WIN-9_F Series User Manual
Foreword
Thank you for using WIN-9 series of frequency inverters of Shezhen Winner S&T
Co., Ltd. WIN-9 series of SVPWM frequency inverters feature in rated torque
output at low speed, ultra-low noise running, built-in PID function, multiple control
modes, on-line parameter adjustment monitoring, easy operation, double LED
display. They satisfy customers' demands to the extreme extend. WIN-9 includes
models for general purpose, for blower/pump, for extruder and for textile ma-
chines.
WIN-9 series of frequency inverters are suitable for most equipment driven by
motors, such as equipment in industries of paper-making, textile, food, cement,
print, plastic, metallurgy, iron and steel, etc. They are stable, accurate, reliable
and efficient in improving the power factor and saving cost. A noise filter must be
added to comply with the CE standards.
This User's Manual provides the users with the instructions on the installation, pa-
rameter setting, fault diagnosis, routine maintenance and necessary precautions.
Please read the Manual carefully before handling the inverter inorder to ensure
the correct installation and operation.
We are not going to give pre-notice for any change in the user's manual.
1
●
●

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WIN-9 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Winner WIN-9 Series

  • Page 1 WIN-9_F Series User Manual Foreword Thank you for using WIN-9 series of frequency inverters of Shezhen Winner S&T Co., Ltd. WIN-9 series of SVPWM frequency inverters feature in rated torque output at low speed, ultra-low noise running, built-in PID function, multiple control modes, on-line parameter adjustment monitoring, easy operation, double LED display.
  • Page 2 WIN-9_F Series User Manual Safety Precautions Proper transportation, installation, operation and maintenance decide the secure performance of the product. Pay attention to the safety precautions before work- ing on the product. This sign means that the mal-usage may lead to injury or fatal error. DANGER! This sign means that the mal-usage may lead to slight or medium hu- man injury or equipment damage.

  • Page 3: Table Of Contents

    WIN-9_F Series User Manual CONTENTS Chapter 1 Check the Product at Acceptance .....7 1.1 Check The Content ..............7 1.2 Model Number Designation ............7 1.2.1 Nameplate ..................7 1.2.2 Nameplate Description ..............8 1.3 Main Structure ................8 Chapter 2 Installation and Wiring .......9 2.1 Dimension ( See Appendix 1) ............
  • Page 4 WIN-9_F Series User Manual 2.6 Wiring Precaution ..............17 Chapter 3 Operation ..........18 3.1 Keypad Functions And Keypad Operation ........ 18 3.2 OPERATION MODE SELECTION ..........20 3.2.1 Operation Mode Selection .............. 21 3.2.2 Operation state and LED relation ........... 21 3.3 Test Running ................
  • Page 5 WIN-9_F Series User Manual 5.2.7 Energy Saving Control Mode ............39 5.2.8 Energy Saving Tuning ..............40 5.2.9 Frequency Detection (P073) ............41 5.2.10 Frequency Meter or Ammeter (P048) ........... 42 5.2.11 Frequency Signal Adjustment ............43 5.2.12 Jog Operation ................44 5.2.13 Jump Frequencies (P058 to P060) ..........
  • Page 6 WIN-9_F Series User Manual Chapter 6 DIAGNOSTICS ........69 6.1 Fault Display ................69 6.2 Alarm Display................72 6.3 Motor Faults................73 Chapter 7 Main Circuit Wiring........74 7.1 Input Wiring ................74 7.2 Output Wiring................75 Chapter 8 MAINTENANCE & INSPECTION ....77 8.1 Maintenance ................

  • Page 7: Chapter 1 Check The Product At Acceptance

    Please contact your supplier or contact us if there is any thing wrong. 1.2 Model Number Designation 1.2.1 Nameplate MODEL: WIN-9GF-3R7T4 INPUT: AC 3φ 380V AC3φ 3.7kW8.0A OUTPUT: ~400 Hz S/N: SHENZHEN WINNER S&T CO., LTD Nameplate Example ● ●...

  • Page 8: Nameplate Description

    WIN-9_F Series User Manual 1.2.2 Nameplate Description WIN - 9GF - 3R7 T4 Product Code Series Code Capacity Voltage Special Notice 9G general type 3R7: 3.7kW T4: 380V Blank: Standard 9P for pumps, 5R5: 5.5kW T6: 660V B: With braking Function blowers 011: 11kW...

  • Page 9: Chapter 2 Installation And Wiring

    WIN-9_F Series User Manual Chapter 2 Installation and Wiring 2.1 Dimension ( See Appendix 1) 2.2 Requirement to The Installation Place NOTE! 1. Move the inverter by holding the bottom. The inverter might fall onto your feet and hurt you if you hold its cover.

  • Page 10: Ambient Temperature

    WIN-9_F Series User Manual 2.2.2 Ambient Temperature Good ventilation ensures the good performance of the inverter. Keep the ambient temperature below 40°C when it is installed in a closed cabinet by using cooling fan or air conditioner. 2.2.3 Prevention Please cover the inverter against the dust during installation. Prevent the metal powder entering the inverter.

  • Page 11: Wiring

    WIN-9_F Series User Manual 2.4 Wiring 2.4.1 Control Circuit Terminals COM FOR X1 X5 COM V12 VG GND IG FM GND TC2 TA2 TA1 TB1 TC1 2.4.2 Main Circuit Terminals Standard 1.5~15kW Main Circuit Terminals Standard 18.5~75kW Main Circuit Terminals Standard 18.5~75kW with Brake Unit Main Circuit Terminals Above 93kW Main Circuit Terminals (with in-built choker for 220kW and above) ●...

  • Page 12: Explanation About Main Circuit Terminals

    WIN-9_F Series User Manual 2.4.3 Explanation about Main Circuit Terminals Power Input : R, S, T ● Grounding : G ● DC Common Bus: ● Connecting Motor: U, V, W ● Brake Resistor: PB ● Note: PB takes place of when there is braking function in 22 75kW inverters, 2.4.4 The Functions of Main Circuit Terminals Terminal Functions Terminal...
  • Page 13 WIN-9_F Series User Manual WIN-9F WIN-9F WIN-9F WIN-9F WIN-9F WIN-9F Note: The motor's neutral point in Y connection method cannot be grounded Phase shift capacitor is prohibited Do not connect the phase shift capacitor or LC/RC filters to the output circuit, oth- erwise, the inverter might be damaged.

  • Page 14: Wiring Terminals Of The Control Circuit

    WIN-9_F Series User Manual The cable length between the inverter and the motor: The longer the cable, the higher the carrier frequency and the greater the higher harmonics leak current on the cable. The leak current badly affects the inverter and the surrounding equipments so it must be limited to the smallest.

  • Page 15: Control Circuit Terminals Functions

    WIN-9_F Series User Manual 2.4.7 Control Circuit Terminals Functions Classi- Termi- Function Description fication Forward run/stop Forward run when closed, stop when open Reverse run when Reverse run/stop closed, stop when open Fault when closed, Multi- External fault input normal state when func- open Multi-function contact inputs...

  • Page 16: Standard Wiring

    WIN-9_F Series User Manual 2.5 Standard Wiring External External brake u nit brake r e sistor MCCB WIN-9F Motor Power Source Relay output 1 Multi- functional input terminals Relay output 2 Analogue 0 ~ 10V input FM output 4 ~ 20mA Note: 1.intends to import given voltage or electric current but P042 sets up from the parameter choosing, leave the factory setting up the mA exporting electric current...

  • Page 17: Wiring Precaution

    WIN-9_F Series User Manual 2.6 Wiring Precaution Don't install electromagnetic contactor between the frequency converter and ● motor. To disassemble or replace the motor, the input power supply must be turned ● off. The motor or power supply can be switched on/off only after the converter ●...

  • Page 18: Chapter 3 Operation

    WIN-9_F Series User Manual Chapter 3 Operation DANGER! 1. Close the terminal block's cover before giving power. Otherwise, electric shock may occur. 2. If the inverter is set to pick up after power resumption, leave it awayfrom other machines because it will restart once the power is on.
  • Page 19 WIN-9_F Series User Manual Mode Indicator LED.s (Re- mote Mode) Lights when selecting input mode from the control circuit REMOTE terminal or serial communi- cation. RUN STOP SEQ REF Display SEQ: Lights when selecting Displays set values of run command from the con- each function or monitor- trol circuit terminal or serial ing values such as output...

  • Page 20: Operation Mode Selection

    WIN-9_F Series User Manual Content LED details Description Set/Read during Run Fref Frequency reference setting/monitoring Available Fout Output frequency monitor Available Iout Output current monitor Available kWout Output power monitor Available FWD/REV run command selection Available Montr Monitor selection Available Accel Acceleration time Available...

  • Page 21: Operation Mode Selection

    WIN-9_F Series User Manual 3.2.1 Operation Mode Selection Set- Operation Method Selection Reference Selection ting Operation by run command from digital Master frequency reference from digital operator operator Operation by run command from control Master frequency reference from digital circuit terminal operator Operation by run command from digital Master frequency reference from control...

  • Page 22: Check During Test Running

    WIN-9_F Series User Manual 3.3.2 Check During Test Running During test running, please check that the motor runs smoothly in the correct direction without abnormal vibration, it runs smoothly during acceleration and de- celeration, the load is not over current and the display on the keypad correct. 3.4 Test Running keyboard 3.4 1 Operation by Control Circuit Terminal Signal The diagram below shows a typical operation pattern using the control circuit ter-...

  • Page 23: Operation By Digital Operator

    WIN-9_F Series User Manual 3.4.2 Operation by Digital Operator The diagram below shows a typical operation pattern using the digital operator. Forward Stop 20Hz Forward Run Reverse Run Power Reverse 60Hz Frequency Setting Frequency Reference Change Typical Operation Example by Digital Operator Description Key Sequence Display...
  • Page 24 WIN-9_F Series User Manual Description Key Sequence Display (4) Frequency Reference Value Change (15~60Hz) Select frequency reference ● value display. Change set value. ● Write-in set value. ● Select output frequency moni- ● tor display. (5) Reverse Run Select reverse run. ●...

  • Page 25: Operation By Control Circuit Terminal Signal

    WIN-9_F Series User Manual 3.5 Operation by Control Circuit Terminal Signal The diagram below shows a typical operation pattern using the control circuit ter- minal signals. Forward 60Hz Power ON Operation Stop Frequency Setting Operation Sequence by Control Circuit Terminal Signal Typical Operation Example by Control Circuit Terminal Signal Description Key Sequence...

  • Page 26: Chapter 4 Parameters

    WIN-9_F Series User Manual Chapter 4 Parameters WIN-9_F Parameters (P001~n108) Factory De- Function Name Description fault 0: P001 read and set, P002~n108 read only 1: P001~P034 read and set, P035~n108 read only 2: P001~P049 read & set, P050~n108 read only 3: P001~n108 read and set Parameter selection/ P001...
  • Page 27 WIN-9_F Series User Manual Factory De- Function Name Description fault Unit: 0.1V Motor rated voltage 230.0V P011 (same as Vmtr LED) (460.0V) Setting range: 150.0~255.0V (510V for 460V units) Unit: 0.1Hz P012 Maximum frequency 60.0Hz Setting range: 50.0~400.0Hz Unit: 0.1V P013 Maximum voltage 230.0V...
  • Page 28 WIN-9_F Series User Manual Factory De- Function Name Description fault Unit: 1% P031 Frequency lower limit Setting range: 0~100% Motor rated current Unit: 0.1A Range: 10~200% inverter rated current Unit kVA depen- P032 (same as FLA LED) is 1A, when setting is more than 1,000A dent Setting Characteristics...
  • Page 29 WIN-9_F Series User Manual Factory De- Function Name Description fault Multi-function input (Ter- P037 Set items are same as P035 minal S4) Multi-function input (Ter- P038 Set items are same as P035 minal S5) Set items are same as P035 Multi-function input (Ter- P039 25: Up / Down command...
  • Page 30 WIN-9_F Series User Manual Factory De- Function Name Description fault Setting Monitor Output frequency Multi-function analog P048 Output current output (AM) Output power DC bus voltage Unit: 0.01 P049 Analog monitor gain Setting range: 0.01~2.00 Unit: 1 kVA depen- P050 Carrier frequency dent Setting range: 1~6 (x2.5kHz), 7~9 (custom pattern)
  • Page 31 WIN-9_F Series User Manual Factory De- Function Name Description fault Unit: 1% P064 DC injection current Setting range: 0~100% 100% = inverter rated current Unit: 0.1 sec P065 DC injection time at stop 0.5 sec Setting range: 0.0~10.0 sec Unit: 0.1 sec P066 DC injection time at start 0.0 sec...
  • Page 32 P078 Off-delay timer 0.0 sec Setting range: 0.0~25.5 sec 0: No dB protection calculated or provided dB resistor overheat P079 1: Protection provided for installed WINNER resistor function (rH) only Unit: 1% Input phase loss detec- P080 Setting range: 1~100% tion level (SPI) When setting is 100%, this function is disabled.
  • Page 33 WIN-9_F Series User Manual Factory De- Function Name Description fault 0: Energy saving is disabled. Energy saving selection P095 (same as kWsav LED) 1: Energy saving is enabled. Unit: 0.01 kVA depen- P096 Energy saving gain K2 dent Setting range: 0.00~655.0 Unit: 1% Energy saving voltage P097...

  • Page 34: Chapter 5 Enlarged Upon The Parameters

    WIN-9_F Series User Manual Chapter 5 Enlarged upon the Parameters 5.1 PARAMETER SET-UP & INITIALIZATION Parameter Selection/Initialization (P001) The following table describes data which can be set or read when parameter P001 is set. Setting Parameters that can be set Parameters that can be read 0 (parameter read-only) P001...

  • Page 35: Automatic Fault Retry (P060)

    WIN-9_F Series User Manual opening or closing the appropriate accel/decel time selection (terminal S2, S3, S4, S5 or S6). At OFF: P019 (accel time 1) P020 (decel time 1) At ON: P021 (accel time 2) P022 (decel time 2) Parameter No. Name Unit Setting Range...

  • Page 36: Automatic Restart After Momentary Power Loss (P051)

    WIN-9_F Series User Manual 5.2.2 Automatic Restart After Momentary Power Loss (P051) When momentary power loss occurs, operation restarts automatically. Setting Description Not provided (factory default) Continuous operation after power recovery within 2 seconds 2 ** Continuous operation after power recovery within control logic time (no fault output) * Holds the operation signal to continue operation after recovery from momentary power loss.

  • Page 37: Current Limit (Stall Prevention)

    WIN-9_F Series User Manual 5.2.4 Current Limit (Stall Prevention) This function automatically adjusts the output frequency and thus output current according to the load, to continue operation without tripping the inverter. Current Limit Level During Acceleration (P071) ● The current limit level during acceleration can be set in units of 1% (inverter rated current = 100%).

  • Page 38: Dc Injection Braking

    WIN-9_F Series User Manual Motor Current n072 Time Output Frequency Time Decreases frequency to prevent the inverter from tripping. Current Limit During Running Stall prevention during deceleration (P070) ● To prevent overvoltage during deceleration, the inverter automatically extends the deceleration time according to the value of main circuit DC voltage. When using an optional braking resistor for the WIN-9_F, set parameter P070 to“1”.

  • Page 39: Energy Saving Control

    WIN-9_F Series User Manual n017 Min. Output Frequency n065 DC injection Braking Time at Stop DC Injection Braking Time at Stop When coast to stop is selected in the stopping method selection (P003),DC injec- tion braking at stop is disabled. 5.2.6 Energy Saving Control To enable energy saving control, set energy saving selection (P095) to “1”.

  • Page 40: Energy Saving Tuning

    WIN-9_F Series User Manual Voltage 255V* n097 n098 Lower Limit 60Hz Frequency * This value is doubled for 460V class inverters. Energy Saving Voltage Lower Limit 5.2.8 Energy Saving Tuning In the energy saving control mode, the optimum voltage is calculated according to load power, and the voltage is supplied to the load.

  • Page 41: Frequency Detection (P073)

    WIN-9_F Series User Manual Voltage Variation Width n101 n102 100% Output Voltage Energy Saving Voltage Variation Width 5.2.9 Frequency Detection (P073) When multi-function contact output selections P040 or P041 are set to “4”or “5”, frequency detection is enabled. This function is activated when the output fre- quency is higher or lower than the frequency detection level (P073).

  • Page 42: Frequency Meter Or Ammeter (P048)

    WIN-9_F Series User Manual Release Width Frequency Detection -2Hz Level (Hz) n073 Output Frequency Frequency Detection Signal Frequency Detection Example ( Fout ≥ Frequency detection level) 5.2.10 Frequency Meter or Ammeter (P048) This function selects between outputting either output frequency or output current to analog output terminals AM and AC for monitoring.

  • Page 43: Frequency Signal Adjustment

    WIN-9_F Series User Manual n049 setting = 3V 0.30 Output frequency becomes 100% at this value. 5.2.11 Frequency Signal Adjustment When the frequency reference is given by an analog signal at control circuit ter- minals FV and FI, the relation between analog voltage (or current) and frequency reference can be set.

  • Page 44: Jog Operation

    WIN-9_F Series User Manual Max. Output Frequency (100%) Frequency Signal Adjustment Example - 0 to 5V input Gain: Parameter P046 = “200” Bias: Parameter P047 = “0” To operate the inverter with a frequency reference of 50% to 100% at a 0 to 10V input: Max.

  • Page 45: Modbus Communication

    WIN-9_F Series User Manual Set jump frequency 1 or 2 such that P058 ≤ P059. If this condition is not satisfied, the inverter displays the parameter setting error “OPE6”. Output Frequency n059 n058 n060 n060 Frequency Reference Jump Frequencies 5.2.14 MODBUS Communication The WIN-9_F can perform serial transmission by using a programmable controller (PLC) and MODBUS communication.

  • Page 46: Motor Overload Detection

    WIN-9_F Series User Manual Data to be sent/received by communication are run commands, frequency refer- ence, fault contents, inverter status and parameter setting/reading. Operation Mode Selection (P002) ● Select the run command and frequency reference input method in parameter P002. To provide a run command and frequency reference by communication, set this parameter to settings “4”...
  • Page 47 WIN-9_F Series User Manual Applied to blower-cooled motor, short time rating (Class 10 overload) The electronic thermal overload function estimates motor temperature, based on inverter output current and time, to protect the motor from overheating. When the electronic thermal overload relay is activated, an .oL1. error occurs, shutting OFF the inverter output and preventing excessive overheating in the motor.

  • Page 48: Multi-Step Speed Selection

    WIN-9_F Series User Manual 60 sec Short time Standard Rating Effective when operated Effective when oper- Blower- at low speeds (approx. ated at low speeds cooled 6Hz). (approx. 6Hz). Frequency (Hz) Base Frequency 60Hz (V/f for 60Hz, 230V Input Voltage) Use blower-cooled motor for continu- ous operation at low speeds.

  • Page 49: Phase Loss Protection

    WIN-9_F Series User Manual FWD Run/Stop REV Run/Stop External Fault Fault Reset Multi-function Contact Input Multi-step Speed Ref. 1 Multi-step Speed Ref. 2 Multi-step Speed Selection - Control Circuit Terminals (n028) Frequency 60.0Hz Reference (n027) 50.0Hz (n026) 40.0Hz (n025) 30.0Hz Multi-step Speed Ref.

  • Page 50: Pid Control

    WIN-9_F Series User Manual Unit: 1% P080 Input phase loss detection level Setting range: 1 to 100% of input voltage Unit: 1 (1.28 s) Input phase loss detection delay P081 8 (10.24 s) time Setting range: 2 to 255 (2.56 to 326.4 s) Input phase loss detection is disabled in the following cases: - Parameter P080 is set to .100%..
  • Page 51 WIN-9_F Series User Manual Intended Value Setting ● The control circuit terminal FV voltage signal (0 to 10V) or multi-step speed pa- rameters P025 to P029 can be used to set the PID intended value. Control circuit terminal FV voltage signal: Set operation mode selection (P002) to“2”or“3”.

  • Page 52: Reverse Run Prohibit (P006)

    WIN-9_F Series User Manual the integral time, output lag filter time, etc., decrease the set value of pa- rameter P090. 3. PID control can be canceled by a multi-function contact input signal. By setting any of parameters P035 to P039 to .19. and by closing the con- tact during running, PID control is disabled and the intended value signal itself is used as a frequency reference signal.

  • Page 53: Speed Limit Adjustment

    WIN-9_F Series User Manual FWD Run Command REV Run Command Acceleration Deceleration DC Injection Braking Time at Stop Min. Output Frequency n065 n017 Output Frequency Min. Output Frequency n017 Acceleration Deceleration S-curve Characteristics - FWD/REV Operation 5.2.20 Speed Limit Adjustment Internal Frequency Frequency Reference...
  • Page 54 WIN-9_F Series User Manual Setting Description Deceleration to stop (factory default) Coast to stop Coast to stop with timer 1 (run command cycle) Coast to stop with timer 2 (auto-start after time out) Deceleration to Stop (P004 = “0”) ● Output Frequency Decel time 1 (n020) Min.
  • Page 55 WIN-9_F Series User Manual Output Frequency Decel Time 1 (n020) Accel Time 1 (n019) Coasting Time FWD (REV) Run Command Run Command Disabled Example of Stopping Method - Coast to Stop w/ Timer 1 A run command is not accepted while the motor decelerates after a stop command is given.

  • Page 56: Torque Adjustment (P067)

    WIN-9_F Series User Manual 5.2.22 Torque Adjustment (P067) Motor torque can be adjusted by changing the V/f pattern (P010) or by adjusting the torque compensation gain (P067). For details on setting the V/f pattern, see .V/f Pattern Adjustment., on page 74. Full-range Automatic Torque Boost ●...
  • Page 57 WIN-9_F Series User Manual To output an overtorque detection signal, set multi-function contact input selection P040 or P041 to “6” (N.O. contact) or “7” (N.C. contact). Inverter Rated Current Motor Current n075 Time Multi-function Contact Output Signal (Overtorque Detection Signal) Terminal MA, MB, M1 n076 n076...

  • Page 58: Tripless Operation

    WIN-9_F Series User Manual (P075) is longer than the overtorque etection time (P076), the overtorque detec- tion function is enabled. 5.2.24 Tripless Operation When starting into a coasting motor, use the speed search command or DC injec- tion braking at start, to prevent a drive trip and motor burnout. Speed search ●...

  • Page 59: V/F Pattern Adjustment

    WIN-9_F Series User Manual n017 Min. Output Frequency n066 DC Injection Braking Time at Start DC Injection Braking at Starting 5.2.25 V/f Pattern Adjustment Set the V/f pattern using parameter P010 as described below. It may be neces- sary to change the V/f pattern when using a high-speed motor, or when special torque adjustment is required in the application.

  • Page 60: Preset V/F Patterns

    WIN-9_F Series User Manual 5.2.26 Preset V/f Patterns Specifications n010 V/f Pattern *1 Specifications n010 V/f Pattern *1 Starting Torque 50Hz 50Hz High Starting Torque (Hz) (Hz) 0 1 .3 2 .5 0 1 .3 2 .5 60Hz Satur- Starting ation Torque 60Hz...

  • Page 61: Inputs & Outputs

    WIN-9_F Series User Manual Custom V/f Pattern ● Set up a custom V/f pattern by setting parameter P010 to .F., and then setting the values in parameters P012 to P018. Voltage Be sure to satisfy the following conditions for setting parameters n012 to n018: n013 n017 ≤...
  • Page 62 WIN-9_F Series User Manual · Terminal S3 function: set to P036 · Terminal S4 function: set to P037 · Terminal S5 function: set to P038 · Terminal S6 function: set to P039 Set- Name Description ting REV run command (2-wire sequence) Only parameter P035 can be set to this value.
  • Page 63 WIN-9_F Series User Manual * 2 to 6 are displayed in_corresponding to S2 to S6, respectively.Factory settings:P035=0,P036=2,P037=4,P 038=9,P039=10 FWD Run/Stop REV Run/Stop Terminal Function at 2-Wire Sequence Selection (setting:“0”) Run Command (Run when “Closed”) Stop Command (Stop when “Open”) FWD/REV Run Selection (FWD Run when “Open”...
  • Page 64 WIN-9_F Series User Manual Closed: run by frequency reference and run command from serial communica- tion. Timer Function (setting: 20) ● When the timer function input is longer than the ON-delay timer (P077), the timer function output closes. When the timer input is open for longer than the OFF-delay timer (P078), the timer function output opens.

  • Page 65: Procedure

    WIN-9_F Series User Manual Control Circuit Terminal S5 (UP command) Closed Open Open Closed Control Circuit Terminal S6 (DOWN command) Open Closed Open Closed Operation Status Accel Decel Hold Hold FWD Run UP Command S5 DOWN Command S6 Upper Limit Speed Lower Limit Speed Output Frequency D1 H...

  • Page 66: Analog Input Signals (P042 To P045)

    WIN-9_F Series User Manual 1Set multi-function contact input selection (P039) after turning ON the in- verter power supply, then turn OFF the inverter power supply. 2Short-circuit terminal S6 to terminal SC and connector 2CN pin 1 to pin 2. (Do not short-circuit when connecting the communication interface card SI- K2/P.) Begin the loop test by turning ON the inverter power supply.

  • Page 67: Multi-Function Output Signals (P040, P041)

    WIN-9_F Series User Manual Detection disabled (factory default) Detection enabled, continue to run at 80% of previous Fref. If the frequency reference decreases by 90% within 400ms (when detection is en- abled), operation continues at 80% of the reference reached before the rapid de- crease.
  • Page 68 WIN-9_F Series User Manual Set- Name Description ting Detects a rapid decrease in feedback and outputs a contact when the PID control mode is set. Detects when the feedback PID feedback loss value decreases less than the detection level (P093) for longer than the feedback loss detection delay time (P094);...

  • Page 69: Chapter 6 Diagnostics

    RESET key on the digital operator, or cycle power to reset the stop status. If taking the corrective actions described does not solve the problem, contact your WINNER representative immediately. Fault Diagnosis and Corrective Actions...
  • Page 70 WIN-9_F Series User Manual Fault Name Description Corrective Action Display The transistor heatsink temperature exceeded the allowable value *oH1 Heatsink overheat (OH1) (Fin temperature > OH1 detection level). Check the fan and ambient temperature. The transistor heatsink temperature exceeded the allowable value Heatsink overheat (OH2) (Fin temperature >...
  • Page 71 WIN-9_F Series User Manual Fault Name Description Corrective Action Display · Transmission between the inverter and digital operator is established · Insert the digital operator Control circuit fault 2 once after supplying power, but connector again. · Check the CPF1 (CPF1) Digital operator later trans-mission fault continues digital control circuit wiring.

  • Page 72: Alarm Display

    WIN-9_F Series User Manual 6.2 Alarm Display Unlike faults, alarms do not activate fault contact outputs. After the cause of the alarm is corrected, the inverter returns to its former operation status automatically. Alarm Display and Explanations Alarm Display Contents Explanation Uu (blinking) Undervoltage detection...

  • Page 73: Motor Faults

    If a motor fault occurs, follow the checkpoints listed in the table below and take the corresponding corrective actions. If taking the corrective actions described does not solve the problem, contact your WINNER representative immediately. Motor Faults and Corrective Actions...

  • Page 74: Chapter 7 Main Circuit Wiring

    WIN-9_F Series User Manual Chapter 7 Main Circuit Wiring 7.1 Input Wiring 3Φ AC MCCB WIN- 9_F Ancillary equipment connection layout Molded-Case Circuit Breaker (MCCB) ● Be sure to connect MCCB’s or fuses between the AC main circuit power supply and WIN-9_F input terminals L1, L2 and L3, to protect wiring.

  • Page 75: Output Wiring

    WIN-9_F Series User Manual side. However, frequent switching may cause the inverter to malfunction. When using a braking resistor unit, use a sequencer to break the power supply side of the inverter in the event of an overload relay trip contact. If the inverter malfunctions, the braking resistor unit may be burned out.
  • Page 76 WIN-9_F Series User Manual If the total wiring distance between inverter and motor is excessively long and the inverter carrier frequency (IGBT switching frequency) is high, harmonic leakage current from the wiring will adversely affect the inverter and peripheral devices. If the wiring distance is long, reduce the inverter carrier frequency as described be- low.

  • Page 77: Chapter 8 Maintenance & Inspection

    WIN-9_F Series User Manual Chapter 8 MAINTENANCE & INSPECTION DANGER! 1) Never touch high voltage terminals in the inverter. 2) Replace all protective covers before powering up the inverter. When removing the cover, be sure to shut OFF the power supply to the inverter. 3) Perform maintenance or inspection only after verifying that the charge LED has gone OFF, after the main circuit power supply is turned OFF.

  • Page 78: Regular Maintenance

    WIN-9_F Series User Manual Daily check point: What to Where to check How to check Criteria check According to the Display LED monitor Any display error? running status Cooling Is there strange noise? Does it run Cooling fan Normal system smoothly? Is there temperature rise, strange Body...
  • Page 79 WIN-9_F Series User Manual cally driven wattmeter. Please use the oscilloscope whose scan frequency is greater than 40 MHz to test the waveform. Oscilloscope whose scan frequency over 100 MHz is recom- mended for measuring transient waveform. Electric isolation must be done before measure.

  • Page 80: Components Which Should Be Changed Regularly

    WIN-9_F Series User Manual cuit, R, S, T, U, V, W, P, N etc. main circuit terminals must be short circuited and be measured by megaohm meter. (250V meter for 220V inverter, 500V for 380V inverter, 1000V for 660V inverter). Do not measure the control circuit with a megaohm meter.

  • Page 81: Chapter 9 Warrantee

    WIN-9_F Series User Manual Chapter 9 Warrantee The warrantee period for the inverter itself is 12 months from the delivery date and no longer than 24 months since the manufacture date marked on the nameplate. Repair service is charged even in warrantee period if the failure is caused by the following occasion: Improper operation, repair or alternation without our permission;...
  • Page 82 WIN-9_F Series User Manual Vehicles Medical equipment Nuclear, electricity equipment Aviation equipment Security equipment Other special equipment Your complaint or suggestion on the design, performance, quality and service about our product will be appreciated. ● ●...

  • Page 83: Appendix 1 Installation Dimension

    WIN-9_F Series User Manual Appendix 1 Installation Dimension 5 0 . 0 0 3 8 8 R E V J O G STOP RESET R E V J O G STOP RESET CAUTION -Read the instruntion manal. CAUTION -Disconnect power and ensure "CHARGE"indicator LED is off -Read the instruntion manal.
  • Page 84 WIN-9_F Series User Manual WIN-9_F-T4 Series Wall-hanging type Model Code WIN-9_F - 1R5~3R7T4 — WIN-9_F - 5R5 _ 7R5T4 — WIN-9_F - 011~015T4 / 9P-018T4 WIN-9_F - 018~030T4 WIN-9_F - 037T4 WIN-9_F - 045T4 / 9P-055T4 WIN-9_F - 055~075T4 WIN-9_F - 093~132T4 / 9P-160T4 WIN-9_F - 160~200T4 1140 1110 1072 WIN-9_F - 220~400T4...

  • Page 85: Appendix 2 Win-9_F Technical Specification

    WIN-9_F Series User Manual Appendix 2 WIN-9_F technical specification Item Specification Output rated voltage Max. output voltage is the same as the input power supply voltage Suitable motor power (kW) 1.5 2.2 3.7 5.5 7.5 15 18.5 22 93 110 Output rated current (A) 4.8 6.2 96 128 165 180 224...

  • Page 86: Appendix 3 Digital Operator Monitor Display

    WIN-9_F Series User Manual Appendix 3 Digital Operator Monitor Display Name Description Frequency reference can be monitored/set. ● Fref Frequency Reference Setting/display unit depends on display mode (P024). ● Output frequency is displayed. ● Fout Output Frequency Display unit depends on display mode (P024). ●...
  • Page 87 WIN-9_F Series User Manual Name Description Input terminal status is displayed (terminals S1 to S6). |||||||| 1: S1 closed 1: S2 closed U-07 1: S3 closed 1: S4 closed 1: S5 closed 1: S6 closed Always blank Inverter status is displayed. ||_||||| Montr Monitor...
