Topway BCS1A1 User Manual

Product Name
Product Model
Pressure Monitoring Range
Operating Temperature
Battery Life
Remark:
1. This sensor can detect real time tire pressure & temperature;
2. According to different vehicle models, the dashboard or infotainment may show pressure,
pressure & temperature, or warning icon in time of data beyond the "safety range" has been
detected. However, what is shown is set by the vehicle factory & cannot be changed. For example,
if the infotainment shows tire pressure only with its original sensors, when you replace the
sensors, the information shown on the infotainment is also tire pressure only.
Before Installation:
Make sure that -
1. Your car model & year are within the "Car Models Supported " listed at the bottom;
2. The sensor frequency is the same as what is indicated on the original sensors or vehicle user's
manual;
Installation:
1. Only professionals are authorized to install the sensors, who can be found in Every tire stores,
Every car service workshops, or Most of car parts stores;
2. Demount the tire & wheel from a vehicle;
3. Demount the tire from the wheel;
4. Replace the old sensor/valve with our new sensor -
4.1 Sensors with metallic valve: disassemble the cap, gasket & nut->install the valve through
the wheel valve hole->put on the gasket->fasten the nut->screw in the cap.
4.2 Sensor with rubber valve: unscrew the cap->snap in the valve through the wheel valve
hole->screw in the cap.
5. Mount the tire on the wheel;
6. Mount the tire & wheel on the vehicle.
After Installation:
Pairing the sensors with the infotainment is necessary to display tire information on the latter.
Step 1: Scan each newly installed sensor ID in the the sequence of "Front Left - Front Right - Rear
Right - Rear Left" through a scan tool (for example, an Ateq Tool);
Step 2: Turn the ignition to "ON" with the engine off;
Step 3: Connect the scan tool to the OBDII port and upload the sensor IDs;
Step 4: Turn the ignition to "OFF" to re-scan each sensor for pairing;
Step 5: Drive the vehicle for at least 10 minutes with an even speed of 30mph or above to make
sure no warning information is displayed.
User's Manual
SPECIFICATION
Programmed TOYOTA TPMS Sensor BCS1A1 (4pcs)
BCS1A1
0 ~ 8Bar (0 ~ 116PSI)
-40 O C ~ 125 O C ( -40 O
~ 6years
4
F ~ 257 O F)
