- Page 1 User Manual 07/2023 224BHAC36 Horizontal Open Air Merchandisers Models: 224BHAC28, 224BHAC36, 224BHAC51, 224BHAC63, 224BHAC75, 224WHAC28, 224WHAC36, 224WHAC51, 224WHAC63, 224WHAC75 Note: Please read this manual in its entirety prior to equipment setup, operation, and maintenance.
- Page 2 User Manual Horizontal Open Air Merchandisers Warnings DANGER – RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED. TO BE REPAIRED ONLY BY TRAINED SERVICE PERSONNEL. DO NOT PUNCTURE REFRIGERANT TUBING. PELIGRO - RIESGO DE INCENDIO O EXPLOSION. REFRIGERANTE INFLAMABLE UTILIZADO. PARA SER REPARADO SOLAMENTE POR PERSONAL DE SERVICIO CALIFICADO.
-
Page 3: Installation
User Manual Horizontal Open Air Merchandisers Installation Please read this manual thoroughly prior to equipment setup, operation, and maintenance. This unit is intended for use in a temperature-controlled environment less than 75 degrees Fahrenheit and 55% relative humidity. Malfunction due to improper conditions is not covered under warranty. -
Page 4: Temperature Controls
User Manual Horizontal Open Air Merchandisers Avoid installation in a high humidity and/or dusty area. • Humidity above 55% can cause the unit to rust, collect condensation, and may decrease efficiency. • Dust collected on condenser coil will cause unit to malfunction. •... -
Page 5: Defrost System
User Manual Horizontal Open Air Merchandisers Digital Control Units Controller #1 1. Hold "SET" for 1 second. The display will flash the current minimum temperature. 2. Use the arrow buttons to adjust the minimum temperature you'd like the unit to run at. 3. - Page 6 User Manual Horizontal Open Air Merchandisers Safety/Warning Please pay close attention to the safety notices in this section. Disregarding these notices may lead to serious injury and/or damage to the unit. Attention • To minimize shock and fire hazards, be sure not to overload outlet. Please designate one outet for your unit.
-
Page 7: Loading Product
User Manual Horizontal Open Air Merchandisers Loading Product • Do not block the air duct / fan at the top of the unit. Make sure there is at least 4” of clearance from the evaporator. • Ensure all shelves are sitting level and properly secured before loading products. •... -
Page 8: Troubleshooting
User Manual Horizontal Open Air Merchandisers Troubleshooting Problem Possible Cause Possible Solution Fuse blown or circuit breaker Replace fuse or reset circuit breaker. tripped. Compressor not Power cord unplugged. Plug in power cord. running. Thermostat set too high. Set thermostat to lower temperature. Cabinet in defrost cycle.
