OWNER'S MANUAL
WASHING MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
WP11GAK / WP13GAK
MFL72042051
Rev.00_040324
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
Scan the QR code to see the manual.
www.lg.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LG WP11GAK
Summary of Contents for LG WP11GAK
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH WP11GAK / WP13GAK www.lg.com MFL72042051 Rev.00_040324 Copyright © 2024 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS This manual may contain images or content that may be different from the model you purchased. This manual is subject to revision by the manufacturer. SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE............3 WARNING ......................3 CARING FOR THE ENVIRONMENT ..............8 INSTALLATION Parts and Specifications ..................9 Installation Place Requirements ..............10... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. -
Page 4: Maximum Capacity
• The inlet water pressure must be less than 100 kPa. Maximum Capacity The maximum capacity for clothes to be used is: WP11GAK WP13GAK Wash (11 kg) / Wash (13 kg) / Spin (6.5 kg) - Page 5 SAFETY INSTRUCTIONS to weathering conditions such as direct sunlight, wind, rain, or temperatures below freezing. • Make sure the power plug is completely pushed into the power outlet. • Do not plug the appliance into multiple outlet sockets or an extension power cable.
- Page 6 • In case of a water leak from the appliance, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
-
Page 7: Maintenance
• Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location. -
Page 8: Caring For The Environment
• You can take your appliance to any of the authorised centres for collection. If you want to know an updated list of countries that have this service, visit the page https:// www.lg.com/global/take-back-recycling-global-network- south-america. -
Page 9: Installation Parts And Specifications
INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View *2 This feature is only available on models with a two-pin plug. Accessories Inlet Hose Safety Cover Drain Hose Washing Cover Snap Ring... -
Page 10: Specifications
INSTALLATION Specifications Model WP11GAK / WP13GAK Power Supply 120 V~, 60 Hz Water Level H : 84 litres, M : 72 litres, L : 60 litres, S : 50 litres Water Pressure Less than 100 kPa (1 kgf/cm Product Weight 30 kg Max. -
Page 11: Installation Location
INSTALLATION • Do not connect the earth wire to the gas pipe Remove the inlet hose and filter from the , lightning arrester, telephone connector, etc. accessory bag. Installation Location Installation Area • For placing & leveling the machine WARNING - Select flat &... -
Page 12: Installing The Drain Hose
INSTALLATION • If grounding method as described are not Press hose clip and push the hose towards the possible, a separate circuit-breaker should be body of the washing machine and release the employed and installed by a qualified electrician. snap ring. Installing the Drain Hose NOTE •... - Page 13 INSTALLATION • Make sure water is drained smoothly by placing a base under the machine or by applying other appropriate mean.
-
Page 14: Operation
OPERATION OPERATION Preparing the Wash Load • When you use liquid detergent, follow the guidelines provided by the detergent manufacturer. Sort the wash load for best washing results, and then prepare the clothes according to the symbols • Detergent usage may need to be adjusted for on their care labels. -
Page 15: Control Panel
OPERATION Control Panel Control Panel and Functions Water Supply Inlet • Connect here with the Inlet hose from the water tap to feed water to the tub. Water Selector • Select WASH to supply water for washing and rinsing and SPIN for spin shower rinse. Wash Timer •... -
Page 16: Operating The Appliance
OPERATION Operating the Appliance Set the desired wash time. Washing Set the Drain Selector as Wash.Rinse Position. • In the period 0~15 min - The machine will run the washing function. • In the period 16~35 min - The machine will switch between washing Set the Water Selector to WASH. - Page 17 OPERATION Spinning Put the laundry into the wash tub and open the water tap. Put the laundry evenly into the spin dryer basket. Set the rinse time with the Wash Timer and • Transfer the clothes from wash tub to spin feed water continuously.
- Page 18 OPERATION • Do not drain the water out of the wash tub while the spin dryer basket is in operation. Otherwise the spin motor could be damaged. • If the spin dryer basket is off- balance and vibrates excessively, stop the spinning, rearrange the clothes evenly, and then resume spinning.
-
Page 19: Maintenance Cleaning After Every Wash
MAINTENANCE MAINTENANCE Cleaning after Every Wash • Do not drop the filter on the floor. • Be careful not to get your fingernails caught in What to Clean the filter when you handle the filter. • Do not leave iron objects (such as clothes pins, •... -
Page 20: Caring The Appliance
MAINTENANCE Use a brush or your hand to remove all of the Take out the pulsator cap with "-" type screw lints which has adhered to the overflow filter. driver. Use a screwdriver to unscrew the screw in the center of the pulsator and lift the pulsator Insert the overflow filter back into the wash straight up in order to remove the button or tub. -
Page 21: Water Leakage
MAINTENANCE Firmly hold the tub by the other hand. Pull the safety cover upward. Remove the clothing. Close the safety cover, pressing down on it so that it fits securely into the spin tub. Water Leakage In case water leakage is observed, rotate Drain Selector 5-7 times. -
Page 22: Troubleshooting
You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. -
Page 23: Appendix Reference
APPENDIX APPENDIX Reference Weight Guide for Clothes Type of clothing Type of fabric Weight per piece Under Shirt Cotton 150 g (5.3 oz) Handkerchief Cotton 50 g (1.8 oz) Bath Towel Cotton 300 g (10.6 oz) Shirt Mixed Fabric 200 g (7.1 oz) Socks (1 Pair) Mixed fabric 50 g (1.8 oz) - Page 24 APPENDIX Amount of Amount of Type of Wash Wash time Amount of Water level laundry detergent fabric Selector (min.) water (l) (kg) 0.5 - 5.0 5.0 - 6.0 Heavy soils Cotton, Strong 10 - 15 6.0 - 7.0 Linen More than NOTE •...
- Page 25 Memo...
- Page 26 Memo...
- Page 27 Memo...
