Page 1 TASER ® Operating Manual TASEIR...
Page 2: Important Safety And Heal Th Information
Read, understand and follow the warnings and safety instructions contained in the enclosed Product Warnings document included with this weapon. The most current warnings are posted on our Web site at www.TASER.com. Do not attempt to use this device until you have read and understood this manual.
Page 3: Operational Safety
Minimize Risks Before Use Read, understand and follow all warnings and instructions before using TASER C2. Read and Heed. Do not attempt to use a TASER device unless you have read and understood this Complete Training First. manual. Carry and use the TASER in accordance with applicable federal, state, and local Obey Applicable Laws.
Page 4 New Weapon Activation section for more details. Do not give a TASER device away as a gift or sell it without filling in the registration card or transfer card. Do not give or sell a TASER device to anyone not authorized to own it. For more information, see the Legality section of this manual.
Page 5 The TASER C2 uses a replaceable cartridge containing compressed nitrogen to deploy two small probes that are attached to the TASER C2 by insulated conductive wires with a maximum length of 15 feet. The TASER C2 transmits electrical pulses along the wires and into the body affecting the sensory and motor functions of the peripheral nervous system.
Page 6 These injuries are secondary in nature and not directly attributable to the electric stimulation of the TASER device, but are possible consequences of the involuntary muscle contractions the TASER device induces to produce incapacitation. Some of the effects may include: Subject may fall immediately to the ground and be unable to catch him/herself.
Page 7 TASER conducted energy pulses. TASER C2 AND CARTRIDGE FEATURES The C2 is constructed of impact resistant sonic welded polymer and weighs approximately 7 ounces. Various color options are available. See www.TASER.com for the most current specifications.
Page 8: Safety Cover
(ARMED). The microcontroller will then sense the battery voltage and determine whether or not the battery is marginal or operating in a marginal condition (-20 °C). The C2 will then light the green LED to indicate a "good" battery or the yellow LED for a "bad" battery.
Page 9: Power Led
TRIGGER BUTTON The trigger button is located under the safety cover and is ARMED when the safety cover is in the open position. If the C2 has not been activated, the trigger button is used to enter the authorization code.
Page 11 Avoiding Unintentional Discharge Never attempt to open or modify a TASER C2 Cartridge. Tampering with a live TASER Cartridge could cause it to discharge or malfunction (which may result in injury). Handle all T ASER Cartridges with care. Probes may deploy unexpectedly if exposed to physical shock.
Page 12 ACTIVATING A NEW TASER C2 (U.S. Only) The C2 is shipped in a pre-active mode, and will not discharge until the background check is complete and the unique activation code is entered in the C2.
Page 13 If the green light does not flash, remove the LPM, wait five seconds, and re-insert the LPM. This will reset the pre-active state and permit you to enter the entire code sequence again. If the C2 cannot be activated in 100 attempts, return it to TASER International. See the RMA Process section for more information.
Page 14 UNLOADING: The C2 Cartridge is designed to ensure a secure fit when inserted in the C2. The placement of the wire bundles behind the insertion tabs aids in providing a secure fit. It is very difficult to remove a cartridge with the wire in place (that is, when the cartridge has not been deployed).
Page 15 Removal of an expended cartridge does not require the additional force because the wires are no longer behind the tabs. The TASER Cartridges for the C2 are specifically designed so there is no "up" or "down" position - enabling you to quickly reload one in a stressful situation without worrying about putting it in upside down.
Page 16 Depending on local and state laws, the TASER C2 may be kept in the house for home protection, or carried in a car, purse, etc. for personal protection when away from home. Be sure to research each state's applicable laws prior to possessing or transporting the device across state lines, or into other states where laws may vary.
Page 17 As soon as it is safe to do so, call 911 and report the specific location of the threat. Do not hesitate to leave the C2 at the scene of the attempted assault. Send a copy of the police report to TASER International and we will replace the weapon at no charge. See www.TASER.com for more information on the replacement guarantee.
Page 18 Due to automatic reflex actions, most subjects will struggle to separate from the TASER device. When the TASER device is used in the drive-stun mode and the subject struggles to get away it may be difficult to maintain contact between the device and the subject.
Page 19 When using the drive-stun, push (drive) the front of the TASER C2 firmly against the body of the subject. Simply "touching" the C2 against the subJect is not sufficient. The subject is likely to recoil and try to get away from the stun electrodes.
Page 20 The C2 internal software provides functionality for all aspects of the device. You can always install a previous version LPM in the weapon. The software will not program the C2 to an older version and the weapon will remain at the higher of the software version in the weapon or the LPM.
Page 21: Warranty Policy
Dry the C2 thoroughly (at least 24 hours). Reinstall the LPM. Safety cover open (ARMED). If the C2 discharges without pressing the trigger button, remove the LPM and return the C2 to TASER International immediately. Spark test for a full 30 seconds.
Page 22 Failure to provide the required information may delay or forfeit the return of the repaired items. Any TASER device that has not been paid for or required inf o rmation has not been provided during a period of 90 days after receipt of the TASER device by TASER shall be deemed abandoned and TASER may dispose of such TASER device without any compensation to Purchaser.
Page 23: Additional Information
Because M 18-, M26-, X26-, and C2-series devices are not firearms, they may be carried without a permit in certain jurisdictions (check state and local laws for permit requirements in your area) The TASER device is restricted from possession by citizen users in the following states: Washington DC, Hawaii, Massachusetts, Michigan, New Jersey, New York, Rhode Island, and Wisconsin.
Page 24 TASER International warrants that its TASER C2 devices are free from defects in workmanship and materials for a period of 90 days from the date of attempted activation. TASER International agrees to repair or replace such defective product which, under normal use as defined in the instructions that accompanied the product at time of purchase, fails to function within the limited warranty period provided that the disclosed defect is determined by TASER International to be TASER lnternational's fault.
Page 25 For customers who have purchased a "No Questions Asked" Warranty, TASER International warrants it will repair or replace any TASER C2 which fails to function for any reason from the date of purchase of the "No Questions Asked" Warranty through the balance of the warranty term. The "No Questions Asked" Warranty entitles Purchaser to one (1) free replacement for damage from any cause during the "No Questions Asked"...
Page 26: Warranty Exclusions
Name, address, and phone number of where to return the repaired item. Failure to provide the required information may delay the return of the repaired item. Any TASER device that has not been paid for or required information has not been provided for during a period of 90 days after receipt of the TASER device by TASER International shall be deemed abandoned and TASER International may dispose of such TASER device without any compensation or further notification to Purchaser.
Page 27: Limitation Of Remedies
DAMAGES AND PERSONAL INJURY WHICH MAY RESULT FROM THE DEPLOYMENT, USE, OR MISUSE OF THE TASER PRODUCT TASER IS NOT LIABLE FOR THE FAILURE OF THE TASER PRODUCT TO PERFORM AND TASER IS NOT LIABLE FOR ANY CLAIMS MADE BY A THIRD PARTY OR BY PURCHASER FOR OR ON BEHALF OF A THIRD PARTY.
Page 28 40 +states.Prohibited citizen use in DC, HI, MA, Ml, RI, NY, NJ, WI & certain cities & counties. CT and IL legal with restrictions. Check local laws on carrying electronic control devices. C> 2007 TASER International, Inc. TASER and the Globe and Lightning Boh logos are trademarks ofTASER International, Inc. All Rights Reserved. MMUOOl O Rev: B...
