YANMAR CO., LTD.
YANMAR AMERICA CORP.
Supplement to Yanmar Kit Installation Instructions
SAFETY
This product is designed and intended only for use
with a YANMAR engine. All safety and warning
information contained in the Yanmar Operation
Manual and Service Manual is adopted and
incorporated to apply to the components,
accessories, and parts that are utilized with Yanmar
engines. Follow all instructions and precautions
before installing this product, before operating,
during operation, and during periodic maintenance
procedures for your safety, the safety of others, and
to protect the performance of your engine.
Advertisement
Summary of Contents for Yanmar KPH20
- Page 1 Supplement to Yanmar Kit Installation Instructions SAFETY This product is designed and intended only for use with a YANMAR engine. All safety and warning information contained in the Yanmar Operation Manual and Service Manual is adopted and incorporated to apply to the components, accessories, and parts that are utilized with Yanmar engines.
- Page 2 2) Service parts are denoted by an asterisk. To replace non-service parts, the entire kit will need to be purchased MODELS 3TNV88F Figure 1. Adapter Harness Harness as Installed KPH20 - Adapter Harness(KPH3 to KP8/9) PAGE 1 OF 3 INS-KPH20-0010...
- Page 3 Figure 2. KP9 connection Figure 3. Alignment slots Turn the locking ring clockwise until it clicks into place as shown in Figure 4. Figure 4. Turn locking ring clockwise KPH20 - Adapter Harness(KPH3 to KP8/9) PAGE 2 OF 3 INS-KPH20-0010...
- Page 4 Figure 5. KPH3 Connection Figure 6. Alignment Slots Turn the locking ring clockwise until it clicks into place as shown in Figure 7. Figure 7. Turn locking ring clockwise KPH20 - Adapter Harness(KPH3 to KP8/9) PAGE 3 OF 3 INS-KPH20-0010...
