- Page 1 CAR AUDIO AMPLIFIER TPT-15 00 USER MANUAL...
-
Page 2: Before Installing
EN-US Introduction Thank you so much for choosing a TIMPANO product! The chosen amplifier has been developed with the most advanced technology for those who are looking for high performance audio systems with one or more speakers and “pro car audio” system. - Page 3 Indicators LED POWER (blue LED): Indicates amplifier operation POWER when it is on. PROT (top red LED): Indicates that the amplifier PROT encountered malfunctions and entered protection CLIP mode, forcing it to shut down. Verify in the protection table below the possible problem and turn on the amplifier again.
- Page 4 TPT-1500 OVERVIEW 1. INPUT: Input of the signal to be amplified. Connect to the radio/player through high quality shielded RCA cables to prevent unwanted noise. 2. LEVEL: Signal level control in the amplifier input. 3. CROSSOVER: ▪ HIGH PASS FILTER (H.P.F.): This variable control allows you to select the initial frequency from 10Hz to 90Hz that will be reproduced by the amplifier.
- Page 5 TPT-1500 OVERVIEW ventilation ventilation 7. OUTPUT CONNECTOR (SPEAKERS): MONO output of amplified signal for speakers connection. Check the minimum impedance and polarities before performing the installation. 8. POSITIVE POWER SUPLY CONNECTOR: Connect to the positive battery terminal through a minimum 4 AWG cable with a fuse/circuit breaker (70A) as close to the battery as possible.
- Page 6 TPT-1500 INSTALLATION Installation should only be done by qualified professionals with the product turned OFF. NEGATIVE: Speakers: 4 AWG cable 12 AWG cables POSITIVE: Check the minimum impedance 4 AWG cable supported by the amplifier. Fuse Radio / Player (Maximum 12”...
- Page 7 TPT-1500 SPECIFICATIONS 1 OHM 2 OHMs 4 OHMs Minimum Output Impedance: Number of Channels 1600W RMS 1600W RMS 1600W RMS @ 1 Ohms @ 2 Ohms @ 4 Ohms Power Output @ 14.4V: 1050W RMS 900W RMS 900W RMS @ 2 Ohms...
-
Page 8: Troubleshooting
Troubleshooting AMPLIFIER DOES NOT TURN ON: ▪ Verify that the cables are connected correctly. Make sure all connections have electrical and mechanical contact. ▪ Fuses or circuit breakers may be defective or blown. Check the condition of the circuit breakers and if it is compatible with the equipment consumption. ▪...
