- Page 1 CM01WTA11M Approval Sheet Revision Date 20230504 Revision No. Total Pages CM01WTA11M (BLE/WiFi Combo Module) USER manual SoluM Co., Ltd REV-1.0 1/19...
-
Page 2: Revision History
Revision History Revision Date Descriptions 2022-05-10 Initial release REV-1.0 SoluM Co., Ltd 2/19... -
Page 3: Table Of Contents
Manual ............................. 14 4 4.1 Interface (UART) ........................14 4.2 Module Control (Host → module) ....................14 4.3 Commend response (module → Host) ..................16 Antenna list ..........................17 5 FCC Information to User ......................18 6 REV-1.0 SoluM Co., Ltd 3/19... -
Page 4: General Description
Application Home appliances Rice cooker, Induction range, IoT sensor etc REV-1.0 SoluM Co., Ltd 4/19... -
Page 5: Features
Serial peripheral interface (master and slave modes) Compact dimension: 3 5 mm x 2 0 mm / H max: 4 . 8 mm Host Interfaces: UART Interface RoHS compliant 1.3 Picture Figure 1-1 Module Picture REV-1.0 SoluM Co., Ltd 5/19... -
Page 6: Dimension, Pin Assignments, Pictures
2 Dimension, Pin Assignments, Pictures 2.1 Dimension L X W X H = 20.0 x 35.0 x 4.8mm Figure 4-1 Module Dimension Parameter Condition Min. Nom. Max. Unit Dimension (Module) 19.7 20.3 29.7 35.3 Height REV-1.0 SoluM Co., Ltd 6/19... -
Page 7: Pin Assignments
2.2 Pin Assignments Figure 4-4 Interface UART Pin Assignments (Top View) Pin Name Description Type UART1_TX UART Interface TX UART1_RX UART Interface RX UART2_TX UART Debug TX UART2_RX UART Debug RX VIN_3V3 +3.3V Power supply(2.97V ~3.63V) REV-1.0 SoluM Co., Ltd 7/19... -
Page 8: Application Design Guide
2.3 Application design guide REV-1.0 SoluM Co., Ltd 8/19... -
Page 9: Absolute Maximum Ratings
3.2.4 Bluetooth mode Parameter Conditions Min. Nom. Max. Unit BT mode (Type. current) BT MP, 4.5dBm Tx Power BT Tx BLE Central mode BT Rx BT Peripheral mode BT ADV BT Central mode BT Connection REV-1.0 SoluM Co., Ltd 9/19... -
Page 10: Recommended Operating Conditions
Parameter Conditions Min. Max. Unit DC supply voltage from HOST +2.97 +3.3 +3.63 °C Operating temperature(Ambient) 3.4 Environmental Characteristics Symbol Parameter Conditions Min. Max. Unit Electro-static discharge voltage Operating temperature °C Tstg Storage temperature °C REV-1.0 SoluM Co., Ltd 10/19... -
Page 11: Rf Specifications
48Mbps OFDM -78.0 54Mbps OFDM -76.5 -93.5 MCS0 MCS1 -91.0 MCS2 -88.5 PER<10%, MCS3 -85.5 802.11n (HT20) Packet size= MCS4 -82.5 1,024bytes MCS5 -77.0 MCS6 -75.5 MCS7 -74.0 Maximum input level 802.11b PER<8% 802.11g/n(2.4GHz) PER<10% REV-1.0 SoluM Co., Ltd 11/19... -
Page 12: Wlan Transmitter Rf Specifications
. Method: composite EVM method. . Number of symbols: 17. . Phase correction: Symbol-by-symbol correction. . Channel estimation: Raw channel estimate full packet. . Symbol timing correction: on. . Amplitude tracking: off. . Frequency Sync: Long training symbol. REV-1.0 SoluM Co., Ltd 12/19... -
Page 13: Bluetooth Rf Specifications
Parameter Conditions Typ. Unit Frequency Range 2402+K*2MHz (K=0~39) 2402 2480 Receiver Sensitivity (PER) PER ≤30.8% -100 Max received signal PER ≤30.8% Transmitter Output Power Average Power ICFT Frequency offset Drift rate kHz/50us Initial drift rate REV-1.0 SoluM Co., Ltd 13/19... -
Page 14: Manual
Broadcast BLE advertisement by device name AT+BROADCAST=XXXXXXXX XXXXXXXX AT+CONNECT Connect to the server OK[CR][LF] ATSC=0 AT+OTA_PROD=XXXXXXXX Update Product FW(URL: XXXXXXXX) ATSC=1 AT+OTA_MOD=XXXXXXXX Update module FW(URL: XXXXXXXX) AT+OTA_READY_OK Host is ready for OTA AT+OTA_DONE OTA completion confirmed REV-0.1 SoluM Co., Ltd 14/19... - Page 15 AT+PRODINFO=XXXX Set product information XXXX AT+LCDSEND=XXXXXXX Set LCD type to XXXXXXX AT+NMAC=? Get WLAN MAC AT+RSSI=? Get RSSI AT+MODULEVER=? Get MODULE version OK_XXXX[CR][LF] AT+LCDVER=? Get LCD version AT+SSID=? Get SSID AT+PWD=? SET WLAN PASSWORD REV-0.1 SoluM Co., Ltd 15/19...
-
Page 16: Commend Response (Module → Host)
ERROR Commend fail READ=XXXXXX Rx data from server OK[CR][LF] EVENT=TCP_SERVER_CONNECT Successful sever connection EVENT=TCP_SERVER_FAIL Sever connection fail EVENT=TCP_SERVER_DISCONNECT Sever disconnected EVENT=OTA_READY OTA ready OK[CR][LF] EVENT=OTA_START OTA started EVENT=OTA_END OTA completed EVENT=OTA_FAIL OTA failed REV-0.1 SoluM Co., Ltd 16/19... -
Page 17: Antenna List
5 Antenna list Antenna selection guide 1) Impedance: 50Ω 2) Frequency range: 2.4GHz~2.5GHz 3) Peak gain: 3.999dBi 4) Example antenna - KDT-TE-2450TO-03D-RP (Wi-Fi Dual and 2.4GHz /5GHz) for External Tilt REV-0.1 SoluM Co., Ltd 17/19... -
Page 18: Fcc Information To User
A label must be affixed to the outside of the host product with the following statements: Product Name: Wi-Fi CAT (Connected Appliance Transceiver) Module Contains FCC ID: 2AFWN-CM01WTA11M REV-0.1 SoluM Co., Ltd... - Page 19 That module is limited to installation in mobile or fixed applications, according to Part 2.1091(b). That separate approval is required for all other operating configurations, including portable configurations with respect to Part 2.1093 and different antenna configurations. REV-0.1 SoluM Co., Ltd 19/19...
