Summary of Contents for The Handy H20S
- Page 1 MANUAL EDGER HANDY Instructions for use and maintenance Ed. 1.2 Standard models: HANDY 20 - H20 - H30 - H34 Models with sensor for automatic Start/Stop: HANDY 20S - H20S - H30S - H34S R.O.M. s.p.a. Ricerca Ottico Meccanica...
- Page 2 HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Foreword Congratulations for having chosen a R.O.M. free-hand edging system. We recommend become familiar with your new manual edger to work safely. To this end, read these instructions carefully before use; they will...
-
Page 3: Table Of Contents
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Contents 4.2.2 Preparing the HANDY edger with solenoid valve..9 4.2.2.1 Upwards rotation ..........9 CAP. -Contents .............. 3 4.2.2.2 Downwards rotation......... 10 4.2.3 Preparing the HANDY edger with tray .... -
Page 4: Cap. 1 -General Information
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S General information 1.3.1 Glossary • OPERATOR: the person or persons given the task of installing, operating, adjusting, maintaining, cleaning, Using the instruction manual repairing or transporting the machinery (Annex I, 1.1.1 - This manual is an integral part of the line and provides all the Directive 89/392/EC);... - Page 5 HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Description of the machine and technical data Machine versions and optional VERSIONS MODEL GRIT D25/64 D12/25F D12/25M * For the disk with grinding segment, we recommend using version E or P Structure of the machine As of October 2006, the lower fuse holder (H) has been eliminated on all models.
-
Page 6: Description Of The Machine
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Description of the machine Do not wear clothes that could get caught (ties, bracelets, necklaces). The HANDY manual edger is a patented machine for... -
Page 7: Cap. 4 -Instructions For Installation
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Instructions for installation Installation Place the edger on a flat and solid surface and leave enough The installation of the HANDY edger is at the charge of the user. -
Page 8: Downwards Rotation
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S • Place pump (E) into tank (F); fill the tank with water and place it underneath the HANDY edger at max 60cm from the same. -
Page 9: Preparing The Handy Edger With Solenoid Valve
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S 4.2.2.1 Upwards rotation To prepare the machine for use, proceed as follows: • Remove case (A) using the pliers (B) provided. Op009010 Fig. 2.14 - Water leve •... -
Page 10: Downwards Rotation
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S • Insert the bottom end of the drain pipe into the decantation • Check that sponge (C) (40x21x15 mm) is present in its seat;... -
Page 11: Preparing The Handy Edger With Tray
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S • Insert the feeding pipe (F) in the feeding fitting. Screw this fitting on the threaded part of the water tap. Before screwing the fitting down, check that the seal is fitted. -
Page 12: Downwards Rotation
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S 4.2.3.2 Downwards rotation To prepare the machine for use, proceed as follows: • Insert sponge (A) (60x41x21 mm) in seat (3). Op009023 Fig. 2.34 - Case assembly •... -
Page 13: Edger With Solenoid Valve
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S 5.1.2 Edger with solenoid valve In case of a power failure while the motor is working, when the power is restored the motor will not automatically restart; it is Before starting using the machine, check that the water system necessary to turn the On switch (A) Fig. -
Page 14: Final Operations
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Changing water (edger with pump) We recommend changing the water in the pump tank (A) at regular intervals. Op009027 Fig. 2.39 - Cooling adjustment Op009030 The edger is ready for use. -
Page 15: Maintenance Of The Diamond Disk
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Electrical maintenance Maintenance of the diamond disk When necessary, re-sharpen the diamond disk with the special 6.5.1 Changing the fuses stick supplied with the machine. -
Page 16: Cap. 7 -Troubleshooting
HANDY 20 - H20 - H30 - H34 / 20S - H20S - H30S - H34S Troubleshooting This section will help you solve the most common problems which can be encountered when using the HANDY edger. Problem Cause Solution Main switch turned to OFF Turn the main switch to position ‘I’... - Page 17 R.O.M. s.p.a. Ricerca Ottico Meccanica Strada delle Seriole, 14 47894 Chiesanuova (RSM) PH: 00 39 (0) 549/999558 FX: 00 39 (0) 549/999478...
-
Page 18: Spare Parts Catalogue
Ed. 1.3 Ed. 1.3 MANUAL EDGER Spare parts catalogue HANDY R.O.M. s.p.a. Ricerca Ottico Meccanica... - Page 19 BASE & COVER COVER WITH SENSOR SCREW COVER W/O SENSOR SCREW RESERVOIR CUP BODY VERSION SOLENOID VALVE BODY VERSION PUMP AND TANK BODY VERSION...
- Page 20 SHAFT-SUPPORT & BEARING ASSY COVER-RESERVOIR CUP VERSION 17 COVER-SOLENOID VALVE PUMP & TANK VERSION...
- Page 21 ELECTRIC MOTOR 230 V 50Hz ASSY 1 TRV 9 230 V 50Hz ASSY 1 TRV 9...
- Page 22 START/STOP SENSOR CAPACITOR 8 Mdf 450V (32X55) CAPACITOR 10 Mdf 450V (36X68) CAPACITOR 30 Mdf 450V (40X92) K I T...
- Page 23 MAIN PLATE & SENSOR BOARD - FUSE & CABLE K I T...
- Page 24 SOLENOID VALVE...
- Page 25 WATER PUMP & TANK K I T K I T...
- Page 26 DIAMOND WHEELS HANDY H34 HANDY H34 F HANDY H34 CODE : 0352062200 CODE : 0352064200 CODE : 0352062800 GRIT 22mm : D12 GRIT 15mm : D12 GRIT 22mm : D25 GRIT 12mm : D25 GRIT 19mm : D25 GRIT 22mm : D64 POLISH FINISH POLISH...
- Page 27 R.O.M. s.p.a. Ricerca Ottico Meccanica Strada delle Seriole, 14 47894 Chiesanuova (RSM) - Italy PH: 00 39 (0) 549/999558 FX: 00 39 (0) 549/999478...
