Panasonic CQ-EA1060L Service Manual

Specification*
General
Power Supply
Current Consumption
Power Output
Speaker Impedance
AM Radio
Frequency Range
Usable Sensitivity
FM Stereo Radio
Frequency Range
Usable Sensitivity
Tape Player
DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Less than 2.5A (0.5W×4ch)
12W×2ch
4Ω
530 - 1,710kHz
14dB/µV (S/N 20dB)
87.7 - 107.9MHz
12dB/µV (S/N 30dB)
AUTOMOTIVE ELECTRONICS
AUDI
CQ-EA1060L
CQ-EA1061L
CQ-EA1062L
CQ-EA1063L
AM/FM MPX ELECTRONIC TUNING
RADIO with Stereo Cassette Tape
Player and CD Changer
DESTINATION : North America
PRODUCED AFTER (CQ-EA1060L-61L) : Apr., 2001
PRODUCED AFTER (CQ-EA1062L) : Jly., 2001
PRODUCED AFTER (CQ-EA1063L) : Jun., 2001
[Note] See the next page about PART No. and VECLE.
Signal to Noise Ratio
Wow and Fuluter
ICD Player
Signal to Noise Ratio
Channel Separation
Dimensions**
Weight**
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
Dolby noise reduction manufactured under license from Dolby
Laboratories Licensing Corporation.
"Dolby" and the double-D symbol
Laboratories Licensing Corporation.
© 2001 Matsushita Communication Industrial Co.,
Ltd. All rights reserved. Unauthorized copying and
distribution is a violation of law.
ORDER No. AED0109025
55dB (IHF-A)
Less than 0.3%
More than 60dB (IHF-A)
More than 50dB (IHF-A)
179(W)×110(H)×163(D)mm
3.1kg
are trade marks of Dolby
I0
