- Page 1 CP4S 4-channel HD vehicle recorder User guide Version 1.1.2 | Last updated 6/25/2024 sensatainsights.com INSIGHTS...
-
Page 2: Table Of Contents
Software user guide ................ 14 Package contents ................5 Recording time table ................15 Introduction ................... 6 CP4S firmware update instructions via SD card ....16 Functions ....................8 Technical support and warranty ..........17 Installation .................... 11 CP4S accessory add-ons ............. 18 Operation —... - Page 3 WARNING: Sensata INSIGHTS installations should be performed by a qualified individual or installation professional only. Working with a vehicle’s power system can be dangerous to both you and your vehicle. This installation is intended only to be a guide since vehicle designs and power/input sources can vary significantly from vehicle to vehicle.
-
Page 4: Gps Reception
Sensata INSIGHTS CP4S user guide GPS reception 1. Activate the product in an area without large buildings to improve GPS reception. The commercial-purpose GPS has the average range error of more than 15 meters, and the range error could be more than 100 meters due to environmental conditions like buildings, roadside trees, etc. -
Page 5: Package Contents
3 Camera Input Cable pg. 3 Camera input cable (4x input) Wire Splice clip, Velcro Sticker, Torx Screw (x2), and Torx screwdriver 2. CP4S Hardware Overview Wire splice clip, hook-and-loop adhesive, Mounting bracket and Torx ® screw (x2) and Torx screwdriver 4x self-tapping screws 2x stubby antennas pg. -
Page 6: Introduction
Sensata INSIGHTS CP4S user guide Introduction Front view Rear view... - Page 7 The SIM card is not registered with the cellular network. Please verify the SIM is inserted correctly. Sensata INSIGHTS CP4S user guide o If it looks to be inserted correctly, please remove and re-insert the SIM card and try again Introduction o Power cycle the camera.
-
Page 8: Functions
Make sure the main unit and all components are properly connected. Once the CP4S has been wired to your vehicle power source, the CP4S will boot up. It will take around 30 seconds for the unit to be ready to record. - Page 9 Set your time zone using the configuration tool, then the CP4S gets its time from GPS satellites. Parking Mode Recording With parking mode activated and on normal recording mode, the CP4S will change to parking mode when the vehicle is not moving for more than 5 minutes, recording at 1FPS.
- Page 10 SD memory card format Please format [initialize] the SD card using the “CP4S Configuration Tool” software. A SD Memory Card Format blank SD card will also automatically format but will take a few minutes to complete. Please format (initialize) the SD card using the CP4S Configuration Tool software. A blank SD card will also automatically format but will take a few minutes to complete. Safe Removal of SD Card Safe removal of SD card Remove the Torx screw, and then slide the SD door open.
-
Page 11: Installation
WARNING: Sensata INSIGHTS installations should be performed by a qualified individual or installation professional only. Working with a vehicle’s power system can be dangerous to both you and your vehicle. This installation is intended only to be a guide since vehicle designs and power/input sources can vary significantly from vehicle to vehicle. -
Page 12: Operation - On-Screen Display
Sensata INSIGHTS CP4S user guide Operation — on-screen display Operation – On Screen Display The following displays can only be seen when a monitor is connected. The default display is 2*2 with all cameras shown, to change, press [M2] button to The following displays can only be seen when a monitor is connected. select which camera to view. Each press will change the camera on display with the last option being all camera views. The default display is quad view (2x2) with all cameras shown. To change the video display channel, press the M2 button to select which camera to view. -
Page 13: Configuration Tool User Guide
Configuration tool user guide CP4S Configuration Tool software The CP4/CP4S Configuration Tool allows you to further customize your device settings. If you wish to make specific calibration changes, please follow this link to download the most up-to-date software and gain access to supplemental documentation. -
Page 14: Software User Guide
CP4S user guide Software user guide SD Viewer Software SOFTWARE USER GUIDE Sensata INSIGHTS’ SD Viewer Software gives you access to enhanced video playback, editing and review. Please follow this link to download the software and gain access to supplemental documentation. PC Viewer Software PC SYSTEM REQUIREMENT Recommended PC specifications for PC Viewer Software Windows Vista. Windows 7, Windows 8/8.1... -
Page 15: Recording Time Table
Sensata INSIGHTS CP4S user guide Recording time table DRV file size Space for video/audio (MB) Reserved space for overwriting Hours Size 16GB 32GB 64GB 128GB 256GB 512GB 106.8MB 15,593 31,593 63,593 127,593 255,593 511,593 748MB 14,952 30,952 62,952 126,952 254,952... -
Page 16: Cp4S Firmware Update Instructions Via Sd Card
In this case, the firmware update can be much more eas If you’re using the CP4S with a SIM and connected service, please consult your telematics provider or Sensata INSIGHTS before attempting to update your device firmware. In this case, the firmware update can be much more easily applied to your device using SmartAPI over-the-air update service. -
Page 17: Technical Support And Warranty
Sensata INSIGHTS CP4S user guide Technical support and warranty Technical support For technical support, please contact your local distributor or visit support.smartwitness.com Limited warranty This product is supplied with a 2-year warranty. The warranty excludes products that have been misused (including accidental damage) and damage caused by normal wear and tear. -
Page 18: Cp4S Accessory Add-Ons
CP4S Accessory Add-ons Model Descriptions CP4S-LC Locking Steel Housing for CP4S Dimension : 155.00 x 130.00 x 24.00 mm, 330g Model Image Description CP4S-LC Locking steel housing for the CP4S Dimension: 155.00 x 130.00 x 24.00 mm, 330g SVA055-AM Road + Driver Facing Dual Camera (Road 1080p + Driver 720p) SVA055-AM Road + driver-facing dual camera (Road 1080p + driver 720p) SVA027-A Weatherproof Side Mount Camera, 720p... -
Page 19: Remote Controller Indicators And Led Specifications
Sensata INSIGHTS CP4S user guide Remote controller indicators and LED specifications Voice Warning Record Network Status/step Buzzer To hear the Voice, To hear the Voice, please audio Blue Green please audio output output cable to cable to speaker speaker Booting step 1 (0~20) -
Page 20: Safety Advice
Sensata INSIGHTS CP4S user guide Safety advice CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Please make sure you follow the safety advice/instructions given in the user guide. - Page 21 sensatainsights.com INSIGHTS...
