Digi-Code DC-GN3 Manual

4. P ress and release the same remote button and the status LED will blink red and the
opener will activate.
Replacing the Battery
Replacing the battery will not affect the programming of the remote.
1. T ake note of the battery cable and battery position before removing. New battery
must be installed in the same position
2. Remove the battery cover and unclip the battery from the connector.
3. Clip a new 9V battery to the connector.
4. P lace the battery in the cradle and press down. After seating the battery, reapply the
cover.
Erase All Remotes from your Garage Opener
Intellicode 1 Type: Press and hold the LEARN button on the garage door opener. After 6
seconds the light above the button will turn off. Once the light is turned off your opener
will be cleared of all previous remote connections.
Intellicode 2 Type: Press and hold the Program/Set button until the round LED turns blue,
then release. Press and hold the Up (+) and Down (-) buttons at the same time, until both
LED turn blue and flashing and then turn off. The opener is now cleared of all remotes.
Warranty
All Digi-Code door related products carry an eighteen (18) month warranty against
defects in workmanship or material. This warranty begins on the date of manufacture, for
eighteen months. Digi-Code warrantees our product only to our authorized dealers and
distributors, and not to the end customer. If you have any questions about our warranty,
please ask your dealer to determine the nature and scope of their warranty. Digi-Code
does not assume, and is not responsible for, any real or consequential damages from
claims against the performance of our product, nor is it liable for any costs related to
the loss of life, property, or revenue. Further, Digi-Code is in no way responsible for the
installation of our product and will assume no cost related to reinstallation or removal.
Digi-Code's warranty is in lieu of all other warrantees, expressed, or implied.
CAUTION: Any changes or modifications in intentional or unintentional radiators which
are not expressly approved by Digi-Code USA Inc. could void the user's authority to
operate this equipment. This applies to intentional and unintentional radiators certified
per part 15 of the FCC rules and regulations.
DIGI-CODE USA, INC.
Part # 72-DC-GN3
DC-GN3 Genie Replacement Garage Door Remote
Section 1
Determine the Model of Your Genie Opener
Use the images below to determine which type of Genie garage opener you have.
DC-GN3 Labeled Diagram
Intellicode 2 2010-Present –
Go to Section 3
Intellicode 1 1995-Present – Go to Section 2
Pre-1995 and 9 & 12 Code Switch
- Go to Section 4 for 9 Dip Switch Trinary
- Go to Section 5 for 12 Dip Switch Binary
- Go to Section 6 for 9 Dip Switch Binary
