Designed for Fan and Pump Applications
Thank you for purchasing our FRENIC-Eco series of inverters.
• This product is designed to drive a three-phase induction motor. Read through this supplement in
conjunction with the instruction manual (INR-SI47-1059-E) and be familiar with the handling procedure for
correct use.
• Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as
the motor.
• Deliver this supplement to the end user of this product. Keep this supplement in a safe place until this
product is discarded.
• For how to use an optional device, refer to the installation and instruction manuals for that optional device.
Fuji Electric Systems Co., Ltd.
200 V class series
90 kW: FRN90F1S-2
110 kW: FRN110F1S-2
400 V class series
280 kW: FRN280F1S-4
to
560 kW: FRN560F1S-4
Supplement for High-Capacity Inverters
Instruction Manual
INR-HF52250b-E
