- Page 1 452cc Electric Start Brush Mower Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item 5883228...
- Page 2 Thank you very much for choosing a Powerhorse product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code (if applicable): _____________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ..........................4 Packaging Contents ......................... 5 Technical Specifications ......................5 Important Safety Information ....................5 Specific Operation Warnings ....................8 Fuel Safety ..........................9 Main Parts of Product ......................11 Assembly Instructions ......................12 Before Each Use ........................16 Operating Instructions ...................... -
Page 4: Intended Use
Intended Use The Power Horse brush mower is a versatile and powerful tool designed for outdoor maintenance and landscaping tasks. The primary uses is for cutting through thick vegetation, such as tall grass, weeds, and small brush, to create a finished appearance. This Power Horse brush mower is capable of clearing overgrown areas such as gardens, parks, public spaces, and agricultural fields. -
Page 5: Packaging Contents
Packaging Contents Main Body (1) Handle (1) Technical Specifications Property Specification Engine 14HP Electric Start,452cc, OHV Engine Power Gasoline/Petrol Belt Drive and Blade, A belt Blade 1PC Blade packing size 55 X 28 X 26.2in Gross weight 288lbs Net Weight 228lbs Blade width... - Page 6 work of larger industrial equipment. There are certain applications for which this equipment was designed. This product will be safer and do a better job at the capacity for which it was intended. DO NOT use this equipment for a purpose for which it was not intended.
- Page 7 Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people, their property, and themselves. Always wear protective goggles or safety glasses with side shields while using the equipment to protect your eyes from possible thrown debris. Avoid wearing loose clothing or jewelry, which can catch on moving parts.
-
Page 8: Additional Information And Potential Changes
Additional Information and Potential Changes We reserve the right to discontinue, change, and improve its products at any time without notice or obligation to the purchaser. The descriptions and specifications contained in this manual were in effect at printing. Equipment described within this manual may be optional. -
Page 9: Fuel Safety
It may be helpful to better familiarize yourself with the features of your equipment before beginning the steps outlined in this chapter. Your equipment is a powerful tool, not a plaything. Exercise extreme caution always. Do not use it for any other purpose except its designed purpose. Know how to stop the equipment quickly. -
Page 10: A Note To All Users
Gasoline is a highly flammable liquid. Gasoline also gives off flammable vapor that can be easily ignited and cause a fire or explosion. Never overlook the hazards of gasoline. Always follow these precautions: Never run the engine in an enclosed area or without proper ventilation as the exhaust from the engine contains carbon monoxide, which is an odorless, tasteless, and a deadly poisonous gas. -
Page 11: Main Parts Of Product
Main Parts of Brush Mower Subassembly Main Body Handle Assembly Instructions... -
Page 12: Assemble Instruction
Assemble Instruction Handle assembling: Hold the handle frame and align the handle holes to the holes on the frame. Secure the handle to the frame with the bolts. Cable connection: Connect the plug from engine to the plug from battery. - Page 13 Secure the Cables to the Handlebars with the Cable Ties. Cut off the excess from the Cable Ties using Wire Cutters. Starting Position your equipment on flat, dry ground. Make sure the fuel shut-off valve is in the “ON” position. Turn and hold the Key in the start position until engine starts.
-
Page 14: Blade Engagement
Blade Engagement Gently squeeze “Blade Engagement Lever” to engage. Release the “Blade Engagement Lever” to stop the blade rotating. Engine Stopping Turn the Key to the OFF position. NOTICE Do not cut brush or saplings more than 50mm in diameter. Obstacle Tips Warning The engine's power can easily throw stones, sticks, and other debris up to 100 feet at... -
Page 15: Slope Operation
Slope Operation Warning When operating the equipment over uneven terrain or slopes, use extreme caution not to tip the machine over. Never use the equipment on slopes greater than 20 degrees. Doing so could result in serious injury or damage to your machine. If you mow on sloping terrain, mow across the slope, not up and down, for better control. -
Page 16: Before Each Use
Before Each Use ⚠WARNING The mower must be operated safely to prevent or minimize the risk of minor or moderate injury. Unsafe operation can create several hazards for you. Always take the following precautions when operating this mower: Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people, their property, and themselves. -
Page 17: Maintenance
Maintenance ⚠WARNING Regular maintenance is the way to ensure the best performance and long life of your machine. Please refer to this manual and the engine manufacturer's user manual for maintenance procedures. Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool. -
Page 18: Changing The Engine Oil
Changing the Engine Oil 1. Remove the “Engine Oil Fill Cap”. 2. Remove the “Engine oil drain bolt”. 3. When the Engine Oil is completely drained, reinstall the “Engine oil drain bolt”. 4. Fill enough Engine Oil from the position of “Engine oil fill cap”, and reinstall the fill cap. -
Page 19: Removing And Replacing The Blade
Notice: Use above steps still cannot remove the belt A1448, please remove the “Belt Cover” by unscrewing the 4 screw which fasten the cover to the frame to change the Belt A1448. Removing and Replacing the Blade 1. Push Down the handlebar to see the blade system. 2. -
Page 20: Troubleshooting
Troubleshooting ⚠WARNING Most problems are easy to fix. Consult the Troubleshooting Table below for common problems and their solutions. If you continue to experience problems, contact the dealers in your area. Before performing any maintenance procedure or inspection, stop the engine, wait five minutes to allow all parts to cool. - Page 21 The Belt frays or rolls A Pulley groove may be nicked. Check the Belt for wear and hard spots. File off any nicks on the Pulley. over the Pulley. The Belt may be stretched; replace it. Blade vibrates when ...
-
Page 22: Parts Diagram
Parts Diagram... -
Page 23: Parts List
Parts List Ref.No Description Ref.No. Description Chassis Bearing 6005-2Z M8*30 hex screw+flat Protection cover washer+spring washer Blade axle Blade M8*20 hex screw+ larger washer+ Belt cover spring washer Axle seat Handle Axle cover Gearbox cable Gearbox cover Tension cable Tank seat Ignition switch Belt location frame M6*12 flange screw+nut... - Page 24 M8X40 black half-round Ignition switch board screws gearbox pulley transition pulley belt A914 M6X20 hex screw+flat spring A type double belt pulley washer M8locknut+springwasher+flat Transition shaft welding washer φ25 wire protection ring Tension springs battery Tensioner wheel bracket battery cover Anvil M6*16 flange screw + flat Bearing NA4900...
-
Page 25: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 26: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Powerhorse product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of two year from date of purchase. - Page 27 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in CHINA...
