Summary of Contents for Powerhorse 5849345
- Page 1 4-Stroke Gasoline Post Driver Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item # 5849345...
- Page 2 Thank you very much for choosing a Powerhorse product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code (if applicable): _____________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Introduction ....................... 错误!未定义书签。 Features ........................错误!未定义书签。 Specifications ............................5 Safety Warnings ..........................5-6 Preparations for use.......................... 6-8 Operation Instructions ........................8-9 Service and Maintenance ....................... 9-11 Maintenance Schedule ........................12-13 Parts Breakdown ........................... 14-17 Limited Warranty ..........................18... -
Page 4: Introduction
FEDERAL EMISSION INFORMATION Powerhorse warrants to the retail purchaser, that this small, off-road engine was designed, built and equipped to conform at the time of manufacture to all applicable regulations of the U.S. Environmental Protection Agency (EPA) when applicable. -
Page 5: Specifications
Specifications Property Specification Engine type 4-stroke, over herd value, single cylinder forced air cooling Fuel unleaded gasoline or higher Displacement 37.7cc Max. Power and speed 1.0kw/6500r/min Fuel tank capacity 0.17 us gal Fuel consumption rate 0.15 US gal/hr Impact Frequency 1700-1900 RPM Starter system Handle-pull start... -
Page 6: Preparations For Use
13. Never let your post driver run unattended, and keep unauthorized persons away from the operation area. 14. While operating the post driver, be sure the contact surface of the post is smooth and flat and the diameter of the post is within the limit of the post driver barrel (3.15”). 15. - Page 7 Adding Fuel 1. Always turn the engine off and allow adequate time for it to cool before refueling. Only use unleaded fuel with 86 octane or higher. Never refuel your driver with the engine hot, running, or in an unventilated area. Fuel vapors are extremely flammable and can cause severe injury or death if ignited by a spark or excessive heat from a hot engine.
-
Page 8: Operation Instructions
The recommended environmental temperature range of the machine is 5° to 10 5 ° F. We recommend the use of SAE 10W-30 engine oil, which equals to API classification SJ. Checking the Air Filter Remove the air filter cover, and check to see if the air filter is clean. If it is dirty, clean it. 2. -
Page 9: Service And Maintenance
Operating 1. After the engine is started, ALLOW IT TO IDLE FOR 5 MINUTES BEFORE USE. For a brand new driver, ONLY PERFORM LOW TO MEDIUM-SPEED WORK FOR THE FIRST 24 HOURS OF USE in order to break in the engine and prolong the life of the machine. For a brand new driver, it may take 2 to 3 minutes of post driving for the machine to begin running at a normal performance level. - Page 10 Fuel Filter Maintenance If the fuel filter is blocked, the post driver will have reduced speed and weaker impact energy. Open the tank lid. Remove the fuel filter from the fuel tank and clean it. 3. When cleaning the fuel filter, clean the fuel tank at the same time as shown below. Carburetor Maintenance The fuel tank and the carburetor generally have residual fuel.
- Page 11 Replacing Engine Oil Dirty engine oil will result in reduced service life of moving engine parts. It is necessary to regularly replace engine oil and keep engine oil at proper levels. Replace engine oil every 6 months or after 50 hours of operation. Drain the oil when the engine is hot to guarantee that engine oil can be emptied quickly and completely.
-
Page 12: Maintenance Schedule
Maintenance Schedule This schedule is based on operating the post driver under normal conditions. Under more strenuous conditions, such as a dusty environment or long work hours, the maintenance cycle should be adjusted accordingly. Outlook Check (state, √ √ tightness of The Whole Machine screws) Clean... -
Page 13: Troubleshooting
Troubleshooting Example 1: Difficulty starting the engine. Make sure the choke lever is in the "on" position . Remove the fuel in the tank, and replace it with fresh gasoline. Press the fuel bubble 3-4 times. 4. Check to make sure the on/off switch is in the down position. Check the fuel filter, the air filter and the spark plug . -
Page 14: Parts Breakdown
Parts Breakdown Quality engine parts explosion... - Page 15 Quality engine parts list...
- Page 16 Gasoline Post driver explosion...
- Page 17 Name Name Front cover Φ8 spring Front shroud eccentric shaft plate M8X20 hex. Socket screw Φ8 spring Hammer head M8X25 hex. Socket screw M8X40 hex. Socket screw 6201 bearing Iron head Φ22 circlip Hammer lever Big gear M5x16 screw O ringФ45XФ3 6205 bearing plate Damping gasketФ48.4XФ40.5X5 Small damping gasket...
- Page 18 NK18/20 needle bearing Gasoline post driver part lists...
-
Page 19: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Powerhorse product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year on the gasoline post driver and from date of purchase. - Page 20 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China...
