SR-OCFF
SPEED RING
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the SR-OCFF and is the answer not in the manual?

Questions and answers

Summary of Contents for raya SR-OCFF

  • Page 1 SR-OCFF SPEED RING USER MANUAL...
  • Page 2 INTRODUCTION Thank you for choosing Raya. The Raya SR-OCFF Speed Ring is designed exclusively to mount the Raya OC-OSB80 32˝ or Impact FF- OSB60 24˝ Octa Softboxes to the Raya SDR-400 Alpha Monolight. It offers easy setup and takedown with quick attachment to your SDR-400’s S-Mount, so you can create soft, diffuse lighting on location or in the studio.
  • Page 3 OVERVIEW Speed Ring: Also Included: Rod sockets User manual 2. Mounting pegs...
  • Page 4 INSTRUCTIONS MOUNTING YOUR OCTA SOFTBOX TO THE SPEED RING Open and unfold your Insert the plain black end softbox, and fit the speed of one of your softbox’s ring inside the center hole. flex rods into one of the Make sure the speed ring’s speed ring’s rod sockets.
  • Page 5 Insert the next rod into the Attach the remaining rod socket on the opposite flex rods according to side of the speed ring, the instructions above, and then fit it into your making sure to insert one softbox’s rod pocket. rod and then the next on the opposite side of the Attach the next two flex...
  • Page 6 MOUNTING THE SPEED RING ASSEMBLY Before mounting the speed ring assembly to your Raya SDR-400 Alpha Monolight, make sure that your monolight is turned off and unplugged from its power source and that it’s securely mounted to a light stand.
  • Page 7 Remove the flex rods Remove the speed ring from the softbox in pairs, from the center hole of in the same manner that your softbox. Specifications SR-OCFF Diameter 6.25˝ (16 cm) Depth 2˝ (5 cm) Weight 8.8 oz. (249 g)

  • Page 8: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY This RAYA product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
