- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. LG MV1608ST Owner's Manual Shop genuine replacement parts for LG MV1608ST Find Your LG Microwave Parts - Select From 955 Models -------- Manual continues below --------...
-
Page 2: Microwave Oven
MICROWAVE OVEN INSTALLATION INSTRUCTIONS PLEASE READ AND SAVE THESE INSTALLATION INSTRUCTIONS. MV1608WW MV1608BB MV1608ST MV1610ST P/NO.: 3828W5U0514... - Page 3 Your Safety First BEFORE YOU START • Proper installation is the installer's responsibility! – Read the entire manual before you begin. The model number label is located on the oven front. See Figure 1. The mounting plate is located on back side of microwave oven. See Figure 2. NOTE: Vent grille appearance varies by model.
- Page 4 Your Safety First • THIS APPLIANCE MUST BE GROUNDED! – If there is an electrical short circuit, grounding reduces the risk of electrical shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug.
- Page 5 Your Safety First • MAKE SURE YOU HAVE ENOUGH SPACE AND SUPPORT. – Mount the oven against a flat, vertical wall, so it is supported by the wall. The wall should be constructed of minimum 2" x 4" wood studding and 3/8" thick drywall or plaster/lath. –...
-
Page 6: Parts, Tools, Materials
Parts, Tools, Materials THE FOLLOWING PARTS ARE SUPPLIED WITH THE OVEN: : Depending on your ventilation requirements , you may not us e all of thes e parts . NOTE One power cord clamp and Damper/duct connector One dark-colored mounting screw (for roof venting or wall venting installation) (to hold the power cord) Not Actual Size (2 pieces must be assembled as... - Page 7 Parts, Tools, Materials YOU WILL NEED THE FOLLOWING TOOLS AND MATERIALS FOR THE INSTALLATION: Carton or other heavy material for covering the counter top. Clear tape Stud finder or thin nail. (for taping the templates to the wall) Saber saw (for cutting vent holes for roof Key hole saw (for the power cord hole) or wall venting) Electric drill...
-
Page 8: Step 1: Prepare The Electrical Connection
STEP 1: Prepare The Electrical Connection W A R N I N G AVOID ELECTRICAL SHOCK! THIS APPLIANCE MUST BE GROUNDED! 1. Locate the grounded electric outlet for this oven in the cabinet above the oven, as shown in Figure 5. Upper Cabinet NOTE: The outlet should be on a circuit dedicated to the... -
Page 9: Step 2: Prepare The Venting System
STEP 2: Prepare The Venting System NOTE: The ductwork you need for outside ventilation is not included with your oven. The standard ductwork fittings and length are shown in Figure 10, page 9. W A R N I N G THIS OVEN MUST BE PROPERLY VENTED! You may vent your oven in one of three ways. - Page 10 STEP 2: Prepare The Venting System Standard Fittings NOTE: If the existing duct is round, you must use a rectangular-to-round adapter, with a rectangular 3" extension duct installed between the damper assembly and the adapter to prevent the exhaust damper’s sticking. Duct Length The total length of the duct system, including straight duct, elbows, transitions, and wall or roof caps must not exceed 140 feet.
-
Page 11: Step 3: Prepare The Venting Blower
STEP 3: Prepare The Venting Blower Your microwave oven is shipped with the blower assembled for room (recirculating) venting. You need to adjust the blower if you want wall-vented or roof-vented installation. W A R N I N G ELECTRICAL SHOCK HAZARD! UNPLUG UNIT BEFORE WORKING ON IT. •... -
Page 12: Wall-Vented Installation
STEP 3: Prepare The Venting Blower WALL-VENTED INSTALLATION: Blower Plate Mounting Screw 1. Remove one blower unit mounting screw and one or several blower plate mounting screw(s). Remove the Blower Plate blower plate from cabinet. See Figure 13. Back Plate Blower Unit 2. -
Page 13: Roof-Vented Installation
STEP 3: Prepare The Venting Blower ROOF-VENTED INSTALLATION: Blower Plate Mounting Screw 1. Remove one blower unit mounting screw and one or several blower plate mounting screw(s). Blower Plate Remove the blower plate from cabinet. See Back Plate Figure 19. Blower Unit 2. -
Page 14: Step 4: Prepare The Wall & Upper Cabinet
STEP 4: Prepare The Wall & Upper Cabinet W A R N I N G To avoid personal injury or property damage, do not attempt to install this microwave oven if you cannot find a wall stud. Consult a carpenter or contractor. Measure And Tack/Tape Up The Templates 1. - Page 15 STEP 4: Prepare The Wall & Upper Cabinet W A R N I N G To avoid risk of personal injury, electrical shock or death: Note where electrical outlets and electrical wires are before you drill into the wall. Locate and disconnect power to any electrical circuits that could be affected by installing this oven.
-
Page 16: Step 5: Install The Mounting Plate
STEP 5: Install The Mounting Plate The Oven Must Be Connected To At Least One 3/16 Hole on Studs 5/8 Hole on Drywall Only Wall Stud. " Minimum 66 From the Floor 1. Draw a vertical line on the wall at the center of the 30" wide For Wall- space. - Page 17 STEP 5: Install The Mounting Plate For Wall-Vented Make the box cutout for the rear wall duct. – 1-piece mounting plate: Using a pencil, put dots through slots F and G, and through holes H and I. Remove the mounting plate and draw lines extending through the points.
-
Page 18: Step 6: Attach The Oven To The Wall
STEP 6: Attach The Oven To The Wall W A R N I N G To avoid risk of personal injury or property damage, you will need two people to install this microwave oven. 1. Carefully lift microwave oven and hang it on support tabs (See Figure 28) at the bottom of the mounting plate.Reaching through upper cabinet, thread Power Cord... - Page 19 STEP 6: Attach The Oven To The Wall 5. Roof venting installation: See Figure 34. Install ductwork through the vent opening in the upper cabinet. Complete the venting system through the Damper roof according to the method needed. See Prepare The Venting System STEP 2.
- Page 21 Printed in China...
