Summary of Contents for Positive Grid Spark NEO
- Page 1 Spark NEO User Manual...
- Page 2 Guitar & Bluetooth audio up to 6 hours playtime Head band INCLUDED IN THE BOX 70° Silica gel cover 70° Silica gel BOX CONTENTS Bridge Spark NEO Headphone Plastic Wireless Transmitter Bridge Cap USB-C Cable Plastic Quick Start Guide Hinge...
- Page 3 Spark NEO Control Panel (A) Preset Selector Press the preset button to select one of four presets on Spark NEO. These presets can also be customized in the Spark app. (B) Guitar Volume Control (- / +) Adjust the guitar volume. *only controls guitar volume ...
- Page 4 Spark NEO Transmitter Button Behaviour System Overview (A) Unlatched Button (B) PWM RGB Led (C) Pin-Hole reset button (D) USB-C Wireless Transmitter Technical Specifications Frequency Range: 2.4GHz Sample Rate: 24-bit, 48kHz Frequency Response: 20Hz - 20kHz Distortion (THD+N): • Less than 1% at 0.57Vrms input (1KHz) •...
- Page 5 Music Input (Bluetooth Audio) • Spark NEO accepts Bluetooth Audio to stream the music. • Bluetooth Audio In will be prior to all the inputs. LED Indicator Status...
-
Page 6: Factory Reset
Power/Pair or Preset button. Force Shutdown & Restart If Spark NEO runs into an issue where the knobs/buttons doesn't respond anymore or freezes, or emits a high pitched or unusual noise, follow the steps below to force shutdown and restart Spark NEO. - Page 7 For Spark NEO TX： The FCC SAR limit is 1.6 W/kg, with a maximum SAR value of 0.157 W/kg when testing the device for use on the body. The device was tested at 0 mm and meets RF exposure requirements.
