XACT N1 ETHERNET SWITCH
USER'S MANUAL
I.
Introduction
The
XACT
N1
is
a
high-end
Ethernet
switch
specifically designed for audio applications. It
is optimized to enhance the sound quality of audio
systems that stream music or are controlled over
an Ethernet network.
Please make sure to read this user manual carefully
before connecting or operating the product.
While the XACT N1 delivers outstanding performance
right out of the box, its full sonic potential
typically emerges after a break-in period of 100
to 150 hours of operation.
Advertisement
Summary of Contents for Xact N1
- Page 1 Ethernet network. Please make sure to read this user manual carefully before connecting or operating the product. While the XACT N1 delivers outstanding performance right out of the box, its full sonic potential typically emerges after a break-in period of 100...
-
Page 2: Specification
Specification Ports 1G/100M RJ45 Auto negotiate SFP 1G 1G RJ 45 (100M limited compatibility) Isolated Max Power Consumption 15 W Standard Operating Temperature 0 to + 40 °C Storage Temperature -40 to +85 °C Mains Voltage 115, 230 ± 5% V Mains Frequency 48 to 63 Hz Fuse... - Page 3 III. Package Contents § N1 Ethernet switch § User manual WARNING! IMPORTANT SAFETY INFORMATION § Prior to use set correct mains voltage (230 or 115V) with voltage selector switch located on back panel of device. Incorrect setting may damage your switch. NEVER operate voltage selector switch when AC power is connected.
- Page 4 Compatibility The XACT N1 was designed with absolute sound quality as the top priority. As a result, certain compatibility limitations may apply. Modern network devices generally work without issues. However, some standard features — such as energy-saving protocols — have been disabled to optimize audio performance, which may affect compatibility with older devices.
- Page 5 The SFP port is part of the main LAN circuitry and shares a common ground with the standard LAN ports. A typical use case for the N1’s SFP port is connecting it to an SFP-capable router via a fiber optic cable. In most routers, SFP ports are...
- Page 6 VII. Switch Installation 1. Placement : Ensure the switch is in a well- ventilated area. Do not block the ventilation holes. 2. Voltage Check : Set the voltage selector (on the back of the power supply) to match your local mains voltage before connecting to AC power.
- Page 7 VIII. Operation After completing all network connections, connect the switch to an AC power source. The XACT N1 will power up automatically and complete its initial configuration within a few seconds. Once configured, the switch will operate normally. Please note: The N1’s main processor powers off 15...
- Page 8 AC power to reinitialize its configuration. If the issue persists, please visit www.xact.audio for further support or contact us directly at contact@xact.audio . Warranty The XACT N1 is covered by a 24-month warranty from the date of purchase.
- Page 9 During the warranty period, XACT will repair or replace any defective components with parts of equal or superior performance, provided that the following conditions are met: The product is returned to XACT, with • shipping costs covered by the customer.
