1.IPQ5018 UI settings
2.DR5018S UART configuration
3.DR5018S GPS
DR5018S
THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF
THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED,
COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT
WRITTEN PERMISSION OF WALLYSTECH.
Advertisement
Related Manuals for WALLYS DR5018S
Summary of Contents for WALLYS DR5018S
- Page 1 1.IPQ5018 UI settings 2.DR5018S UART configuration 3.DR5018S GPS DR5018S THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED, COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT...
- Page 2 Wallys | User Manual | DR5018S IPQ5018 UI setting 1.Input the IP 192.168.1.1 and login 2.Input the username “admin” password “password” then press the button “Login” 3. Network setting • IP Setting: setting IP in the path "network->Interfaces->LAN- >IPV4 address"...
- Page 3 Wallys | User Manual | DR5018S IPQ5018 UI setting 4. Wireless setting login the path network->Interfaces->WIFI, then choose one wifi,we select the red marked as example,click the button ‘Edit’ www.wallystech.com...
- Page 4 Wallys | User Manual | DR5018S IPQ5018 UI setting The detail information show in the picture as below: • Channel:for channel select; • Transmit Power:signal chain power setting; ESSID:for ID • Mode:it support 4 mode AP,AP(WDS),client,client(WDS) Wireless • Security: for Encryption setting...
- Page 5 Wallys | User Manual | DR5018S IPQ5018 UI setting In advance setting you can select which chain do you need,which BW do you need and so on In the end, you need click the button “Save & Apply”, and wait for 2 minutes, then you can enjoy it.
- Page 6 Wallys | User Manual | DR5018S IPQ5018 UI setting 5. Backup archive Login System->Backup/Flash Firmware; Then click the button “Generate archive” Then download the archive www.wallystech.com...
- Page 7 Wallys | User Manual | DR5018S IPQ5018 UI setting 6.Update new image Login System->Backup/Flash Firmware; Then click the button “ flash image” Then click the button “Proceed” warning don't power off wait for about three minutes Then the system will reboot automatic.
- Page 8 Wallys | User Manual | DR5018S IPQ5018 UI setting 7. wireless encryption Login System->Network/wifi/Edit->Choose 5G radio Country Coad choose “ US ” click the button“Wireless Security” Then choose “WPA3” and set password Notice:SAE/SAE PWE/SAE MFP click “ √ ” www.wallystech.com...
- Page 9 Wallys | User Manual | DR5018S IPQ5018 UI setting 7. wireless encryption www.wallystech.com...
- Page 10 Wallys | User Manual | DR5018S DR5018S UART configuration 1. Introduction The photo below shows how to use the Uart for DR5018S www.wallystech.com...
- Page 11 Wallys | User Manual | DR5018S DR5018S UART configuration 2. Device connect Step 1:Connect the cable to the DR5018S As the picture as above,the sequence of the signal in the UART Connector:GND,TX,RX,VCC, And we need use GND connect black cable,TX connect to white cable,RX connect to Green cable VCC don't use.
- Page 12 Wallys | User Manual | DR5018S DR5018S UART configuration 2. Device connect Step 3 Login with the software You can use putty,Xshell or some others,enjoy it. www.wallystech.com...
- Page 13 Wallys | User Manual | DR5018S DR5018S GPS Identification command stty -F /dev/ttyMSM1 9600 cat /dev/ttyMSM1 www.wallystech.com...
- Page 14 DR5018S THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION, WHICH IS THE PROPERTY OF THE WALLYSTECH AND SHALL NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED, COPIED, OR USED AS THE BASIS FOR DESIGN, MANUFACTURING, OR SALE OF APPARATUS WITHOUT...
