Ú
Instructions for connecting gas and gas conversion (for
After-Sales Service only)
HGV1E0U50M
HGV1D0U59M
HGV1D0V50M
HGV1F0U59M
HGVDA0Q50M
HGVDA0Q59M
HGW3ASQ50M
HGW3ASQ59M
HGV1F0V50.
HGV1F0V20.
HGVDF0V..S
HGW3FSV..S
HGV1F0U5.S
HGW3FSV50.
HGX5G7W30.
HGX5G7W8.S
HGVDF0X50S
HGX5G7W59S
HGX5H0W50M
HGX5H0W59M
HIZ5G7W50M
HIZ5G7W59M
HJY5G7V60M
HJY5G7V69M
HJY5G7V60S
HIZ5G7W59S
HJY5G7V69S
06
001215
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bosch HGV1F0V50 Series
Summary of Contents for Bosch HGV1F0V50 Series
- Page 1 Ú Instructions for connecting gas and gas conversion (for After-Sales Service only) HGV1E0U50M HGV1D0U59M HGV1D0V50M HGV1F0U59M HGVDA0Q50M HGVDA0Q59M HGW3ASQ50M HGW3ASQ59M HGV1F0V50. HGV1F0V20. HGVDF0V..S HGW3FSV..S HGV1F0U5.S HGW3FSV50. HGX5G7W30. HGX5G7W8.S HGVDF0X50S HGX5G7W59S HGX5H0W50M HGX5H0W59M HIZ5G7W50M HIZ5G7W59M HJY5G7V60M HJY5G7V69M HJY5G7V60S HIZ5G7W59S HJY5G7V69S 001215...
- Page 2 Table of contents Ú Ú I n s t r u c t i o n s f o r c o n n e c t i n g g a s a n d g a s c o n v e r s i o n ( f o r A f t e r - S a l e s S e r v i c e o n l y ) Important information..............
- Page 3 Important information The appliance must only be converted from one gas type to Risk of gas escape! another by authorised personnel who have received After connecting the appliance to the gas supply, always appropriate training. The procedure must always be carried ■...
- Page 4 Gas connection Approved connections Natural gas connection (NG) If natural has (NG) is used, the gas supply should be These instructions apply only when the appliance is set up in connected via a gas pipe or a safety gas hose with threaded countries that are indicated on the rating plate.
- Page 5 Connection in accordance with EN 10226 R (TS 61-210 EN Secure the connection piece using a 24 mm spanner. Use a 10226 R 24 mm spanner to place the threaded fitting of the gas pipe or safety gas hose on the connection piece and tighten it Place the new seal in the connection piece.
- Page 6 Conversion to a different gas type Changing the gas type (*) Connecting piece for liquid gas (LPG: G30, G31) Change the gas connection piece. ■ Change the burner nozzles. ■ The bypass nozzles of the burner taps will need to be ■...
- Page 7 Setting the burner bypass nozzles and a small Remove the pan supports and the burner parts. flame The bypass nozzles are used to set the minimum flame height for the burners. Preparation Close the gas connection shut-off. Risk of electric shock! Disconnect the appliance from the mains.
- Page 8 Take the knobs off the hob top by pulling them towards you. If an upper appliance cover is available, hold this on both Remove the screws in the corners of the front panel. sides and lower it vertically into the holder (optional). Refit the pan supports.
- Page 9 Replacing the nozzle for the grill burner (optional) Remove the nozzle for the grill burner using a 7 mm box spanner. Open the oven door. Remove the two fastening screws on the grill burner nozzle holder. Select the appropriate nozzle from the table depending on the new gas type.
- Page 10 Checking the oven burner nozzle (option) Check the grill burner nozzle (option) Open the gas supply. Open the gas supply. Carefully close the hole in the oven burner nozzle using your Carefully close the hole in the grill burner nozzle using your finger or a suitable device.
- Page 11 Technical data – Gas Different types of gas and the corresponding values are listed here. Gas type mbar Nozzle Burner type Power Power Max. consumption (kW) min. (kW) (mm) Bypass G20 (l/h) G30 (g/h) Natural gas 1,16 0,78 High output burner ≤...
- Page 12 *9001456465* 9001456465...
