SC185 BRUTE
SHREDDER – CHIPPER
SAFETY AND OPERATING INSTRUCTION MANUAL
This manual contains information concerning proper and improper
operation procedures, warnings, maintenance, troubleshooting, and
assembly tips. Everyone who operates this machine should read these
instructions and be thoroughly familiar with them.
THIS MACHINE IS CAPABLE OF INFLICTING
SERIOUS INJURY IF OPERATED IMPROPERLY
- READ WARNING & CAUTION LABELS -
MACKISSIC, INC. P.O. BOX 111, PARKER FORD, PA. 19457-0111
Phone: (610) 495-7181
e-mail: mackissic1@msn.com Fax: (610) 495-5951
Visit us on the web at WWW.MACKISSIC.COM
P/N 911-0401
8/29/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC185 BRUTE and is the answer not in the manual?

Questions and answers

Related Manuals for MACKISSIC SC185 BRUTE

Summary of Contents for MACKISSIC SC185 BRUTE

  • Page 1 THIS MACHINE IS CAPABLE OF INFLICTING SERIOUS INJURY IF OPERATED IMPROPERLY - READ WARNING & CAUTION LABELS - MACKISSIC, INC. P.O. BOX 111, PARKER FORD, PA. 19457-0111 Phone: (610) 495-7181 e-mail: mackissic1@msn.com Fax: (610) 495-5951 Visit us on the web at WWW.MACKISSIC.COM...

  • Page 2: Section I - Safety

    SECTION I – SAFETY This symbol points out important safety instructions, which , if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before attempting to operate your shredder/chipper. Failure to comply with these instructions may result in personal injury.
  • Page 3 MAKE CERTAIN THAT ALL SAFETY LABELS ON THIS EQUIPMENT ARE KEPT CLEAN AND IN GOOD CONDITION. IF YOU NEED REPLACEMENT LABELS, ORDER BY PART NUMBER. 080-0962 080-0967...
  • Page 4 091-0044 091-0088 091-0057...
  • Page 5 930-0006 930-0002 930-0009...
  • Page 6 930-0004 930-0007 930-0010...
  • Page 7 940-0001 940-0011 091-0043...
  • Page 8 091-0062 091-0093 930-0014...
  • Page 9 930-0013...

  • Page 10: Safe Operation Practices

    SAFE OPERATION PRACTICES TRAINING • Read this owner’s manual carefully in its entirety before attempting to assemble this machine. Read, understand, and follow all instructions on the machine before operation. Be completely familiar with the controls and the proper use of the machine before operating it. Keep this manual in a safe place for future and regular reference and for ordering replacement parts.

  • Page 11: Operation

    OPERATION • Never place your hands, feet, or any part of your body in the shredder hopper, chipper chute, discharge opening, or near or under any moving part while the shredder/chipper is running. Keep clear of the discharge opening at all times. If it becomes necessary to push material into the shredder hopper or chipper chute, use a small diameter stick, NOT YOUR HANDS.
  • Page 12 • Keep area of discharge clear of people, animals, buildings, glass or anything else that will obstruct clear discharge, cause injury or damage. Wind can also change discharge direction, so be aware. • Do not allow an accumulation of processed material to build up in the discharge area as this will prevent proper discharge and can result in kickback from the shredder hopper or chipper chute.

  • Page 13: Your Responsibility

    • Only operate your shredder/chipper from the operator zone. • Know how to turn your unit off. • Never move your chipper or leave it unattended with the engine running. • Follow engine owner’s manual for engine maintenance and repair. YOUR RESPONSIBILITY •...

  • Page 14: Section Ii - Assembly Instructions

    SECTION II – ASSEMBLY INSTRUCTIONS PACKAGE CONTENTS SKID POLYBAG BOLT BAG PART # WHERE USED OWNER’S MANUAL SHREDDER/CHIPPER (x1) KNIFE GAUGE 030-0384 GAUGING KNIFE (x1) 3/8-16 x 3-1/2” HHCS PLTD SHREDDER HOPPER ENGINE MANUAL 090-0018 HITCH ASSEMBLY CHIPPER HOPPER WARRANTY CARD (x2) 1/2-13 GRIPCO LOCKNUT 090-0050 HITCH ASSEMBLY...
  • Page 15 STEP II – ATTACHING THE HITCH ASSEMBLY • Place the base on Jack Stands so that the frame is level with the ground (Figure 2). • Position the Support Leg in the down position and secure using the Pin and Hitch Clip (Figure 3). •...
  • Page 16 STEP III – ATTACHING THE SHREDDER HOPPER • Place the shredder hopper (item #2) onto the basic unit (item #1) making sure the shredder hopper flange is up against the top plate allowing minimal or no gap. • Secure the front two bolts (item #6) and locknuts (item #5) towards the discharge end. •...
  • Page 17 STEP IV – ATTACHING THE CHIPPER HOPPER • Attach the chipper hopper (item #4) to machine using four each 5/16”-18 x 3/4” carriage bolts (item #51), 5/16” flatwashers (item #47) and 5/16”-18 nylock nuts (item #10). Put head of bolt inside hopper with threads sticking out.

  • Page 18: Section Iii - Lubrication & Engine Start Up

    SECTION III – LUBRICATION & ENGINE START UP BEFORE STARTING ENGINE, ALWAYS CHECK OIL LEVEL! Refer to the engine owner’s manual for further details regarding OPERATION AND MAINTENANCE OF the engine. NOTE: ENGINE IS SHIPPED WITHOUT OIL! FILL CRANKCASE WITH OIL BEFORE STARTING ENGINE.

  • Page 19: Checking And Adding Oil

    CHECKING AND ADDING OIL • Check oil level before starting the engine. • Check level daily, or after every eight hours. • Keep oil level at FULL. • Do not overfill. Oil filling procedure: first add 1 quart. Start and run engine at idle for 30 seconds. Shut engine off and wait 30 seconds.

  • Page 20: To Start Engine

    STARTING AND STOPPING STARTING AND OPERATING TIPS • Store and fuel equipment in level position. • Use fresh fuel. • Use correct type of oil for expected starting temperature. • Remove external equipment/engine loads. • Periodically remove any debris buildup from the machine. •...

  • Page 21: Section Iv - Shredding & Chipping

    SECTION IV – SHREDDING & CHIPPING THIS SHREDDER/CHIPPER WAS DESIGNED FOR SHREDDING LEAFY GARDEN OR ORGANIC MATERIAL AND CHIPPING LIMBS OR BRANCHES. NEVER USE THIS MACHINE FOR ANY OTHER PURPOSE AS IT COULD CAUSE SERIOUS INJURY. CONTACT WITH INTERNAL ROTATING HAMMERS WILL CAUSE SERIOUS PERSONAL INJURY.
  • Page 22 • When chipping branches, sometimes a tail will be left at the end of a branch. To avoid this, rotate the branch as it is fed into the chute. • Rotating the branch as you feed it into the machine will improve chipping performance. •...
  • Page 23 USING THE CHIPPER HOPPER • This chipper-hopper is mounted on the side of the machine and is designed to chip the larger, heavier materials that the shredder-hopper isn’t designed to handle. Branches fed into the chute are turned into “chips” by the revolving chipper knife mounted on a flywheel.
  • Page 24 USE COMMON SENSE WHEN USING YOUR SHREDDER/CHIPPER. • LEARN TO RECOGNIZE THE CHANGE IN THE SOUND OF YOUR MACHINE WHEN IT IS OVERLOADED. • BECOME FAMILIAR WITH SUCCESSFUL OPERATING CONDITIONS AND AVOID THOSE THAT CAN OVERLOAD AND DAMAGE THE MACHINE. •...

  • Page 25: Section V - Maintenance & Storage

    SECTION V – MAINTENANCE & STORAGE IMPORTANT: The knife should be checked for sharpness and the bolts attaching them to the flywheel for tightness every 8-10 hours of operation. IMPORTANT: Every time you perform maintenance or any kind of service or check on the knife, be sure to check the gap between the knife and wear plate for proper setting.

  • Page 26: Knife Sharpening

    REMOVAL, SHARPENING AND RE-INSTALLATION OF CHIPPER KNIFE HOW TO REMOVE THE KNIFE • Stop the engine. • Remove spark plug wire(s) and keep away from spark plug(s). • Disconnect battery at negative terminal. • Open the access cover on the chipper basic machine. •...

  • Page 27: Knife Installation

    • The knife should never be sharpened to the extent that more than 3/32” is taken off this measurement. • Once this measurement is below 7/32” (see figure 3) the knife should be replaced. • If you are unable to remove dents or gouges with these guidelines, replace the knife. SHORT SIDE BEVEL EDGE SHARPENED KNIFE Figure 3...
  • Page 28 AFTER ANY BLADE OR WEAR PLATE MAINTENANCE OR ADJUSTMENT, ROTATE THE CHIPPER DISK BY HAND. WATCH AND LISTEN CAREFULLY FOR ANY UNUSUAL NOISES, CLICKING OR VIBRATION. IF ANY OF THESE ARE DETECTED, INSPECT THE MACHINE FOR DAMAGE, REPAIR OR REPLACE ANY DAMAGED PARTS AND CHECK FOR ANY LOOSE PARTS AND RETIGHTEN.

  • Page 29: Belt Replacement

    INSTRUCTIONS FOR ADJUSTING OR REPLACING BELT BELT ADJUSTMENT The belt on your chipper should deflect 3/8” under three pounds of pressure as shown in figure 1 below. If it doesn’t, adjust per the following directions. 3 LBS. PRESSURE REQUIRED TO 3/8"...
  • Page 30 CENTRIFUGAL CLUTCH TECH TIPS CLUTCH PART NO. 030-0612 THE SHOES AND SPRINGS ON THE CLUTCH ARE NORMAL WEAR ITEMS. IF YOU NOTICE DECREASED PERFORMANCE OF THE CLUTCH THEY SHOULD BE CHECKED AND REPLACED IF NECESSARY. The clutch on your machine is designed for rugged, dependable service, however, it is important to understand the limitations of a clutch.

  • Page 31: Clutch Maintenance

    CLUTCH MAINTENANCE The centrifugal clutch on this machine is permanently lubricated and does not require oil or grease. If, after long periods of use, the drum wobbles excessively, replace the drum assembly. Always replace shoes and springs in sets. Whenever shoes are changed, replace all springs. CLUTCH REMOVAL 1.
  • Page 32 030-0612 CLUTCH BREAKDOWN ITEM NO. PART NO. DESCRIPTION 030-0612-1 HUB ASSEMBLY 030-0612-2 BEARING 030-0612-3 SNAP RING 030-0612-4 SHOE 030-0612-5 DRUM 030-0612-6 RETAINING RING 030-0612-7 SPRING...

  • Page 33: Troubleshooting

    TROUBLESHOOTING SYMPTOM PROBLEM CORRECTION • Immediately stop engine. Clutch overheats. Clutch is slipping or rotor is • Remove spark plug wires. jammed or stopped. • Turn flywheel by hand to Belt burns. be sure it turns freely. Flywheel won’t turn. •...

  • Page 34: Lubrication And Maintenance

    LUBRICATION AND MAINTENANCE OPERATION PROCEDURE COMMENTS TIME • Change engine oil and • Follow oil filter after first five recommendations per the engine & owner’s BREAK IN hours. • Check belt tension. manual. • Adjust per directions. • Check all nuts and •...

  • Page 35: Section Vi - Parts

    SECTION VI - PARTS SC185 PARTS LIST ITEM NO. COMPONENT DESCRIPTION 921-0239 Frame Weldment 911-0212 Axle Bracket 911-0229 U-Bolt, 3/8-16 X 3 Dp X 2 Betw 709-3140 Frame Rail Spacer 911-0213 Battery Box 930-2122 450/550 Fender Wldmnt 911-0070 Axle Weldment 702-0040 Wheel &...
  • Page 36 408-0078 3/16 Class 1 Trailer Safety Ch 090-0123 3/8-16 X 3 1/2 Hhcs Gr 5 Pltd 090-0234 3/8 Uss Flatwasher Pltd 090-0438 5/16-18 J-Nut Plain 090-0228 3/8 Med Split Lockwasher Pltd 090-0098 3/8-16 X 3/4 Hhcs Gr5 Pltd 090-0114 3/8-16 X 2 Hhcs Gr5 Pltd 090-0755 5/16-18 X 6"...
  • Page 38 911-0400 BASIC MACHINE ITEM NO. COMPONENT DESCRIPTION 911-0316 Drive Side Plate 911-0317 Chipper Side Plate Weld (Td) 921-0026 Top Plate 921-0003 Scroll Weldment 911-0315 Rotor Weldment 921-0267 Chipper Disk Balanced 911-0318 Chipper Chute Side Weldment 913-0326 Wear Plate 913-0210 Access Cover 911-0050 3/8-16 X 15"Lg Hhcs Pltd (Tie 090-0066...

  • Page 41: Limited Warranty

    The warranty does not cover any product that has been altered or modified. In addition, the warranty does not extend to repairs made necessary by normal wear, or by the use of parts or accessories which, in the judgment of MacKissic, Inc. are either incompatible with the MacKissic product or adversely affect its operation, performance or durability.
