolution 16:9 1920*1080 ratio Color Temperature(K) 16.7M 6500K Viewing angle H：89°/89°Min Refresh rate 60Hz Contrast V：89°/89°Min brightness 1000：1...
  • Page 26 9. Use requirements & Cleaning & Maintenance In order to ensure the normal use of this product and prevent accidents such as electric shock and fire, please read and understand all usage requirements and operating procedures before using this product. Please strictly abide by the following requirements: •...
  • Page 27 10. FAQ & Contact Us Questions Answer The screen flickers or Your laptop battery is low. Please use included 5V/3A disappears for a moment power adapter to charge this dual monitor. When your laptop enters sleep mode, the monitor also The dual monitor screen goes to sleep mode.
